Universal Repeater
Note: The Wireless LAN settings will be changed according to the Operation Mode
selected here. For the detailed information, please refer to the section of Wireless LAN.
3 . 2 L A N
3 . 2 L A N
Local Area Network (LAN) is a group of subnets regulated and ruled by modem.
Click LAN to open the LAN settings page and choose General Setup.
Note: Such page will be changed according to the Operation Mode selected. The
following screen is obtained by choosing AP as the operation mode.
Available settings are explained as follows:
Item
LAN IP Network
Configuration
wireless bridge.
This product can act as a wireless range extender that will help
you to extend the networking wirelessly. The access point can
act as Station and AP at the same time. It can use Station
function to connect to a Root AP and use AP function to service
all wireless clients within its coverage.
Description
Enable DHCP Client – When it is enabled, VigorAP 910C will
be treated as a client and can be managed / controlled by AP
Management server offered by Vigor router (e.g., Vigor2860).
IP Address – Type in private IP address for connecting to a local
private network (Default: 192.168.1.2).
Subnet Mask – Type in an address code that determines the size
41
VigorAP 910C User's Guide
