◆ Reserving software update
You can preset a time to update the software if you want
to specify another time for installing the update package.
1
Display preset time→[Sets Time]
The automatically-set rewrite start time is displayed.
2
Enter the desired time→[OK]
❖
When the reserved time is reached
When the reserved time is reached, the rewriting start
screen appears and the software update starts
automatically in about 3 seconds (Tapping [OK] starts
update immediately). Before the reserved time is reached,
make sure that the terminal is in a place with a strong
signal and the Home screen displayed.
✔INFORMATION
･
If there is insufficient battery power for a software update
at the reserved time, the software update will be
performed at the same time the following day.
･
Software is not updated at the reserved time while the OS
is being upgraded.
･
Even when an alarm, etc. is set at the same time as the
reserved time, software upgrade will be executed.
･
If F-01D is turned OFF at the reserved time, the software
update starts at the same time as the reserved time after
the terminal is turned ON.

Main specifications

■Phone
Product name
Size
Weight
Memory
Continuous FOMA/3G
stand-by
time
GSM
*1
LTE
Charging AC adapter
*2
time
DC adapter
LCD Type
Size
Number of
colors
Number of
dots
Image Type
pickup
Size
device
Number of effective
pixels
109
F-01D
×
Approx. 181 mm (H) 262 mm
×
(W) 11.3 mm (T)
Approx. 597 g
ROM : 16 GB
RAM : 1 GB
Stationary (Auto) : Approx.
1,600 H
Stationary (Auto) : Approx.
1,200 H
Stationary (Auto) : Approx. 900 H
AC Adapter F05 : Approx. 400
min.
AC Adapter 01/02 : Approx.
950 min.
Approx. 860 min.
TFT
Approx. 10.1 inches
16,777,216 colors
×
1,280 (H) 800 (V) dots (wide
VGA)
CMOS
Out-camera : Approx. 1/4.0
inches
In-camera : Approx. 1/6.0 inches
Out-camera : Approx.
5,100,000 pixels
In-camera : Approx. 1,300,000
pixels
