AC Power Feeds

NS2300 systems can be ordered with the AC power cords for the PDU installed either top or
bottom.
Top: Power and I/O cables are routed from above the rack
Bottom: Power and I/O cables are routed from below the rack
Here are some typical power feed configurations for a NS2300 system:
AC Power Feeds Without UPS
Example of Bottom AC Power Feed Without UPS (page 38)
Example of Top AC Power Feed Without UPS (page 39)
AC Power Feeds With Single-Phase UPS
Example of Top AC Power Feed With Single-Phase UPS (page 40)
Example of Bottom AC Power Feed With Single-Phase UPS (page 41)
AC Power Feeds With Three-Phase UPS
Example of Top AC Power Feed with Three-Phase UPS (page 42)
Example of Bottom AC Power Feed With Three-Phase UPS (page 43)
Power Distribution for NS2300 Systems 37
