Draytek Vigor2912 User Manual page 225

Available settings are explained as follows:
Item
Enable this account
User Name
Password
Confirm Password
Idle Timeout
Max User Login
External Service
Authentication
Log
Pop Browser Tracking
Window
Description
Check this box to enable such user profile.
Type a name for such user profile (e.g., LAN_User_Group_1,
WLAN_User_Group_A, WLAN_User_Group_B, etc). When a
user tries to access Internet through this router, an
authentication step must be performed first. The user has to
type the User Name specified here to pass the authentication.
When the user passes the authentication, he/she can access
Internet via this router. However the accessing operation will
be restricted with the conditions configured in this user profile.
The maximum length of the name you can set is 24 characters.
Type a password for such profile (e.g., lug123,
wug123,wug456, etc). When a user tries to access Internet
through this router, an authentication step must be performed
first. The user has to type the password specified here to pass
the authentication. When the user passes the authentication,
he/she can access Internet via this router with the limitation
configured in this user profile.
The maximum length of the password you can set is 24
characters.
Type the password again for confirmation.
If the user is idle over the limitation of the timer, the network
connection will be stopped for such user. By default, the Idle
Timeout is set to 10 minutes.
Such profile can be used by many users. You can set the
limitation for the number of users accessing Internet with the
conditions of such profile. The default setting is 0 which means
no limitation in the number of users.
The router will authenticate the dial-in user by itself or by
external service such as LDAP server or Radius server. If
LDAP or Radius is selected here, it is not necessary to
configure the password setting above.
Time of login/log out, block/unblock for the user(s) can be sent
to and displayed in Syslog. Please choose any one of the log
items to take down relational records for the user(s).
If such function is enabled, a pop up window will be displayed
on the screen with time remaining for connection if Idle
215
Vigor2912 Series User's Guide
