- Page 1 User Manual PPC-4150W Intel® Atom D2550 processor based microcomputer, with 15.6" color TFT LCD display...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
-
Page 3: Declaration Of Conformity
This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information. -
Page 4: Safety Instructions
The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. -
Page 5: Battery Information
Battery Information Batteries, battery packs and accumulators should not be disposed of as unsorted household waste. Please use the public collection system to return, recycle, or treat them in compliance with the local regulations. PPC-4150W User Manual... - Page 6 PPC-4150W User Manual...
-
Page 7: Table Of Contents
Environment Specifications............3 1.2.6 Certification Specifications............4 1.2.7 IP ....................4 Dimensions ....................5 Figure 1.1 PPC-4150W dimensions ..........5 Chapter System Installation & Setup ....7 Quick Start Guide..................8 Figure 2.1 Front panel ..............8 Figure 2.2 Side view ..............8 Figure 2.3 Location of I/O interfaces.......... - Page 8 BIOS Setup ..................... 27 4.2.1 Enter BIOS.................. 27 4.2.2 Display Brightness Adjustment ........... 28 4.2.3 COM2 Mode Selection (RS232/422/485) ........30 4.2.4 COM1 & COM2 Pin9 Function Selection........31 4.2.5 Wake Up by LAN ................ 32 PPC-4150W User Manual viii...
-
Page 9: Chapter 1 General Information
Chapter General Information This chapter gives background information on PPC-4150W panel Sections include: Introduction Specifications Dimensions... -
Page 10: Introduction
Introduction Advantech PPC-4150W are Intel Atom processor based panel PCs with 15.6" color LCD. Powerful D2550 and Intel NM10 chipset not only meet with most application requirements, but also ensure the operation reliability under all environments. Built-in Mini SATA interface can be used as backup HDD solution for OS bootup; Mini PCIe card interface supports various expansion cards (e.g. -
Page 11: General Specifications
0 ~ 50° C (32 ~ 122° F) Storage Temperature -20 ~ 60° C (-4 ~ 140° F) Relative Temperature 10 ~ 95% @ 40° C (non-condensing) Shock 10 G peak acceleration (11 msec duration) Vibration 5 ~ 500 Hz 1 G RMS PPC-4150W User Manual... -
Page 12: Certification Specifications
Safety CB, CCC, UL 1.2.7 IP Front Panel IP Grade IP65 Note 1: PPC-4150W's power test conditions are as follows: Test Test Configuration Test System Software Memory: Transcend DDR3 1333 SODIMM 4 GB x 1 Windows 7 32bit HDD: Seageat 500G 2.5” SATA II Burn-in 7.0... -
Page 13: Dimensions
Dimensions Figure 1.1 PPC-4150W dimensions Note! Supports VESA 100 x 100 mm; please use M4 screw, 6 mm depth (maximum). Use suitable mounting apparatus to avoid risk of injury. PPC-4150W User Manual... - Page 14 PPC-4150W User Manual...
-
Page 15: Chapter 2 System Installation & Setup
Chapter System Installation & Setup Sections include: Quick Installation Guide Inslation Procedures Install Memory Install HDD Install Mini SATA Install Wireless LAN Install Expansion Card AT/ATX Function Switch Grounding Installation Hook Installation ... -
Page 16: Quick Start Guide
When you place the panel PC upright on the desktop, its front panel appears as shown in Figure 2.1. Figure 2.1 Front panel I Key Home Key Power status indicator, off (S5): orange, on (S0): blue Figure 2.2 Side view PPC-4150W User Manual... -
Page 17: Figure 2.3 Location Of I/O Interfaces
G: DC power port (12 - 30 V) H: Power button I: Speaker J: Grounding screw (refer to Fig 2.4) K: PCI/PCIE x1 Expansion slot (refer to Fig 2.5) Figure 2.4 Grounding screw Figure 2.5 PCI expansion slot PPC-4150W User Manual... -
Page 18: Installation Procedures
Connect Keyboard and Mouse Connect the keyboard and mouse to panel PC’s I/O interfaces. 2.2.2.1 Power ON The power button is located in the right bottom side of the panel PC. Note! Power cable and adapter are optional. PPC-4150W User Manual... -
Page 19: Install Memory Card
The black and grey lumps as indicated in the red circle of Fig 2.12 are cooler pads, which must be removed by professional personnels to avoid improper use. Figure 2.11 Figure 2.12 Note! CPU cooler pad surface is isolated by anodization treatment to avoid static electricity (CPU contact side excluded). PPC-4150W User Manual... -
Page 20: Install Hdd
Lock the HDD bracket, and take out the HDD cable from the accessory box and connect it to the mainboard. (See Fig 2.16 ~ 2.18) Figure 2.13 Figure 2.14 Figure 2.16 Figure 2.15 Figure 2.17 Figure 2.18 PPC-4150W User Manual... -
Page 21: Install Mini Sata
The wirless LAN card can be installed to the locations as indi- cated in Fig 2.21 and 2.22; for the wireless short card, you need to take out one hexagonal screw from the accessory box to fix it. Figure 2.21 Figure 2.22 PPC-4150W User Manual... -
Page 22: Figure 2.23
Take down the two plugs in the left and right sides of the rear cover. (See Fig 2.26) Return the rear cover and install the antenna of the wireless LAN card module. (See Fig 2.27) Note! For wireless LAN card module, you can choose Advantech Product: (Part No. PPC-6150-WLANE). Figure 2.23 Figure 2.24 Figure 2.26 Figure 2.25... -
Page 23: Install The Riser Card
