1.5 Options

Optional devices can expand your GV-Hot Swap Surveillance System V5 's capabilities and
versatility. For details on combining options for your system, see Appendix C. Combining
Optional Accessories.
GV-Video Loop
Through Card
GV-IO 12-In Card
GV-IO 12-Out Card
GV-Data Capture V3
Box
GV-Hub V2
GV-COM V2
GV-IO Box (4 Ports)
GV-IO Box (8 Ports)
GV-IO Box (16 Ports)
10
This card can take the video signal from the GV-Hot Swap
Surveillance System V5 and then split it into 16 signals while
maintaining video quality. It can meet the need for multiple spot
monitors.
** This device is not available for GV-SDI-204H V5, GV-5016H V5,
GV-900H V5 and GV-800H V5 models and GV-Hot Swap VMS
System V5.
With 12-point digital inputs, this card can expand the GV-Hot Swap
Surveillance System V5 up to 16 sensor inputs.
With 12-point relay outputs, this card can expand the GV-Hot Swap
Surveillance System V5 up to 16 alarm outputs.
GV-Data Capture V3 Box can integrate the GV-Hot Swap
Surveillance System V5 to an electronic POS system, while
GV-Data Capture V3E Box can establish such integration through
LAN or Internet.
**This device is not supported by GV-Hot Swap VMS System V5 /
Recording Server / Backup Center System.
An easy way for serial port extension. This hub can add 4
RS-232/RS-485 serial ports through the GV-Hot Swap Surveillance
System V5 's USB port.
This unit can add 1 RS-232/RS-485 serial port through the GV-Hot
Swap Surveillance System V5's USB port.
GV-IO Box 4 provides 4 inputs and 4 relay outputs, and supports
both DC and AC output voltages. A USB port is also provided for PC
connection.
GV-IO Box 8 provides 8 inputs and 8 relay outputs, and supports
both DC and AC output voltages. A USB port is also provided for PC
connection.
GV-IO Box 16 provides 16 inputs and 16 relay outputs, and supports
both DC and AC output voltages. A USB port is also provided for PC
connection.
