4 . 7 . 1 I P O b j e c t
4 . 7 . 1 I P O b j e c t
For IPs in a range and service ports in a limited range usually will be applied in configuring
router's settings, therefore we can define them with objects and bind them with groups for
using conveniently. Later, we can select that object/group that can apply it. For example, all
the IPs in the same department can be defined with an IP object (a range of IP address).
You can set up to 192 sets of IP Objects with different conditions.
Available settings are explained as follows:
Item
Set to Factory Default
Index
Name
To set a new profile, please do the steps listed below:
1. Click the number (e.g., #1) under Index column for configuration in details.
2. The configuration page will be shown as follows:
Description
Clear all profiles.
Display the profile number that you can configure.
Display the name of the object profile.
221
Vigor2912 Series User's Guide
