  • Page 1 User Manual PCM-9563...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.

  • Page 3: Declaration Of Conformity

    Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.

  • Page 4: Technical Support And Assistance

    Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –...

  • Page 5: Ordering Information

    Ordering Information Model Number Description M.2 E Model Name Memory VGA LVDS HDMI* DP* eDP* GbE 1 SATAIII mSATA RS-232 miniPCIe PCI-104 Audio 422/485 Intel Celeron PCM-9563N-S1A1E SODIMM N3350 Intel Pentium PCM-9563NF-S2A1E SODIMM N4200 Intel Celeron PCM-9563NF-S1A1E SODIMM N3350 * By request...

  • Page 6: Safety Instructions

    The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
  • Page 7 Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder weiger. Haftungsausschluss: Die Bedienungsanleitungen wurden entsprechend der IEC- 704-1 erstellt. Advantech lehnt jegliche Verantwortung für die Richtigkeit der in die- sem Zusammenhang getätigten Aussagen ab. PCM-9563 User Manual...
  • Page 8 Safety Precaution - Static Electricity Follow these simple precautions to protect yourself from harm and the products from damage.  To avoid electrical shock, always disconnect the power from your PC chassis before you work on it. Don't touch any components on the CPU card or other cards while the PC is on.

  • Page 9: Table Of Contents

    Contents Chapter General Information ......1 Introduction ....................2 Product Specifications................2 Chipset ...................... 3 1.3.1 Functional Specifications .............. 3 1.3.2 Mechanical Specifications............. 4 1.3.3 Electrical Specifications ..............4 1.3.4 Environmental Specifications............4 Chapter Hardware Installation ......5 Jumpers ....................6 2.1.1 Jumper Description ...............
  • Page 10 Interrupt Assignments ................78 Table C.3: Interrupt assignments..........78 Table C.4: System I/O Ports ............79 PCM-9563 User Manual...

  • Page 11: Chapter 1 General Information

    Chapter General Information...

  • Page 12: Introduction

    Introduction ®  Intel Pentium N4200 Celeron N3350 & Atom™E3950/E3940/E3930 processor  EBX form factor standard, supports PCI-104  One SODIMM up to 8G DDR3L 1867MHz  Dual Display: VGA + LVDS(Displayport *) + HDMI * (Displayport)  Supports 6 x USB 2.0, 2 x USB 3.0 Supports 2 x SATAIII ...

  • Page 13: Chipset

    Chipset 1.3.1 Functional Specifications 1.3.1.1 Processor  Intel Pentium N4200 Celeron N3350 & Atom™E3950/E3940/E3930 processor 1.1/1.1/1.6/1.6/1.3 GHz  CPU Process: 45nm. 1.3.1.2 Chipset Intel Pentium N4200 Celeron N3350 & Atom™E3950/ Controller Hub E3940/E3930 processor 1.1/1.1/1.6/1.6/1.3 GHz Memory DDR3L 1867MHz Multi Display VGA+ LVDS/eDP*+ HDMI*/DP* VGA Memory Up to 224 MB of dynamic video memory allocation...

  • Page 14: Mechanical Specifications

    1.3.2 Mechanical Specifications 1.3.2.1 Dimensions 203mm(L*146mm(W) mm (8" x 5.75 inches) 1.3.2.2 Height top side 19mm, PCB 1.6mm, bottom side 6.8mm, total 27.4mm 1.3.2.3 Weight 700 g (1.54 lb) (with heatsink) (reference weight of total package) 1.3.3 Electrical Specifications 1.3.3.1 Power Supply Voltage ...

  • Page 15: Chapter 2 Hardware Installation

    Chapter Hardware Installation...

  • Page 16: Jumpers

    This chapter explains the setup procedures of the PCM-9563 A1 hardware, including instructions on setting jumpers and connecting peripherals, switches, indicators and mechanical drawings. Be sure to read all safety precautions before you begin the installation procedure. Jumpers Clear CMOS 1653003101 Part Number HD_3x1P_79_D...
  • Page 17 LCD Power 1653003260 Part Number HD_3x2P_79 Footprint PIN HEADER 3x2P 2.0mm 180D(M) SMD 21N22050 Description Setting Function (1-3)* +3.3V (3-5) (3-4) +12V   LVDS VCON Setting 1653000014 Part Number HD_2x2P_79 Footprint PIN HEADER 2x2P 2.00mm 180D(M) SMD 21N22050 Description Setting Function (1-2)* 3.3V High for VCON on LVDS...

