Draytek Vigor2912 User Manual page 255

Below shows the items which are categorized under Protocol.
Available settings are explained as follows:
Item
Profile Name
Select All
Clear All
Support List
Action
The profiles configured here can be applied in the Firewall>>General Setup and
Firewall>>Filter Setup pages as the standard for the host(s) to follow.
Description
Type a name for the CSM profile. The maximum length of
the name you can set is 15 characters.
Click it to choose all of the items in this page.
Uncheck all the selected boxes.
Display the all the information (name, version and note)
about IM, P2P, Protocol and others applications that Vigor
router supports for APPE function.
Block – Block all the packets passing with the settings
configured in this page.
Pass – Pass all the packets with the settings configured in
this page.
245
Vigor2912 Series User's Guide
