1.2.2

General Specifications

CPU
Chipset
Memory
Storage 1
Storage 2
Network
I/O Ports
Expansion Slot
Additional Expansion
Slot
System
1.2.3
Power Specifications
Model
Power
(i5-3610ME)
Power
(i3-3210ME)
Output Power
Input Voltage
Model No.
Core i5-3610ME
Core i3-3120ME
Intel QM77
One 204 pin SO-DIMM slot, up to 8 G DDR3 (1600 MHz) / DDRL
(1333 MHz)
2.5" SATA HDD
2.5" SATA HDD (support Intel RAID function) (optional)
Support slim 8X or above DVD +/- RW (optional)
2 x Gigabit Ethernet ports, support Intel AMT (GbE1- Intel
82579LM,GbE2–Intel 82583V)
4 x COM port: 1 x isolated RS-232/422/485; 3 x RS232
1 x GPIO/RS-232 (8 channels, TTL level)
3 x USB3.0 + 2 x USB2.0
2 x Gigabit Ethernet ports
1 x D-SUB VGA ports
1 x HDMI ports
1 x Line-out port,1 x Mic-in port, 2 x 1 W speaker (built-in)
1 x PCI + 1 x PCIe x1 (default)
1 x PCIe x4 (available in the accessory box)
2 x PCIe x1 (optional)
2 x PCI (optional)
1 x mini PCIe long card slot (support mSATA)
1 x mini PCIe half long card slot
Windows XPE / Windows XP Pro / Windows Embedded Standard 7
/ Windows 7
PPC-6150
61 W (test system: Windows7 32bit)
50 W (test system: Windows XP 32bit) 60 W (test system: Windows XP 32bit)
55 W (test system: Windows7 32bit)
47 W (test system: Windows XP 32bit) 47 W (test system: Windows XP 32bit)
100-240 Vac, 50/60 Hz, 4 A ~ 2 A
Frequency Cache
2.7 GHz 4 M
2.4 GHz 3 M
PPC-6170
65 W (test system: Windows7 32bit)
55 W (test system: Windows7 32bit)
150 W (Max.)
3 PPC-6150/6170 User Manual
