Maintenance Switch

The HPE ProCurve maintenance switch provides the communication between the NS2300 system
through the VIO enclosures, CLIMs, the optional UPS, and the system console running or
accessing OSM software.
The NS2300 system requires multiple connections to the maintenance switch. For more
information, refer your service provider to the NonStop NS2100 and NS2300 System Hardware
Installation Manual or to the

System Console

A system console is a Windows Server purchased from Hewlett Packard Enterprise that runs
maintenance and diagnostic software for NS2300 systems. When supplied with a new NS2300
system, system consoles have factory-installed Hewlett Packard Enterprise and third-party
software for managing the system. You can install software upgrades from the NonStop System
Console Installer DVD.

UPS and ERM (Optional)

A rack-mounted uninterruptible power supply (UPS) is optional but recommended to provide
power during power failures when a site UPS is not available.
NOTE: For information on using OSM to manage: a site UPS, AC power monitoring, or for
power fail support, see the OSM Configuration Guide.
HPE supports these rack-mounted UPS modules which support up to two HPE ERMs per UPS;
no mixing of UPS and ERM types.
Supported UPS
Single-phase R5000
Three-phase R12000/3
More information
Power Specifications

UPS and ERM Checklist

UPS and ERM Checklist
√ Verify:
UPS's and ERMs are in the lowest portion of the system to avoid tipping and stability issues.
No more than two HPE ERMs are used per UPS; no mixing of UPS or ERM types.
The manufacturing default setting ride-through time for the optional HPE-supported UPS has been changed
to an appropriate value for the system. Service providers can refer to the NonStop NS2100 and NS2300
Hardware Installation Manual for these instructions
Your UPS configuration is supported. See
18 NS2300 System Overview
Technical Document for the system.
UPS Manuals
HPE UPS R5000 User Guide
HPE UPS Network Module User Guide
HPE 3 Phase UPS User Guide
HPE UPS Management Module User Guide
"UPS and Data Center Power Configurations" (page 64).
