A Cables

Cable Types, Connectors, Length Restrictions, and Product IDs

The following table lists supported cables.
Although a considerable cable length can exist between the modular enclosures in the system,
Hewlett Packard Enterprise recommends that cable length between each of the enclosures be
as short as possible.
Connection From...
VIO enclosure to:
Blade element (ServerNet-to-processor port)
IP, Telco, Storage CLIM (ServerNet fabric
ports)
VIO enclosure to VIO enclosure (cross-link
connection)
Copper Ethernet ports on IP CLIM, Telco CLIM,
or VIO enclosure to RJ45 patch panel
Maintenance LAN interconnect
Maintenance LAN interconnect
Cable Type
MMF
MMF
CAT 5e UTP
CAT 6 UTP
CAT 5e UTP
CAT 6 UTP
Cable Types, Connectors, Length Restrictions, and Product IDs
Connectors
LC to LC
MTP to MTP
RJ-45 to RJ-45
RJ-45 to RJ-45
RJ-45 to RJ-45
RJ-45 to RJ-45
