3
.
5
Q
o
S
S
e
t
t
i
3
.
5
Q
o
S
S
e
t
t
i
Assume a teleworker sometimes works at home and takes care of children. When working
time, he would use Vigor router at home to connect to the server in the headquarter office
downtown via either HTTPS or V PN to check email and access internal database. Meanwhile,
children may chat on Skype in the restroom.
1.
Go to Bandwidth Management>>Quality of Service.
2.
Click Setup link of WAN(1/2/3). Make sure the QoS Control on the left corner is
checked. And select BOTH in Direction.
3.
Set Inbound/Outbound bandwidth.
Vigor2912 Series User's Guide
n
g
E
x
a
m
p
l
e
n
g
E
x
a
m
p
l
e
Note: The rate of outbound/inbound must be smaller than the real bandwidth to
ensure correct calculation of QoS. It is suggested to set the bandwidth value for
inbound/outbound as 80% - 85% of physical network speed provided by ISP to
maximize the QoS performance.
78
