3.12.2 GV-Hot Swap VMS System V5

You can customize the display settings of GV-VMS. Click Home
select Configure , select System Configure, and click Set Position. This dialog box
appears. The right side of the dialog box is only available when multiple monitors are installed.
Select Monitor: If you have multiple monitors connected, select the monitor you want to
configure from the drop-down list.
Position: Offsets the position of the GV-VMS window relative to the upper-left corner of
the screen. The default position is 0, 0. A position of 100, 60 will place the GV-VMS
window 100 pixels to the right and 60 pixels below the upper-left corner. This function is
only supported when the GV-VMS window does not take up the entire screen.
Panel Resolution: Sets the Panel Resolution of the GV-VMS.
66
Figure 3-47
Figure 3-48
, select Toolbar ,
