  • Page 1 User Manual PPC-3100/3120 Intel® Atom Processor Based Micro-Computer with a 10.4" / 12.1" Color TFT LCD...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.

  • Page 3: Declaration Of Conformity

    This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information.

  • Page 4: Safety Instructions

    The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
  • Page 5 Don't touch any components on the CPU card or other cards while the PC is on.  Disconnect power before making any configuration changes. The sudden rush of power as you connect a jumper or install a card may damage sensitive elec- tronic components. PPC-3100/3120 User Manual...
  • Page 6 PPC-3100/3120 User Manual...

  • Page 7: Table Of Contents

    Figure 2.21Removing Screws............. 23 Figure 2.22Removing Metal Cover ..........24 Figure 2.23Fixing Metal Cover............ 24 Figure 2.24Installing Riser Card ..........25 Figure 2.25Installing Card............25 Figure 2.26Fixing Rear Cover............. 26 Installing Hook..................27 Figure 2.27Installing Hook ............27 PPC-3100/3120 User Manual...
  • Page 8 Figure 4.1 Drivers in CD-ROM ..........38 BIOS Setup Program ................38 4.2.1 Entering BIOS Setup ..............38 4.2.2 Adjustment of LCD Brightness............ 39 4.2.3 COM2 Mode Selection (RS232/RS422/RS485) ......41 4.2.4 COM1&COM2 Pin9 Function Selection........42 4.2.5 Wake on LAN\................43 PPC-3100/3120 User Manual viii...

  • Page 9: Chapter 1 Overview

    Chapter Overview This chapter gives basic information of PPC-3100/3120. Sections include:  Introduction  Specifications  Dimensions...

  • Page 10: Introduction

    Introduction Advantech PPC-3100/3120 is an Intel Atom processor based panel PC with a 10.4" / 12.1" color LCD display. The powerful D2550 and Intel NM10 chipsets bring the most dynamic applications to life without sacrifices to any industrial reliability. The internal...

  • Page 11: General Specifications

    Note! For details about the above test conditions for power consumption, please see Remark 1 and Remark 2. 1.2.4 Touchscreen Specifications Type Five wire resistive Resolution 2048 x 2048 Light Transmission 81%+/-3% Controller COM interface Durability 36,000,000 PPC-3100/3120 User Manual...

  • Page 12: Environment Specifications

    Memory: Apacer DDR3 1333 SODIMM 4GBx1 Windows 7 32bit 36 W HDD: Seagate ST250LT003 9YG141C-500 Burn-in 7.0 250GB SATA 2.5' IO: COM Port RS232 loopback x4, USB2.0 Windows XP 32bit 34 W device x3, USB mouse x1 PPC-3100/3120 User Manual...

  • Page 13: Dimensions

    Dimensions PPC-3100: PPC-3100/3120 User Manual...

  • Page 14: Figure 1.1 Ppc-3100 Dimensions (Unit: Mm)

    Figure 1.1 PPC-3100 Dimensions (Unit: mm) Note! Specification of mounting VESA screw: M4. Depth of screw hole: 6 mm (Max.). PPC-3120: PPC-3100/3120 User Manual...

  • Page 15: Figure 1.2 Ppc-3120 Dimensions (Unit: Mm)

    Figure 1.2 PPC-3120 Dimensions (Unit: mm) Note! Specification of mounting VESA screw: M4. Depth of screw hole: 6 mm (Max.). PPC-3100/3120 User Manual...
  • Page 16 PPC-3100/3120 User Manual...

  • Page 17: Chapter 2 System Setup

    Chapter System Setup Sections include:  A Quick Tour  Installation Procedures  Installing Memory  Installing HDD  Installing Mini SATA  Installing Wireless LAN  Installing Expansion Card  Installing Hook  Quick Installation of PPC-3120  Installing Internal USB...

  • Page 18: A Quick Tour

    Network status indicator (LAN LED) HDD status indicator (HDD LED) Power status indicator (Power LED) LAN LED Status HDD LED POWER LED LAN1 LAN2 Green Yellow Yellow Power On (S0) (Operating, (Operating, (Operating, Green flashing) flashing) flashing) PPC-3100/3120 User Manual...

  • Page 19: Figure 2.2 Side View Of Panel Pc

    Figure 2.2 Side View of Panel PC Antenna hole CPU heatsink Hook hole for panel mount (8 holes) Speaker (left & right) PPC-3100/3120 User Manual...

  • Page 20: Figure 2.3 Io Connectors Of Panel Pc

    B: 2 x Gigabit Ethernet ports C: 4 x USB 2.0 connectors D: DIO connector E: VGA connector F: COM1, 3, 4 RS232 connector, COM2 RS232/422/485 connector G: DC power connector (12 V ~ 30 V) H: Power switch PPC-3100/3120 User Manual...

  • Page 21: Installation Procedures

    Connecting Keyboard and Mouse Connect the mouse and keyboard to the I/O connector of the panel PC. 2.2.3 Switching on Power The power switch is located at the lower right corner on the rear cover of the panel PPC-3100/3120 User Manual...

