HP Integrity NonStop i NS2300 Planning Manual page 52

Enclosure Type
2
mPDU core
mPDU extension
bar
Blade element
(rx2800 i4)
VIO enclosure
G6 CLIM
Gen8 CLIM
Gen9 CLIM
D2700 SAS disk
enclosure, empty
D3700 SAS disk
enclosure, empty
SAS disk drive
200GB SAS 2.5"
SSD, Gen1
200GB SAS 2.5"
SSD, Gen2
400GB SAS 2.5"
SSD
RJ45 patch panel
Maintenance
switch (Ethernet)
Rack-mount
system console,
keyboard, and
display
R5000 UPS
(single-phase)
R12000/3 UPS
(three-phase)
ERM for
three-phase power
(AF434A)
R5000 ERM for
single-phase power
Total
1
iPDU=Intelligent PDU
2
mPDU=Modular PDU
For examples of calculating the weight for various enclosure combinations, see
Specifications for Enclosure Combinations" (page
52 System Installation Specifications for NS2300 Systems
Number of Weight
Enclosures
lbs
12
1.5
66
62
58
55
45
38
38
1
.52
.34
1
5
5
38
126
307 (with
batteries)
135 (without
batteries)
170
139
--
Total
kg lbs
5.5
0.7
29.9
28.2
26
24
20
17
17
0.5
.24
.15
.45
2.3
2.3
12.7
57
139.2 (with
batteries)
59.8 (without
batteries)
77
63
--
55).
kg
"Calculating
