  • Page 1 User Manual PPC-310/312/315/321W 10.4’’/12.1’’/15’’/21.5” Fanless Panel ® ® PC with Intel Celeron J6412 Processor...
  • Page 2 No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable.
  • Page 3 (ESD) or electromagnetic interference (EMI) leakage, we strongly recommend using CE-compliant industrial enclosure products. Technical Support and Assistance Visit the Advantech website at http://support.advantech.com to obtain the latest product information. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information to hand before calling: –...
  • Page 4 Assurez-vous que la tension de la source d’alimentation est correcte avant de connecter l’appareil à une prise de courant. La prise de courant doit avoir une bonne connexion mise à la terre. Position the power cord away from high-traffic areas. Do not place anything over the power cord.
  • Page 5 AVERTISSEMENT: Ces instructions sont fournies conformément aux normes IEC 704-1. Advantech decline toute responsabilité quant à la précision de toute déclaration contenue dans le présent document. Do not expose the equipment to direct sunlight, or install the equipment in an environment with direct sunlight, as this may cause damage.
  • Page 6 Manual Conventions Warning! Warnings indicate conditions that, if not observed, can cause personal injury! Caution! Cautions are included to prevent hardware damage and data loss. For example, “Batteries are at risk of exploding if replaced with an incor- rect type. Replace only with the same or equivalent type recommended by the manufacturer.
  • Page 7 Dimensions ....................4 Figure 1.4 PPC-310 EHL Dimensions ......... 4 Figure 1.5 PPC-312 EHL Dimensions ......... 4 Figure 1.6 PPC-315 EHL Dimensions ......... 5 Figure 1.7 PPC-321W EHL Dimensions........5 Specifications .................... 6 Table 1.1: Specifications ............. 6 Ordering Information ................. 8 Table 1.2: Ordering Information...........
  • Page 8 Figure 2.23 System Wiring Cabinet..........22 Chapter Jumper Settings........ 23 Motherboard Jumpers and Connectors ..........24 Figure 3.1 Motherboard ............. 24 Table 3.1: Motherboard Jumpers and Connectors....24 3.1.1 COM1 Pin 9 Power Select ............25 Table 3.2: COM1 Pin 9 Power Select........25 3.1.2 RTC Select .................
  • Page 9 Chapter General Information This chapter details general infor- mation regarding PPC-310/312/ 315/321W EHL.  Introduction  Specifications  Dimensions...
  • Page 10 Introduction The Advantech PPC-310/312/315/321W EHL is an all-in-one light panel PC with a ® wide format 10.4"/12.1"/15"/21.5" TFT LCD screen. It is powered by an Intel Cele- ® J6412 processor, PPC-310/312/315/321W EHL to provide good performance, optimal memory, graphics, and peripheral I/O support in a compact, fanless, embed- ded system.
  • Page 11 Rear Panel The PPC-310/312/315/321W EHL rear panel features four VESA mount holes located on its bottom side. Figure 1.2 Rear Panel Panel Bottoms The system’s I/O, located on the bottom of the device, (Figures 1.3) are listed below: 1 x Power input connector ...
  • Page 12 Dimensions Figure 1.4 PPC-310 EHL Dimensions Figure 1.5 PPC-312 EHL Dimensions PPC-310/312/315/321W EHLUser Manual...
  • Page 13 Figure 1.6 PPC-315 EHL Dimensions Figure 1.7 PPC-321W EHL Dimensions PPC-310/312/315/321W EHL User Manual...
  • Page 14 Specifications Table 1.1: Specifications PPC-310- PPC-310- PPC-312- PPC-312- PPC-315- PPC-315- PPC-321W- RJ60A PJ60A RJ60A PJ60A RJ60A PJ60A PJ60A LCD Size 10.4’’ 10.4’’ 12.1’’ 12.1” 15’’ 15” 21.5” Display Type TFT LCD TFT LCD TFT LCD TFT LCD TFT LCD TFT LCD TFT LCD Resolution 1024 x 768...
  • Page 15 Storage -20 ~ 60°C (-4 ~ 140°F) Temperature Relative 10 ~ 95% @ 40°C/104°F (non-condensing) Humidity Shock Operating 10G peak acceleration (11 ms duration), following IEC 60068-2-27 Tolerance Vibration Operating random vibration test, 5 ~ 500 Hz, 2 Grms with SSD, in accordance with IEC 60068-2-64 Tolerance Safety and Safety: CB, UL, CCC, BSMI, UKCA...