  • Page 22: Installing Memory

    Installing Memory Unfasten the screws on the rear cover (8 screws). Figure 2.5 Unfastening Screws on Rear Cover Unplug the switch wire from the main board and remove the rear cover. Figure 2.6 Unplugging Switch Wire PPC-3100/3120 User Manual...

  • Page 23: Figure 2.7 Unfastening Heatsink Screws

    Remove the heatsink and insert the memory into the right place (shown in red rectangle), and then stick the cooling mud onto it. Make sure the mud on CPU (in blue rectangle) is intact and replace the heatsink and the rear cover. Figure 2.8 Installing Memory and Cooling Mud PPC-3100/3120 User Manual...

  • Page 24: Installing Hdd

    Installing HDD Loosen the screws shown in red rectangle. Unplug the power cord and remove the rear cover. PPC-3100/3120 User Manual...

  • Page 25: Figure 2.9 Removing Rear Cover

    Figure 2.9 Removing Rear Cover Remove the green tape and unfasten the four screws to take off HDD bracket. Figure 2.10 Removing HDD Bracket PPC-3100/3120 User Manual...

  • Page 26: Figure 2.11Fastening Hdd Screws

    Figure 2.11 Fastening HDD Screws Replace the HDD bracket and plug the wire. Figure 2.12 Plugging HDD Wire Attach the power wire to the main board. Replace the rear cover and fix it to fin- ish the installation. PPC-3100/3120 User Manual...

  • Page 27: Figure 2.13Removing Hdd Bracket

    Follow the above procedures to remove the HDD bracket. Figure 2.13 Removing HDD Bracket Insert mSATA into the slot on the main board and use 2 M2.5x4 screws from the accessory box to fix it. Figure 2.14 Installing mSATA Then replace the rear cover. PPC-3100/3120 User Manual...

  • Page 28: Installing Wireless Lan Card

    LAN card can be directly installed to the position shown in the below figure, while the short one needs the support of a hex bolt (in accessory box) to be fixed into the position. Figure 2.15 Installing Wireless LAN Card PPC-3100/3120 User Manual...

  • Page 29: Figure 2.16Location Of Antenna

    Fix the antenna into the position as shown below (left & right). Figure 2.16 Location of Antenna Connect the antenna to the wireless LAN card and attach the external antenna terminals. Figure 2.17 Installing Antenna Replace the HDD bracket and the rear cover to finish the installation. PPC-3100/3120 User Manual...

  • Page 30: Installing Ppc-3120-Expe

    Installing PPC-3120-EXPE Take PPC-3120-EXPE module out of the box. Make sure you have correct riser card to be used. Take PCM-922B as an example. Figure 2.18 PPC-3120-EXPE Module Figure 2.19 PCM-922B: 1 PCIEx and PCI PPC-3100/3120 User Manual...

  • Page 31: Figure 2.20Pcm-923B: Pciex 1 And Pciex 1

    Figure 2.20 PCM-923B: PCIEx 1 and PCIEx 1 Remove the screws on the expansion card (7 screws). Figure 2.21 Removing Screws PPC-3100/3120 User Manual...

  • Page 32: Figure 2.22Removing Metal Cover

    Remove the screw that fixes the metal cover onto the back of PPC-3120, and then remove the cover. Figure 2.22 Removing Metal Cover Fix PPC-3120-EXPE onto the rear cover with screws (4 screws). Figure 2.23 Fixing Metal Cover PPC-3100/3120 User Manual...

  • Page 33: Figure 2.24Installing Riser Card

    Insert the desired card into the slot and use the screw to fix it. Card max size: L198 mm * W150 mm, component side height no more than 20 mm, the other side height no more than 5 mm. Figure 2.25 Installing Card PPC-3100/3120 User Manual...

  • Page 34: Figure 2.26Fixing Rear Cover

    Replace the rear cover of PPC-3120-EXPE and use the screws (7 screws) to fix Figure 2.26 Fixing Rear Cover PPC-3100/3120 User Manual...

  • Page 35: Installing Hook

    After the panel PC is installed in the cabinet, prepare the hook. Place the hook in the hole as the picture shows to hookup the panel PC. Screw Fasten the screw to fix the panel PC. Figure 2.27 Installing Hook PPC-3100/3120 User Manual...

  • Page 36: Quick Installation Of Ppc-3120

    Figure 2.28 Put Panel PC into Cabinet Use one hand to support the PC, while use the other hand to push the PC into the cabinet by pushing up the clamp with a tool. Figure 2.29 Installing PC with Clamp PPC-3100/3120 User Manual...

  • Page 37: Figure 2.30Installing Hook

    After the panel PC is attached onto the cabinet, use the hook to fix it. Figure 2.30 Installing Hook If you want to remove the panel PC, reverse the above steps. PPC-3100/3120 User Manual...

  • Page 38: Installing Internal Usb

    2.10 Installing Internal USB Take out the cable and USB bracket. Figure 2.31 Cable and USB Bracket Fix the bracket onto the USB connector with screws. Figure 2.32 Fixing Bracket onto USB Connector PPC-3100/3120 User Manual...