  • Page 18: Jumper Description

      PCI VIO Setting 1653003101 Part Number HD_3x1P_79_D Footprint PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-13 WS Description Setting Function (1-2) (2-3)* +3.3V 2.1.1 Jumper Description Cards can be configured by setting jumpers. A jumper is a metal bridge used to close an electric circuit.

  • Page 19: Connectors

    Connectors Onboard connectors link the PCM-9563 to external devices such as hard disk drives, a keyboard, or floppy drives. The table below lists the function of each of the connec- tors. 2.2.1 Connector List 12V Power Input Standby Power Input 5V power output Battery SODIMMDDR3RVS_204...

  • Page 20: Mechanical

    Mechanical 2.3.1 Jumper and Connector Location CN25 CN26 CN33 CN35 CN28 CN29 CN30 CN34 CN31 CN32 CN24 CN22 CN27 CN23 CN36 CN19 CN18 CN10 CN13 CN11 CN40 CN45 CN15 CN48 CN38 CN39 CN14 CN46 CN12 CN37 Figure 2.1 Jumper and Connector Layout (Component Side) CN17 CN16 CN20...

  • Page 21: Board Dimensions

    2.3.2 Board Dimensions Figure 2.3 Board Dimension Layout (Component Side) PCM-9563 User Manual...

  • Page 22: Figure 2.4 Board Dimension Layout (Solder Side)

    Figure 2.4 Board Dimension Layout (Solder Side) PCM-9563 User Manual...

  • Page 23: Chapter 3 Bios Settings

    Chapter BIOS Settings...

  • Page 24: Entering Setup

    BIOS supports your CPU. If there is no number assigned to the patch code, please contact an Advantech application engineer to obtain an up-to-date patch code file. This will ensure that your CPU’s system status is valid.

  • Page 25: Advanced Bios Features Setup

    The Main BIOS setup screen has two main frames. The left frame displays all the options that can be configured. Grayed-out options cannot be configured; options in blue can. The right frame displays the key legend. Above the key legend is an area reserved for a text message. When an option is selected in the left frame, it is highlighted in white.
  • Page 26 3.1.2.1 ACPI Settings  Enable ACPI Auto Configuration Enable or disable BIOS ACPI auto configuration.  Enable Hibernation Enables or Disables System ability to Hibernate (OS/S4 Sleep State). This option may be not effective with some OS. PCM-9563 User Manual...
  • Page 27  ACPI Sleep State Select the highest ACPI sleep state the system will enter when the SUSPEND button is pressed.  Lock Legacy Resources Enables or Disables Lock of Legacy Resources 3.1.2.2 SCH3106 Super IO Configuration  Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA).
  • Page 28 3.1.2.3 Embedded Controller Configuration  EC Hardware Monitor This page display all information about system Temperature/Voltage/Current.  Backlight Enable Polarity This item allows users to set backlight mode.  1st LVDS Backlight control This item allows users to switch Backlight Control for PWM or DC mode. ...
  • Page 29 3.1.2.4 S5 RTC Wake Settings  Wake system from S5 Enable or disable System wake on alarm event. Select FixedTime, system will wake on the hr::min::sec specified. 3.1.2.5 Serial Port Console Redirection PCM-9563 User Manual...
  • Page 30  Console Redirection This item allows users to enable or disable console redirection for Microsoft Windows Emergency Management Services (EMS).  Console Redirection This item allows users to configuration console redirection detail settings.  Legacy Console Redirection This item allows users to configure the legacy serial redirection port. 3.1.2.6 CPU Configuration ...
  • Page 31 3.1.2.7 Network Stack Configuration  Network Stack Enable/Disable UEFI Network Stack.  Ipv4 PXE Support Enable Ipv4 PXE Boot Support. If disabled IPV4 PXE boot option will not be cre- ated.  Ipv4 HTTP Support Enables Ipv4 HTTP boot support. If disabled IPV4 HTTP boot option will not be created.
  • Page 32 3.1.2.8 CSM Configuration  CSM Support Enable/Disable CSM Support.  GateA20 Active UPON REQUEST - GA20 can be disabled using BIOS services. ALWAYS - do not allow disabling GA20; this option is useful when any RT code is executed above 1MB. ...
  • Page 33 3.1.2.9 USB Configuration  Legacy USB Support Enables Legacy USB support. AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications.  XHCI Hand-off This is a workaround for OSes without XHCI hand-off support. The XHCI owner- ship change should be claimed by XHCI driver.