  • Page 16 Ordering Information Table 1.2: Ordering Information Part Number Description Image PPC-310-PJ60A PPC-310-RJ60A PPC-312-PJ60A ® ® PPC-312-RJ60A Panel PC with Intel Celeron J6412 PPC-315-PJ60A PPC-315-RJ60A PPC-321W-PJ60A 96PSA-A90W19OT-3 Power adapter 100 ~ 240 V , 90 W, 19V PPC-WLAN-D2 Wi-Fi module with antenna PPC-ARM-A03 Arm mount VESA standard PPC-174T-WL-MTE...
  • Page 17 Chapter System Installation and Setup  Quick System Tour  Memory Card Installation  SSD Installation  M.2 Installation  Wireless LAN Card Installation  Mounting the System...
  • Page 18 Quick System Tour Before setting up the panel PC, take a moment to identify the locations of the device controls, drives, connectors, and ports (as shown in Figure 2.3). When placed upright, the PPC-310/312/315/321W front panel should appear as shown in Figure 2.1.
  • Page 19 Figure 2.3 Panel PC Bottom With I/O A: Power button B: DC-In C: 2 x USB 2.0 D: 2 x USB 3.1 E: 1x Type-C F: 1x HDMI 1.4 G: 2 x RJ-45 LAN H: COM2 (RS-232/422/485) I: COM1 (RS-232) Installation Procedures When installing system hardware, adhere to the following order: Install the memory card...
  • Page 20 2.2.1 Memory Card Installation Remove 8 screws show in the circle, then remove the rear cover. Figure 2.4 Retention Screws on Rear Cover Insert the memory card into the corresponding slot on the main board, then place the thermal pad provided in the accessory box on top of the memory card and CPU.
  • Page 21 2.2.2 SSD Installation Remove the screws followed by the panel of the rear cover. Fetch materials from the SSD bracket module (requires order the SSD bracket module 98R3P300020). Figure 2.6 SSD Module Bracket Connect the SATA cable provided in the accessory box to the SATA SSD mod- Figure 2.7 SATA Cable Connected to SATA SSD Using the four screws provided in the accessory box, affix the SATA SSD mod- ule to the SSD bracket.
  • Page 22 Affix the SATA SSD bracket to the main board. Tie the SATA power cable in place and then plug the cable into the corresponding connector on the mother- board. Pay attention and ensure that the rear cover SSD cable is not receiving pres- sure.
  • Page 23 Take out the thermal pad from the accessory box, and place it on top of the M.2 SSD card. Figure 2.11 Stick Thermal Pad on M.2 2.2.3.2 M.2 2242 Card Installation First, fetch a pillar from the accessory box and install it on the motherboard as shown figure.
  • Page 24 Insert M.2 2242 card on motherboard with a screw. Figure 2.13 Assemble Pillar on Motherboard Take out the thermal pad from the accessory box, and stick it on the M.2 card. Note: The half size of an M.2 2280 thermal pad can be used as an M.2 2242 thermal pad.
  • Page 25 2.2.4 Install Wi-Fi Module Remove rear cover. Assemble antenna bracket on antenna cable. Figure 2.15 Assemble Bracket with Antenna Cable Attach the Wi-Fi card and stick on the thermal pad. Figure 2.16 Attach Wi-Fi Card PPC-310/312/315/321W EHL User Manual...
  • Page 26 Attach the rear cover and install the antenna. Figure 2.17 Assemble WiFi Antenna 2.2.5 System Power on A 2-pin power connector is included in the accessory box. Connect the power con- nector to 12-30VDC power lines and plug the power lines into the system power receptor.
  • Page 27 Mounting the System Warning! When mounting the panel PC, more than one person should perform the installation to prevent accidental damage to the panel or personal injury. Le comité constate qu’el-nasr “ mounting, Plus d’une personne installa- tion to prevent the cadre accidental damage to the personal injury. The panel PC supports various mounting options, as listed below.
