GeoVision V5 User Manual page 73

8. Go to the system folder and locate DMPOS.exe.
Figure 3-45
9. Run DMPOS.exe. This dialog box appears.
10. In the Screen Setup tab, select a desired monitor display mode, such as Twin View or
Three View, from the Displayer Mode drop-down list.
11. To define the live view monitor, in the MultiCam tab, select Monitor 1 from the Select
Monitor drop-down list.
12. Click the desired application tab to move the application to the monitor, For example,
select the ViewLog tab and Monitor 2 from the Select Monitor drop-down list.
13. Click OK.
The live view should appear on monitor 1. After you open the ViewLog player, it will be
displayed on monitor 2.
For details, see Multi-view Display, Chapter 11, GV-DVR User's Manual (GV-Desktop >
Program button > User Manual).
Figure 3-46
Getting Started
3
65
