General Settings
Open Port-based Bridge
Connection for this
Channel
Open WAN Interface for
this Channel
ISP Access Setup, IP
Address From ISP, WAN
IP Network Settings, DNS
Server IP Address
After finished the above settings, click OK to save the settings.
VLAN Tag – Type the value as the VLAN ID number. Valid
settings are in the range from 1 to 4095. The network traffic
flowing on each channel will be identified by the system via
their VLAN Tags. Channels using the same WAN type may
not configure the same VLAN tag value.
Priority – Choose the number to determine the packet
priority for such VLAN. The range is from 0 to 7.
The settings here will create a bridge between the LAN ports
selected and the WAN. The WAN interface of the bridge
connection will be built upon the WAN type selected using
the VLAN tag configured.
Physical Members – Group the physical ports by checking
the corresponding check box(es) for applying the port-based
bridge connection.
Check the box to enable relating function.
WAN Application - Management can be specified for
general management (Web configuration/telnet/TR069). If
you choose Management, the configuration for this VLAN
will be effective for Web configuration/telnet/TR069.
IPTV - The IPTV configuration will allow the WAN
interface to send IGMP packets to IPTV servers.
WAN Setup – Choose PPPoE/PPPoA or Static or Dynamic
IP to determine what WAN settings must be configured.
For other settings, refer to Details Page for PPPoE in
WAN1.
