- Page 1 User Manual PPC-415 TGL ® Intel Core i Processor Based Micro-Computer with 15" Color TFT LCD Display...
- Page 2 No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable.
- Page 3 This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This type of cable is available from Advantech. Please contact your local supplier for ordering information.
- Page 4 In accordance with IEC 704-1:1982 specifications, the sound pressure level at the operator’s position does not exceed 70 dB (A). DISCLAIMER: These instructions are provided according to IEC 704-1 standards. Advantech disclaims all responsibility for the accuracy of any statements contained herein. PPC-415 TGL User Manual...
- Page 5 Battery Information Batteries, battery packs and accumulators should not be disposed of as unsorted household waste. Please use the public collection system to return, recycle, or treat them in compliance with the local regulations. PPC-415 TGL User Manual...
- Page 6 PPC-415 TGL User Manual...
-
Page 7: Table Of Contents
External COM Port Pin Assignments ............36 Chapter Software Setup ........39 Installing Drivers..................40 BIOS Setup Utility ................... 40 4.2.1 Entering BIOS Setup..............40 4.2.2 COM5 Mode (RS422/485) Selection .......... 41 4.2.3 Wake Up by LAN ................ 42 PPC-415 TGL User Manual... - Page 8 PPC-415 TGL User Manual viii...
-
Page 9: Chapter 1 Overview
Chapter Overview This chapter gives background information on the PPC-415 TGL panel PC. Sections Include: Introduction Specifications Dimensions... -
Page 10: Introduction
Introduction PPC-415 TGL is a new generation XGA (1024 x 768) panel PC. It is based on the 11th. Gen Intel Core processor and adopts an effective fanless thermal solution, fea- turing excellent performance and reliability, for this product series. PPC-415 TGL offers multiple I/O, including 3 COMs, 4 USBs, and dual 2.5Giga Ethernet ports,... -
Page 11: Power Specifications
CB, CCC, UL, BSMI 1.2.6 IP Grade Front Panel Dustproof IP66 and Waterproof Note 1: Power consumption of PPC-415 TGL is shown below: Test Software Test Configuration Test System Memory: 8G DDR4 2133 Burn-in 7.0 HDD: 2.5" 500G SATA III Win 10 (64bit) I/O: COM Port RS232 loopback x 2, USB 3.0 x 4... -
Page 12: Dimensions
Dimensions PPC-415 TGL User Manual... - Page 13 Note! Screw specification: M4; hole depth is 8 mm for maximum. Use suitable mounting apparatus to avoid risk of injury. PPC-415 TGL User Manual...
- Page 14 PPC-415 TGL User Manual...
-
Page 15: Chapter 2 System Installation And Setup
Chapter System Installation and Setup Sections Include: Quick Tour Installation Procedures Replacing Memory Installing HDD Installing M.2 Installing Wireless LAN Installing Expansion Card Adjusting AT/ATX Functions Grounding Installing Hooks Single Person Quick Installation Guide... -
Page 16: A Quick Tour
Power status LED: Off (S5) Orange; Sleep (S3) Orange; On (S0) Blue. Figure 2.2: Side View 1. Antenna hole 4. Expansion slot for optional module 2. Quick installation clip 5. Speaker (left, right) 3. CPU heatsink 6. Hooking holes for panel installation (ten holes) I/O connectors: PPC-415 TGL User Manual... - Page 17 G. 2 x RS-232 B. Line-out/Mic-in H. DC power connector (9-32V) C. 4 x USB 3.2 I. 1 x RS-422/485 D. 2 x 2.5G Ethernet ports J. Power switch E. HDMI K. Grounding screw F. DP PPC-415 TGL User Manual...
