4 . 6 . 1 G e n e r a l S e
4 . 6 . 1 G e n e r a l S e
General Setup can determine the standard (rule-based or user-based) for the users controlled
by User Management. The mode (standard) selected here will influence the contents of the
filter rule(s) applied to every user.
Available settings are explained as follows:
Item
Mode
Authentication page
Display IP Address on
tracking window
Landing Page
After finishing all the settings here, please click OK to save the configuration.
t u p
t u p
Description
There are two modes offered here for you to choose. Each
mode will bring different filtering effect to the users
involved.
User-Based - If you choose such mode, the router will apply
the filter rules configured in User Management>>User
Profile to the users.
Rule-Based –If you choose such mode, the router will apply
the filter rules configured in Firewall>>General Setup and
Filter Rule to the users.
Web Authentication - Choose the protocol for web
authentication.
Display IP Address on the dialog box pops up after
successful login – Check the box to display the IP address of
the client on the pop up window after the user accesses into
Vigor router successfully..
On – The IP address of the user accessing into Vigor
router/Internet will be displayed on the tracking window.
Type the information to be displayed on the first web page
when the LAN user accessing into Internet via such router.
213
Vigor2912 Series User's Guide