  • Page 34: Chipset Configuration

    3.1.2.10 Security Configuration  TXE HMRFPO Disable  TXE EOP Message Send EOP Message Before Enter OS 3.1.3 Chipset Configuration PCM-9563 User Manual...
  • Page 35  North Bridge Details for North Bridge items.  South Bridge Details for South Bridge items.  Uncore Configuration Details for Uncore Configuration.  South Cluster Configuration Details for South Cluster Configuration. 3.1.3.1 North Bridge  Max TOLUD Maximum Value of TOLUD. PCM-9563 User Manual...
  • Page 36 3.1.3.2 South Bridge  Serial IRQ Mode Configure Serial IRQ Mode.  SMBus Support Enable/Disable SMBus Support.  OS Selection Select the target OS. PCM-9563 User Manual...
  • Page 37 3.1.3.3 Uncore Configuration  LVDS Panel Type Select LCD Panel Type.  Integrated Graphics Device Enable: Enable Integrated Graphics Device (IGD) when selected as the Primary Video Adaptor. Disable : Always disable IGD.  RC6 Render Standby) Check to enable render standby support. ...
  • Page 38 3.1.3.4 South Cluster Configuration  HD-Audio Configuration HD-Audio Configuration Settings.  LPSS Configuration LPSS Configuration Settings.  PCI Express Configuration PCI Express Configuration Settings.  SATA Drives Press <Enter> to select the SATA Device Configuration Setup options.  SCC Configuration SCC Configuration Settings.
  • Page 39 3.1.3.4.1HD-Audio Configuration  HD-Audio Support Enable/Disable HD-Audio Support. 3.1.3.4.2LPSS Configuration  LPSS I2C #1 Support (D22:F0) PCM-9563 User Manual...
  • Page 40 Enable/Disable LPSS I2C #1 Support.  Set LPSS I2C #1 Speed Select LPSS I2C #1 Speed. 3.1.3.4.3PCI Express Configuration  Compliance Mode Compliance Mode Enable/Disable.  PCI Express Root Port 1 / 5 Control the PCI Express Root Port.  Onboard LAN1/LAN2/LAN3 Controller Select to Enable or Disable Onboard LAN1/LAN2/LAN3 Controller.
  • Page 41 3.1.3.4.4SATA Drives  Chipset SATA Enable or Disable the Chipset SATA Controller. 3.1.3.4.5SCC Configuration  SCC SDIO Support (D30:F0) PCM-9563 User Manual...
  • Page 42 Enable/Disable SCC SDIO Support. 3.1.3.4.6USB Configuration  XHCI Pre-Boot Driver Enable/Disable XHCI Pre-Boot Driver Support.  USB Port Disable Override Selectively Enable/Disable corresponding USB port from reporting a Device Connection to the controller.  XHCI Disable Compliance Mode Options to disable XHCI Link Compliance Mode. ...
  • Page 43 3.1.3.4.7Miscellaneous Configuration  High Precision Timer Enable or Disable the High Precision Timer.  Restore AC Power Loss Specify what state to go to when power is re-applied after a power failure (G3 state).  BIOS Lock Enable/Disable the BIOS Lock Enable feature. ...

  • Page 44: Security

    3.1.4 Security Select Security Setup from the PCM-9563 Setup main BIOS setup menu. All Security Setup options, such as password protection and virus protection are described in this section. To access the sub menu for the following items, select the item and press <Enter>: ...

  • Page 45: Boot

    3.1.5 Boot  Setup Prompt Timeout Number of seconds that the firmware will wait before initiating the original default boot selection. A value of 0 indicates that the default boot selection is to be initiated immediately on boot. A value of 65535(0xFFFF) indicates that firm- ware will wait for user input before booting.