-
Page 18: Installation Procedures
2.3, C, USB. 2.2.3 Switching on the Panel PC Power switch is located at the lower right corner of the rear cover. Refer to Figure 2.3, J, Power switch. Note! Power cord and adapter are optional. PPC-415 TGL User Manual... -
Page 19: Installing Memory
Take out the thermal PADs for the CPU and memory from the accessory box. Please note the labels of the bags of the memory thermal PADs. Open the back cover and heat sink and install CPU thermal. Install the memory PAD of No.1 directly beneath the memory slot. PPC-415 TGL User Manual... -
Page 20: Installing One Memory
2.3.1 Installing One Memory Install one memory. Install thermal PAD No. 2 above the memory and then install the heat sink. PPC-415 TGL User Manual... -
Page 21: Installing Two Memories
2.3.2 Installing Two Memories Install the first memory. Install the No. 2 thermal PAD on the back of the second memory (identified by the notch position of the memory). PPC-415 TGL User Manual... - Page 22 Install the second memory. Install thermal PAD No. 3 above the two memories and then install the heat sink. PPC-415 TGL User Manual...
-
Page 23: Installing Hdd
VESA holder below left, then take out the HDD bracket below right. Take out 4 screws (see below) from the accessory box to secure the HDD onto the bracket, then replace and fix the HDD bracket. PPC-415 TGL User Manual... -
Page 24: Installing M.2
Follow the procedures in Chapter 2.3 and 2.4 to remove rear cover and VESA holder. Unfasten the screws marked with red circles and remove the heatsink. Fix M.2 card to the location marked with a rectangle. PPC-415 TGL User Manual... - Page 25 Add thermal PAD of M.2 card. Then use screws to install the heatsink on the motherboard. PPC-415 TGL User Manual...
-
Page 26: Installing Wireless Lan Card
Installing Wireless LAN Card Follow the procedures in Chapter 2.3, 2.4 and 2,5 to remove rear cover VESA holder and heatsink. Then fix the card to the location with a rectangle. PPC-415 TGL User Manual... - Page 27 Connect the Wi-Fi cable and add the thermal Pad for the Wi-Fi card. Then use screws to install the heatsink on the motherboard and VESA holder. Remove two plugs on the rear cover as shown below. PPC-415 TGL User Manual...
- Page 28 Then replace the rear cover and install the antenna of wireless LAN card mod- ule. PPC-415 TGL User Manual...
-
Page 29: Installing Wireless Lan Card And 5G Card
Then fix the card to the location with a rectangle. Fix the antenna to the bracket (bracket PN is 1960104428N001, need to pur- chase separately). (The right rectangle is antenna of 5G and left rectangle is antenna of Wi-Fi.) PPC-415 TGL User Manual... - Page 30 Connect the Wi-Fi&5G cable and add the thermal Pad for card. (Fix the cable with adhesive tape.) Then use screws to install the heatsink on the motherboard and VESA holder. Remove two plugs on the rear cover as shown below. PPC-415 TGL User Manual...
- Page 31 Then replace the rear cover. PPC-415 TGL User Manual...
- Page 32 Fix the antenna Bracket and connect the antenna. PPC-415 TGL User Manual...
-
Page 33: Installing Side Com/Gpio
Follow the procedures in Chapter 2.3, Chapter 2.4 and Chapter 2.5 to remove rear cover, VESA bracket and heatsink of card. Fetch materials from COM port module (Advantech PN: 98R3C31530E) as shown below. Assemble COM port module as shown below. Use two screws to fix the COM port module onto the system frame. -
Page 34: Installing Expansion Card
You can adjust AT or ATX function by the internal switch indicated by the red rectan- gle without removing the rear cover. 2.11 Grounding Grounding screw is marked with a red circle as below. It is recommended that prod- ucts with a capacitive screen should be properly grounded. PPC-415 TGL User Manual... -
Page 35: Cabinet Installation And Grounding
Install the PPC system into the cabinet. Figure 2.5 Cabinet Installation a. Connect the cabinet to the earth/ground. b. Embed null PPC system into the cabinet without any I/O cable and power. System wiring. PPC-415 TGL User Manual... - Page 36 AWG/ 0.75mm2 and connected to the earth of the building. Ensure that the voltage of the power source is correct before connecting the equipment to a power outlet. By means of a power cord connected to a socket- outlet with earthing connection. PPC-415 TGL User Manual...
