3. Save the carton and packing material in case the printer needs to be repacked.
4. Remove the packing tape from the front, back and sides of the printer.

About Your Printer


These are the main components of your printer. The following illustrations show the standard Dell 5330dn Mono Laser Printer and optional trays attached:

Front View

1
top cover
2
output support
3
output tray
4
control panel
5
control board cover
6
optional tray 2 (500-sheet paper feeder)
7
optional tray 3 (500-sheet paper feeder)
8
optional tray 4 (500-sheet paper feeder)

Rear View

Downloaded from ManualsPrinter.com Manuals
9
handle
10
tray 1 (500-sheet paper feeder)
11
multi-purpose feeder paper width guides
12
multi-purpose feeder extension
13
multi-purpose feeder
14
Output Expander
15
High Capacity Feeder