  • Page 39: Figure 2.33Removing Rear Cover

    Remove the rear cover. Figure 2.33 Removing Rear Cover Remove the IO shield. Figure 2.34 Removing IO Shield PPC-3100/3120 User Manual...

  • Page 40: Figure 2.35Connecting Cable

    Please adjust the cable in the lower left corner. Figure 2.35 Connecting Cable Replace the IO shield, then the internal USB connector is ready for use. Con- nect the device you want to this connector and replace the rear cover. Figure 2.36 Replacing IO Shield PPC-3100/3120 User Manual...

  • Page 41: Jumpers And Connectors

    Chapter Jumpers and Connectors Sections include:  Jumpers and Connectors  External COM Ports & DIO Pin Definition...
  • Page 42 LCD Size Selection Clear CMOS CN58 RS 422 120 Ω Resistor Selection (COM 2) CN15 Graphic LCD Size Selection (1-2) 12”LCD (PPC-3120) (3-4) 10”LCD (PPC-3100) Graphic Clear CMOS (1-3) P3 Clear CMOS (3-5) P4 Keep CMOS (default) PPC-3100/3120 User Manual...
  • Page 43 The mode can be RS232/422/485, which can be selected via BIOS (For details, please see “BIOS Setup” and “COM2 Mode Selection”.) You can make PIn9 with power like COM1. DIO: 5V tolerant I/Os. 8-bit parallel input/output port. Control signal is SMBUS. PPC-3100/3120 User Manual...
  • Page 44 COM PORT PIN Definition Connector Function RS232 RS422 RS485 422_TXD- 485_Data- 422_TXD+ 485_Data+ 422_RXD+ 422_RXD- DIO PIN Definition Connector Function GPIO0 GPIO1 GPIO2 GPIO3 GPIO4 GPIO5 GPIO6 GPIO7 PPC-3100/3120 User Manual...

  • Page 45: Software Setup

    Chapter Software Setup Sections include:  Driver Installation  BIOS Setup Program...

  • Page 46: Driver Installation

    User manual: Digital copy of the PC's user manual. Please complete the installation based on the operating system you use. The drivers in CD-ROM may not be the latest version, please get the latest ones from the below websites: http://www.advantech.com.cn/ PPC-3100/3120 User Manual...

  • Page 47: Bios Setup Program

    Entering BIOS Setup When the power is turned on, press <Del> button to enter BIOS setup screen. Whenever any setting is made, press <F4> to save and exit; otherwise the settings will not be saved in BIOS. PPC-3100/3120 User Manual...

  • Page 48: Adjustment Of Lcd Brightness

    4.2.2 Adjustment of LCD Brightness Select “Host Bridge” in “Chipset” tab. Then select “Intel IGD Configuration”. PPC-3100/3120 User Manual...
  • Page 49 Select “Brightness Manual Control” under “Brightness Control”. There are in all six brightness levels to choose. B. Dynamic Mode “LCD Brightness Control” is set to “Dynamic Mode”, which means LCD will automat- ically sense the light and adjust the brightness accordingly. PPC-3100/3120 User Manual...

  • Page 50: Com2 Mode Selection (Rs232/Rs422/Rs485)

    4.2.3 COM2 Mode Selection (RS232/RS422/RS485) Select “Super IO Configuration” in “Advanced” tab. Select “Serial Port 2 Configuration”. You can select the mode of COM2 through “Serial Port2 Mode”. PPC-3100/3120 User Manual...

  • Page 51: Com1&Com2 Pin9 Function Selection

    4.2.4 COM1&COM2 Pin9 Function Selection Select “Super IO Configuration” in “Advanced” tab. Select the desired COM port (Serial Port 1/2 Configuration) and select the func- tion of Pin 9 through “Serial Port1/2 Pin9 Select”. PPC-3100/3120 User Manual...

  • Page 52: Wake On Lan

    4.2.5 Wake on LAN\ A. Open wake on LAN function in windows 7. Select “ACPI Settings” in “Advanced” tab. Set “Power Saving” to “Disabled” and set “Power On by PCIE Wake#” to “Enabled”. PPC-3100/3120 User Manual...
  • Page 53 Save the settings and exit OS. Right-click “Computer” to select “Manage” to open “Computer Management” window. Click “Device Manager” and select “Network adapters”. Right-click the desired LAN port and select “Properties” to open “Realtek PCIe GBE Family Controller Properties” window. PPC-3100/3120 User Manual...
  • Page 54 Select “Power Management” tab in “Realtek PCIe GBE Family Controller Prop- erties" window, then check “Allow this device to wake the computer”. B. Open wake on LAN function in windows XP. Right click “Computer” and select “Manage” to enter management interface. PPC-3100/3120 User Manual...
  • Page 55 Select “Network adapters”, and two network devices will appear. Select any device with wake on LAN function, and right click to select “Properties”. Select “Power Management”, and remember to check “Wake on Magic Packet” and “Wake on Magic Packet from power off state”. PPC-3100/3120 User Manual...
