Next
Cancel
3. After typing the required information, click Next. The settings in the page limit the
wireless station (guest) accessing into Internet but not being allowed to share the LAN
network and VPN connection.
Available settings are explained as follows:
Item
Enable/Disable
SSID
Security Key
Rate Control
The WPA encrypts each frame transmitted from the radio
using the key, which either PSK (Pre-Shared Key) entered
manually in this field below or automatically negotiated via
802.1x authentication.
Either 8~63 ASCII characters, such as 012345678(or 64
Hexadecimal digits leading by 0x, such as
"0x321253abcde...").
Click it to get into the next setting page.
Exit the wireless wizard without saving any changes.
Description
Click it to enable or disable settings in this page.
Type the SSID name of this router. (SSID1)
The wireless mode offered by this wizard is WPA2/PSK.
The WPA encrypts each frame transmitted from the radio
using the key, which either PSK (Pre-Shared Key) entered
manually in this field below or automatically negotiated via
802.1x authentication.
Either 8~63 ASCII characters, such as 012345678(or 64
Hexadecimal digits leading by 0x, such as
"0x321253abcde...").
It controls the data transmission rate through wireless
connection.
Upload – Check Enable and type the transmitting rate for
data upload. Default value is 30,000 kbps.
Download – Type the transmitting rate for data download.
Default value is 30,000 kbps.
51
Vigor2912 Series User's Guide
