General Setup - Draytek Vigor2912 User Manual

4 . 1 3 . 2 G e n e r a l S
4 . 1 3 . 2 G e n e r a l S
By clicking the General Settings, a new web page will appear so that you could configure the
SSID and the wireless channel. Please refer to the following figure for more information.
Available settings are explained as follows:
Item
Enable Wireless LAN
Mode
Channel
e t u p
e t u p
Description
Check the box to enable wireless function.
At present, the router can connect to 11b Only, 11g Only,
11n Only(2.4 GHz), Mixed (11b+11g), Mixed (11g+11n),
and Mixed (11b+11g+11n) stations simultaneously. Simply
choose Mixed (11b+11g+11n) mode.
Means the channel of frequency of the wireless LAN. The
325
Vigor2912 Series User's Guide
