Connecting An External Device - Docomo arrows tab lte F-01D Instruction Manual

Connecting an external
device
◆ Operating data on microSD card
from a PC
When the terminal and a PC are connected by the included
PC connection USB cable T01, the microSD card in the
terminal is recognized as a removable disk by the PC, and
data on the microSD card can be operated from the PC.
･
Supported PC operating systems (OS) are "Microsoft
Windows XP", "Microsoft Windows Vista" and
"Microsoft Windows 7".
･
When an application that uses the microSD card is
running on the terminal, close the application before
mounting the microSD card on the PC.
1
Connect the terminal and a PC with the USB
cable
2
→[USB connected]→[Turn on USB
storage]
･
When the precaution [Turn on USB storage]
appears, tap [OK].
3
Display the removal disk on a PC
4
Drag-and-drop files between the microSD
card and the PC
✔INFORMATION
･
When the microSD card is mounted on the PC,
applications such as Camera that use the microSD card
cannot be used.
❖
Safely disconnecting the USB cable
･
Do not disconnect the USB cable during data transfer.
Doing so may damage or destroy the data.
1
Perform safely disconnecting the hardware
operation on the PC
2
[Turn off USB storage]→Disconnect the
USB cable
◆ Exchanging data to or from USB
mass storage
You can exchange data between the terminal and a USB
memory or an external hard disk drive connected via USB
with USB cable for external device connection T01
(optional).
1
Connect the terminal and a USB mass
storage with the USB cable
･
The USB mass storage is automatically mounted
(only 1 device when two or more are connected).
2
Perform required operations
✔INFORMATION
･
For a USB mass storage with AC adapter, connect the AC
adapter. Otherwise, the storage is not recognized.
❖
Removing USB mass storage
･
Do not disconnect the USB cable during data transfer.
Doing so may damage or destroy the data.
1
From the Applications menu, [Settings]→
[Storage]→[Unmount USB storage]→
Disconnect the USB cable
78
File management