  • Page 28 Insert the hook brackets into the holes following the direction of the arrows shown in Figure 2.25 and hang the panel PC. Pull outward Figure 2.19 Hook Brackets Location Tighten the screws to secure the panel PC in place (Figure 2.26). Figure 2.20 Fasten the Hook Bracket Figure 2.21 Panel Mount Rear View (Take PPC-321W drawing as example)
  • Page 29 2.3.2 VESA Mounting If you install the Stand Kit/Wall mount Kit/Arm mount Kit of different specifications, choose the appropriate screw length according to the different plate thickness at the VESA. The suggestions are as follows: Note! Recommended screw thread depth "A" shall be more than 11.5mm. 2.3.3 Cabinet Installation and Grounding Follow these instructions to install the PPC system, and pay attention to the ground...
  • Page 30 System wiring. Figure 2.23 System Wiring Cabinet Step A: Connect the cabinet to the earth/ground. Step B: Ensure that all cabinets have been grounded together. Step C: Connect the ground of the power supply to the cabinet. Step D: Connect the ground pin of PPC system to the cabinet. Step E: Connect the I/O to the controller if needed.
  • Page 31 Chapter Jumper Settings  Jumpers and Connectors  External COM Ports and Pin Definitions...
  • Page 32 Motherboard Jumpers and Connectors Motherboard connectors are highlighted below (Figure 3.1). The internal peripheral connectors are accessible when the motherboard is outside of the chassis. M2E1 NGFF1 JCMOS1 CN11 Figure 3.1 Motherboard The internal jumpers and connectors on the motherboard and their pinouts are listed in the table below.
  • Page 33 3.1.1 COM1 Pin 9 Power Select Table 3.2: COM1 Pin 9 Power Select Function 1-2 pin COM1 RI (Default*) 2-3 pin COM1 Pin-9 5V 4-5 pin COM1 Pin-9 12V 3.1.2 RTC Select Table 3.3: RTC Select JCMOS1 Function Pins 1-2 CLR RTC Register Pins 2-3 Normal (Default*)
  • Page 34 3.1.4 Touch Power Select Table 3.5: Touch Power Select Function Open Closed 3.1.5 Power Button Connection Table 3.6: Power Button Connection CN11 Function Power button Can be used as an external extension line switch ATX_PWRBTN# Note! Resistive touch model JP3 need add jumper, Projected capacitive touch model JP3 need pull off jumper.
  • Page 35 External COM Ports and Pin Definitions Figure 3.2 Location of COM1 and COM2 Ports COM1: RS-232 COM1 Pin 9 is set as “RI” by default. This setting can be changed to 5V or 12V output using a jumper. COM2: RS-232/422/485 Note! COM2 does not support ring function.
  • Page 36 PPC-310/312/315/321W EHL User Manual...
  • Page 37 Chapter Software Setup  Driver Installation  BIOS Setup Program...
  • Page 38 Driver Installation Before installing software on the panel PC, install the corresponding drivers to ensure full functionality. All drivers can be downloaded from the Advantech website: http://www.advantech.com BIOS Setup Utility 4.2.1 Main Setup You can enter the BIOS setup utility by pressing "Delete".
  • Page 39 4.2.2 Advanced BIOS Features Setup Following is COM2 Mode Selection (RS232/RS422/RS485): Select NCT6126D Super IO Configuration in the Advanced tab. Select Serial Port 2 Configuration option. PPC-310/312/315/321W EHL User Manual...
  • Page 40 Select Serial Port 2 Mode option to set the COM2 operation mode as RS232, RS422, or RS485. If COM2 mode is set as RS485, the RS485 Auto Flow control option can be Enabled or Disabled. PPC-310/312/315/321W EHL User Manual...
  • Page 41 4.2.3 Chipset Configuration Following is Wake-on-LAN: Select PCH-IO Configuration option in the Chipset tab. Set the Wake On By option to Enabled. PPC-310/312/315/321W EHL User Manual...
  • Page 42 4.2.4 Security Set Administrator Password  PPC-310/312/315/321W EHL User Manual...
  • Page 43 4.2.5 Boot Setup Prompt Timeout  This item allows users to set the number of seconds to wait for the setup activa- tion key. 65535 (oxFFFF) means indefinite waiting. Bootup NumLock State  This item allows users to select the keyboard NumLock state. Quiet Boot ...
  • Page 44 4.2.6 Save & Exit Save Charges and Exit  This item allows users to exit the system setup after saving changes. Discard Changes and Exit  This item allows users to exit the system setup without saving changes. Save Changes and Reset ...