  • Page 46: Save & Exit

    3.1.6 Save & Exit  Save Changes and Exit This item allows you to exit system setup after saving the changes.  Discard Changes and Exit This item allows you to exit system setup without saving any changes.  Save Changes and Reset This item allows you to reset the system after saving the changes.
  • Page 47 PCM-9563 User Manual...
  • Page 48 PCM-9563 User Manual...

  • Page 49: Chapter 4 Extension I/O Installation

    Chapter Extension I/O Installation...
  • Page 50 Align the pin connector carefully and apply force evenly. PCM-9563 User Manual...
  • Page 51 PCI Card Backplane Align carefully; apply force evenly Make sure the PCI card is fully seated. PCM-9563 User Manual...
  • Page 52 PCM-9563 User Manual...

  • Page 53: Appendix A Pin Assignments

    Appendix Pin Assignments...
  • Page 54 12V Power Input 1655004509-01 Part Number WF_2x2P_165_BOX_D Footprint Description Pin Name +12V +12V Standby Power Input 1655303020 Part Number WHL3V-2M Footprint WAFER BOX 3P 2.0mm 180D(M) DIP 2001-WS-3 Description Pin Name +5VSB PSON#   5V power output 1655002000 Part Number WF_2P_100_D Footprint WAFER 2P 2.54mm 180D(M) DIP 2542-WS-2...
  • Page 55   SODIMMDDR3RVS_204 1651002082-11 Part Number DDR3_204P_AS0A626-N2 Footprint Description Pin Name Power Switch 1655302020 Part Number WF_2P_79_BOX_R1_D Footprint WAFER BOX 2P 2.0mm 180D(M) DIP A2001WV2-2P Description Pin Name PSIN   Reset 1655302020 Part Number WF_2P_79_BOX_R1_D Footprint WAFER BOX 2P 2.0mm 180D(M) DIP A2001WV2-2P Description Pin Name RESET#...
  • Page 56   CN10 Audio 1653208260 Part Number HD_8x2P_79_BOX Footprint BOX HEADER 8x2P 2.00mm 180D(M) SMD 23N6850 Description Pin Name SPK_R+ SPK_R- SPK_L+ SPK_L- LOUTR LOUTL LINR LINL MICR MICL CN11 LAN1 1653205260 Part Number HD_5x2P_79_BOX Footprint BOX HEADER 5x2P 2.0mm 180D(M) SMD 23N6850 Description Pin Name BI_DD+(GHz)
  • Page 57 CN12 LAN1/2 LED 1653004260 Part Number HD_4x2_79 Footprint PIN HEADER 4x2P 2.0mm 180D(M) SMD 21N22050 Description Pin Name +V3.3_LAN1CON LAN1_LINK100# LAN2_LINK100# LAN1_ACT# LAN2_ACT# LAN1_LINK1000# LAN2_LINK1000# CN13 LAN2 1653205260 Part Number HD_5x2P_79_BOX Footprint BOX HEADER 5x2P 2.0mm 180D(M) SMD 23N6850 Description Pin Name BI_DD+(GHz) BI_DD-(GHz)
  • Page 58 CN14 LAN3 1653205260 Part Number HD_5x2P_79_BOX Footprint BOX HEADER 5x2P 2.0mm 180D(M) SMD 23N6850 Description Pin Name BI_DD+(GHz) BI_DD-(GHz) BI_DC+(GHz) BI_DC-(GHz) RX+(10/100),BI_DB+(GHz) RX-(10/100),BI_DB-(GHz) TX+(10/100),BI_DA+(GHz) TX-(10/100),BI_DA-(GHz) PCM-9563 User Manual...
  • Page 59 CN15 PCI-104 1653130428 Part Number PCI_PLUS_264-40303 Footprint PCB SKT 30x4P 2.00mm 180D(F) DIP 264-40303-02 Description Pin Name VI/O (+5V or +3.3V) AD05 C/BE0# AD11 AD14 +3.3V SERR# PA10 PA11 STOP# PA12 +3.3V PA13 FRAME# PA14 PA15 AD18 PA16 AD21 PA17 +3.3V PA18 IDSEL0...
  • Page 60 PB13 PB14 AD16 PB15 +3.3V PB16 AD20 PB17 AD23 PB18 PB19 C/BE3# PB20 AD26 PB21 PB22 AD30 PB23 PB24 REQ2# PB25 VI/O (+5V or +3.3V) PB26 CLK0 PB27 PB28 INTD# PB29 INTA# PB30 REQ3# AD01 AD04 AD08 AD10 AD15 PC10 +3.3V PC11 LOCK#...
