2.3.1.2 GV-5016H V5
No. Name
1 D-Type Audio and Video 1-16
D-Type Audio and Video 16-32 (For 32-Ch Model Only)
2
I/O Terminal Block
3
4 RJ-11 Port
＊
The RS-485± ports are not functional on GV-5016H V5.
For details on the other features of the motherboard and power supply on the rear panel, see
Figure 2-6.
18
Figure 2-7