PCI riser card (PCM-938) is provided in the accessory box for additional use (See Fig 2.30). The installation of expansion card is shown as Fig 2.31 and Fig 2.32. Note! The maximum dimension of the expansion card is 167.65 mm x 106.7 Figure 2.28 Figure 2.29 PPC-4150W User Manual... -
Page 24: At/Atx Function Switch
Figure 2.30 Figure 2.31 Figure 2.32 AT/ATX Function Switch Switch is built in the machine, by which you can choose AT/ATX function without removing the rear cover. Figure 2.33 ATX mode Figure 2.34 AT mode PPC-4150W User Manual... -
Page 25: Grounding Installation
Loosen the screws, take down the plastic cover, plug in the grounding cable, and then fix the screws. (See Fig 2.35 ~ Fig 2.38) Figure 2.35 Figure 2.36 Figure 2.37 Figure 2.38 Note! The grounding cable is not provided in the accessory box. PPC-4150W User Manual... -
Page 26: Hook Installation
2.10 Hook Installation Please follow the figure below: PPC-4150W Panel Installation Guide Wallmount Installation Bracket Put the machine into the cabinet, and prepare wallmount installation bracket Put the plastic plug into the hook to hold the machine Screws Lock the screws and fix the machine Figure 2.39 Hook Installation... -
Page 27: Independent Quick Installation
Guide. Please follow the procedures below: Loosen the two screws at the bottom side, see the figure below. Push the machine into the opened wall gap, the spring hook will lock the machine into the wall. PPC-4150W User Manual... -
Page 28: Cradle Installation Description
For other situations, the recom- mended thickness is less than 6 mm (0.236”). 2.12 Cradle Installation Description Note! For the cradle, you can choose Advantech product (Part No. PPC- 4150W-STANDE). Please refer to the included description for the instal- lation method. PPC-4150W User Manual... -
Page 29: Jumper Configuration
Chapter Jumper Configuration Sections include: Jumper & Connectors Peripheral COM Port & DIO Switch and Pin Definitions... -
Page 30: Jumper & Connectors
Clear CMOS CN58 RS422 120 ohm resistor selection (COM2) Image Clear CMOS (1-3) Clear CMOS (3-5) Clear CMOS (Default) RS422 120 ohm resistor selection CN58 Image (COM2) (1-2) Break 120 ohm resistor (3-4) Add 120 ohm resistor PPC-4150W User Manual... -
Page 31: External Com Port & Dio Switch And Pin Definition
The operation mode can be either RS232/422/485, selected by BIOS. (For details, please refer to "COM2 Mode Selection" in "BIOS Configuration" chapter. Pin9 can be charged as COM1. DIO: Operation voltage 5 V. 8 bit parallel input and output port. Control signal is SMBUS. PPC-4150W User Manual... - Page 32 COM Port Pin Definition Port Function RS232 RS422 RS485 422_TXD- 485_Data- 422_TXD+ 485_Data+ 422_TXD+ 422_TXD- DIO Pin Definition Port Function GPIO0 GPIO1 GPIO2 GPIO3 GPIO4 GPIO5 GPIO6 GPIO7 PPC-4150W User Manual...
-
Page 33: Software Configuration
Chapter Software Configuration Sections include: Install Drivers BIOS Setup Program... -
Page 34: Install Divers
User manual: E-record of the user manual for this machine. Please follow the instructions to install the drivers. The drivers in the accompanied CD-ROM may not be the latest version, if needed, please find it at: http://www.advantech.com/ PPC-4150W User Manual... -
Page 35: Bios Setup
BIOS Setup 4.2.1 Enter BIOS Start the computer and press "Delete" key to enter BIOS. Press "F4" to save and exit after any configuration, or the configuration won't be saved in BIOS. PPC-4150W User Manual... -
Page 36: Display Brightness Adjustment
4.2.2 Display Brightness Adjustment Select “Host Bridge” under “Chipset”. Then select “Intel IGD Configuration”. PPC-4150W User Manual... - Page 37 Select “Brightness Manual Control” under “Brightness Control”, and there will be 6 options: Note! If you want to adjust brightness through AP in the OS, it will keep AP configuration mainly, and BIOS configuration will not be saved. PPC-4150W User Manual...
-
Page 38: Com2 Mode Selection (Rs232/422/485)
4.2.3 COM2 Mode Selection (RS232/422/485) Select “Super IO Configuration” under “Advanced”. Select “Serial Port 2 Configuration” and then select the operation mode of COM2 by "Serial Port2 Mode". PPC-4150W User Manual... -
Page 39: Com1 & Com2 Pin9 Function Selection
4.2.4 COM1 & COM2 Pin9 Function Selection Select “Super IO Configuration” under “Advanced”. Select the needed COM port (serial Port 1/2 Configuration), then select Pin9 function by “Serial Port1/2 Pin9 Select”. PPC-4150W User Manual... -
Page 40: Wake Up By Lan
4.2.5 Wake Up by LAN Select “ACPI Settings” under “Advanced”. Set “Power Saving” as “Disabled”, and set “Power On by PCIE Wake#” as “Enabled”. PPC-4150W User Manual... - Page 41 Then save the configuration and exit the OS. Right click “Computer” and click “Manage”, then open “Computer Management”. Click “Network adapters” in “Device Manage”, then right click and select the needed LAN port, then select “Properties” and open “Realtek PCIe GBE Family Controller Properties”. PPC-4150W User Manual...
- Page 42 Select “Realtek PCIe GBE Family Controller Properties” under “Power Manage- ment”, and check “Allow this device to wake the computer”. PPC-4150W User Manual...
- Page 43 PPC-4150W User Manual...
- Page 44 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2013...