  • Page 61 AD00 AD03 AD06 M66EN AD12 +3.3V PD10 PD11 PD12 DEVSEL# PD13 +3.3V PD14 C/BE2# PD15 PD16 AD19 PD17 +3.3V PD18 IDSEL2 PD19 IDSEL3 PD20 PD21 AD27 PD22 AD31 PD23 VI/O (+5V or +3.3V) PD24 GNT0# PD25 PD26 CLK1 PD27 PD28 RESET# PD29 INTC#...
  • Page 62   CN16 1654010809-01 Part Number SIM_6P_5210622-SINR03 Footprint SIM card conn. 6p 2.54mm 90D(F) SMD 5210622-SINR Description Pin Name UIM_PWR UIM_RESET UIM_CLK UIM_VPP UIM_DATA PCM-9563 User Manual...
  • Page 63   CN17 Mini PCIE 1654002538 Part Number FOX_AS0B226-S68K7F Footprint MINI PCI E 52P 6.8mm 90D SMD AS0B226-S68Q-7H Description Pin Name WAKE# +3.3VSB +1.5V UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RESET UIM_VPP W_DISABLE# PERST# PERn0 +3.3VSB PERp0 +1.5V SMB_CLK PETn0 SMB_DAT PETp0 USB D- USB D+ +3.3VSB...
  • Page 64 +1.5V +3.3VSB   CN18 SATA 1654004659 Part Number SATA_7P_WATM-07DBN4A3B8UW_D Footprint Serial ATA 7P 1.27mm 180D(M) DIP WATM-07DBN4A3B8 Description Pin Name PCM-9563 User Manual...
  • Page 65   CN19 SATA 1654004659 Part Number SATA_7P_WATM-07DBN4A3B8UW_D Footprint Serial ATA 7P 1.27mm 180D(M) DIP WATM-07DBN4A3B8 Description Pin Name PCM-9563 User Manual...
  • Page 66   CN20 mSATA 1654002538 Part Number FOX_AS0B226-S68K7F Footprint MINI PCI E 52P 6.8mm 90D SMD AS0B226-S68Q-7H Description Pin Name WAKE# +3.3VSB +1.5V UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RESET UIM_VPP W_DISABLE# PERST# PERn0 +3.3VSB PERp0 GND  +1.5V SMB_CLK PETn0 SMB_DAT PETp0 USB D- USB D+ +3.3VSB...
  • Page 67 +1.5V +3.3VSB PCM-9563 User Manual...
  • Page 68   CN21 M.2 connector symbol 1654011871-01 Part Number NGFF_75P_2199230-2 Footprint Description Pin Name +3.3VSB USB_D+ +3.3VSB USB_D- SDIO_CLK SDIO_CMD SDIO_DATA0 SDIO_DATA1 SDIO_DATA2 SDIO_DATA3 SDIO_WAKE# SDIO_RESET# PETp0 PETn0 PERp0 PERn0 REFCLK+ REFCLK- PERESET# W_DISABLE#2 PEWAKE# W_DISABLE#1 PCM-9563 User Manual...
  • Page 69 CN22 COM1/COM2 1653004793 Part Number HD_10x2P_79_23N685B-20M10 Footprint BOX HEADER 10x2P 2.0mm 180D(M)SMD 23N685B-20M10B Description Pin Name DCD1# DSR1# RXD1 RTS1# TXD1 CTS1# DTR1# RI1# DCD2# DSR2# RXD2 RTS2# TXD2 CTS2# DTR2# RI2# PCM-9563 User Manual...
  • Page 70   CN23 COM3/COM4 1653004793 Part Number HD_10x2P_79_23N685B-20M10 Footprint BOX HEADER 10x2P 2.0mm 180D(M)SMD 23N685B-20M10B Description Pin Name DCD3# DSR3# RXD3 RTS3# TXD3 CTS3# DTR3# RI3# DCD4# DSR4# RXD4 RTS4# TXD4 CTS4# DTR4# RI4# PCM-9563 User Manual...
  • Page 71 CN24 COM5/COM6 1653205260 Part Number HD_5x2P_79_BOX Footprint BOX HEADER 5x2P 2.0mm 180D(M) SMD 23N6850 Description Pin Name COM5_422_RXD- COM6_422_RXD- COM5_422_RXD+ COM6_422_RXD+ COM5_485-422_TXD+ COM6_485-422_TXD+ COM5_485-422_TXD- COM6_485-422_TXD-   CN25 Inverter Power Output 1655000453 Part Number WHL5V-2M-24W1140 Footprint WAFER BOX 2.0mm 5P 180D(M) DIP WO/Pb JIH VEI Description Pin Name +12V...
  • Page 72 CN26 48 bits LVDS Panel 1653920200 Part Number SPH20X2 Footprint B/B Conn. 40P 1.25mm 90D SMD DF13-40DP-1.25V(91) Description Pin Name +5V or +3.3V +5V or +3.3V +5V or +3.3V +5V or +3.3V LVDS0_D0- LVDS1_D0- LVDS0_D0+ LVDS1_D0+ LVDS0_D1- LVDS1_D1- LVDS0_D1+ LVDS1_D1+ LVDS0_D2- LVDS1_D2- LVDS0_D2+...
  • Page 73 CN27 1653208260 Part Number HD_8x2P_79_BOX Footprint BOX HEADER 8x2P 2.00mm 180D(M) SMD 23N6850 Description Pin Name GREEN BLUE DDAT HSYNC VSYNC DCLK PCM-9563 User Manual...