-
Page 37: Installing Hook
2.12 Installing Hook Please refer to the figure below: PPC-415 TGL User Manual... -
Page 38: Solo Quick Installation
Unfasten the two screws at the bottom as shown below. See diagram below to place and push the panel PC into the opening on the wall, then the hook will secure the PC onto the wall. PPC-415 TGL User Manual... - Page 39 It is recommended that the panel inlaid depth should be less than 2mm (0.079”) according to "Quick Installation Guide". In other circumstances, it is recommended that the panel inlaid depth should be less than 3mm (0.118”). PPC-415 TGL User Manual...
- Page 40 PPC-415 TGL User Manual...
-
Page 41: Chapter 3 Jumper And Switch Settings
Chapter Jumper and Switch Settings Sections Include: Jumpers and Connectors External COM Port & DIO Switch and Pin Assignments... -
Page 42: Jumpers And Connectors
Jumpers and Connectors Connector Function CN26 GPIO CN22 COM Pin9 power selection CN35 Power button AT/ATX selection Clear CMOS CN19 COM4 CN20 COM5 Icon Clear CMOS (1-2) Normal * Default * (2-3) Clear CMOS PPC-415 TGL User Manual... - Page 43 CN22 COM1/2 RI type selection (1-3)/(2-4) P9/P10 COM1/COM2 RI Default * (3-5)/(4-6) P11/P12 COM1/COM2 5V (7-9)/(8-10) P13/P14 COM1/COM2 12V CN26 (on DB9 cable) Signal GPIO4 GPIO0 GPIO5 GPIO1 GPIO6 GPIO2 GPIO7 GPIO3 PPC-415 TGL User Manual...
-
Page 44: External Com Port Pin Assignments
COM3 RS-422/485 COM1-2: COM1/COM2 RING or 5V/12V output Pin9 is set as RI signal in COM port by default, and can be set as 5V/12V output by Jumper. 12V: Max. 200 mA; 5V: Max. 500 mA. PPC-415 TGL User Manual... - Page 45 BIOS. RS422 RS485 UART RS485 auto flow control COM5 supports RS485 auto flow control function When enabling the RS485 auto control function, it will automatically drive RTS# pin to logic high or low for flow control PPC-415 TGL User Manual...
- Page 46 PPC-415 TGL User Manual...
-
Page 47: Chapter 4 Software Setup
Chapter Software Setup Sections Include: Installing Drivers BIOS Setup Utility... -
Page 48: Installing Drivers
When you install the system for the first time, please install the corresponding drivers in advance to make sure all the functions run normally. Please select the drivers to be installed based on the OS you use. Please go to the Advantech official website to get the latest versions of the drivers: http://www.advantech.com.cn BIOS Setup Utility 4.2.1... -
Page 49: Com5 Mode (Rs422/485) Selection
4.2.2 COM5 Mode (RS422/485) Selection Select “NCT6126D Super I/O Configuration” under “Advanced” tab. Then choose "Serial Port3 Configuration" under “NCT6126D Super I/O Configu- ration” item. PPC-415 TGL User Manual... -
Page 50: Wake Up By Lan
Click “Serial Port3 Configuration” item to choose the operating mode of COM3. 4.2.3 Wake Up by LAN Select “PCH-IO Configuration” under "Chipset" tab. PPC-415 TGL User Manual... - Page 51 Set ”PCIE Wake“ as “Enable”. Save all the settings and exit. Then enter the OS. Right-click on “Computer” and select “Manage" to pop up “Computer Manage- ment” window. PPC-415 TGL User Manual...
- Page 52 Click “Device Manager” to select “Network adapters”. Then right-click on the LAN port you want to use and select “Properties” to pop up “Intel(R) Ethemet” window. PPC-415 TGL User Manual...
- Page 53 In “Intel(R) Ethemet Controller I225-LM Properties” window, go to "Power Man- agement" tab and check the boxes of "Allow the computer to turn off this device to save power" and "Allow this device to wake the computer”. PPC-415 TGL User Manual...
- Page 54 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2022...