  • Page 74 CN28 HDMI 1653910261 Part Number SPH10X2 Footprint B/B Conn 10x2P 1.25mm 180D(M)SMD DF13-20DP-1.25V Description Pin Name TMDS Data2– TMDS Clock– TMDS Data2+ TMDS Clock+ TMDS SDA TMDS Data1– TMDS SCL TMDS Data1+ TMDS Data0– TMDS Data0+ Hot Plug Detect PCM-9563 User Manual...
  • Page 75   CN29 1653910261 Part Number SPH10X2 Footprint B/B Conn 10x2P 1.25mm 180D(M)SMD DF13-20DP-1.25V Description Pin Name AUX- AUX+ Hot Plug Detect +5V or +3.3V +5V or +3.3V PCM-9563 User Manual...
  • Page 76   CN30 Internal USB 1653005260 Part Number HD_5x2P_79_N10 Footprint PIN HEADER 2x5P 2.0mm 180D(M) SMD 21N22050 Description Pin Name A_D- B_D- A_D+ B_D+   CN31 Internal USB 1653005260 Part Number HD_5x2P_79_N10 Footprint PIN HEADER 2x5P 2.0mm 180D(M) SMD 21N22050 Description Pin Name A_D- B_D-...
  • Page 77 CN32 Internal USB 1653005260 Part Number HD_5x2P_79_N10 Footprint PIN HEADER 2x5P 2.0mm 180D(M) SMD 21N22050 Description Pin Name A_D- B_D- A_D+ B_D+ CN33 Internal USB 3.0 1653004847 Part Number HD_10x2P_79_BOX_D_52X-80 Footprint Description Pin Name A_SSRX- A_SSRX+ A_SSTX- A_SSTX+ A_D- A_D+ B_D+ B_D- B_SSTX+...
  • Page 78 CN34 1653213260 Part Number HD_13x2P_79_BOX Footprint BOX HEADER 13*2P 180D(M) 2.0mm SMD Description Pin Name STROBE# AUTOFEED# ERROR# INIT# SLCT IN# ACK# BUSY SLCT PCM-9563 User Manual...
  • Page 79 CN35 1655306020 Part Number WHL6V-2M Footprint WAFER BOX 6P 2.0mm 180D(M) DIP A2001WV2-6P Description Pin Name KBCLK KBDAT MSCLK MSDAT CN36 1655304020 Part Number WF_4P_79_BOX_R1_D Footprint WAFER BOX 2.0mm 4P 180D(M) W/LOCK A2001WV2-4P Description Pin Name I2C_DAT I2C_CLK   CN37 SMBus 1655304020 Part Number...
  • Page 80   CN38 GPIO 1653005261 Part Number HD_5x2P_79 Footprint PIN HEADER 5x2P 2.0mm 180D(M) SMD 21N22050 Description Pin Name GPIO4 GPIO0 GPIO5 GPIO1 GPIO6 GPIO2 GPIO7 GPIO3   CN39 GPIO8-15 1653005261 Part Number HD_5x2P_79 Footprint PIN HEADER 5x2P 2.0mm 180D(M) SMD 21N22050 Description Pin Name GPIO12...
  • Page 81   CN40 Smart FAN 1655004347 Part Number WF_4P_100_D_744-81-04TW30 Footprint Description Pin Name +12V SPEED   CN45 PCI Slot 1654002099 Part Number SL-PCI Footprint SLOT 60x2P 180D(F) DIP EH06001-HHW-DF Description Pin Name +12V INTA# INTC# GNT# VI/O (+5V or +3.3V) GNT# +3.3VSB RESET# VI/O (+5V or +3.3V)
  • Page 82 AD22 AD20 AD18 AD16 +3.3V FRAME# TRDY# STOP# +3.3V AD15 +3.3V AD13 AD11 AD09 C/BE0# +3.3V AD06 AD04 AD02 AD00 VI/O (+5V or +3.3V) -12V INTB# INTD# REQ# PCM-9563 User Manual...
  • Page 83 REQ# VI/O (+5V or +3.3V) AD31 AD29 AD27 AD25 +3.3V C/BE3# AD23 AD21 AD19 +3.3V AD17 C/BE2# IRDY# +3.3V DEVSEL# LOCK# PERR# +3.3V SERR# +3.3V C/BE1# AD14 AD12 AD10 AD08 AD07 +3.3V AD05 AD03 AD01 VI/O (+5V or +3.3V) PCM-9563 User Manual...
  • Page 84   CN46 PWR/HDD/LAN3 LED 1653004260 Part Number HD_4x2_79 Footprint PIN HEADER 4x2P 2.0mm 180D(M) SMD 21N22050 Description Pin Name PWR LED+ HDD LED+ PWR LED- HDD LED- +V3.3_LAN LAN3_LINK100# LAN3_ACT# LAN3_LINK1000#   CN48 PCI-104 -12V Input 1653002101 Part Number HD_2x1P_79_D Footprint PIN HEADER 2*1P 180D(M)SQUARE 2.0mm DIP W/O Pb Description...

  • Page 85: Appendix B Optional Extras For Pcm-9563 A1

    Appendix Optional Extras for PCM-9563 A1...

  • Page 86: Pcm-10586-9563E Cable Kit For Pcm-9563

    The PCM-9563 requires several cables for normal operation. You can make them yourself or purchase an optional cable kit assembly, which includes the following PCM-10586-9563E Cable kit for PCM-9563 Table B.1: PCM-10586-9562E Cable kit for PCM-9562 A1 Cable PCM-9563 Quantity Terminating Connector Description Connector...

  • Page 87: Appendix C System Assignments

    Appendix System Assignments...

  • Page 88: 1St Mb Memory Map

    1st MB Memory Map Table C.1: 1st MB memory map Addr. Range (Hex) Device E0000h - FFFFFh System ROM D0000h - DFFFFh System RAM C0000h - CFFFFh VGA BIOS A0000h - BFFFFh Legacy Video Area 00000h - 9FFFFh Base memory DMA Channel Assignments Table C.2: DMA channel assignments Channel...

  • Page 89: Table C.4: System I/O Ports

    Table C.4: System I/O Ports Addr. Range (Hex) Device 00-1F Reserved 20-2D Interrupt Controller 2E-2F Motherboard resources 30-3D Interrupt Controller 40-43 Timer Register 4E-4F Motherboard resources 50-53 Timer/Counter 60-67 NMI Register/Keyboard Controller Real-time clock, non-maskable interrupt (NMI) mask, PMC Regis- 70-7F 80-9F DMA page register...

This manual is also suitable for:
