Enable Limit Client
Mode
Hide SSID
SSID
Isolate Member
VLAN ID
Channel
Rate
Tx Power
Check the box to set the maximum number of wireless stations
which try to connect Internet through Vigor device. The
number you can set is from 3 to 64.
VigorAP 910C can connect to stations supporting 11a Only, 11n
Only (5G), Mixed (11a+11n) or Mixed (11an+11n+11ac).
Check it to prevent from wireless sniffing and make it harder
for unauthorized clients or STAs to join your wireless LAN.
Depending on the wireless utility, the user may only see the
44information except SSID or just cannot see any thing about
VigorAP 910C while site surveying. The system allows you to
set three sets of SSID for different usage.
Set a name for VigorAP 910C to be identified.
Check this box to make the wireless clients (stations) with the
same SSID not accessing for each other.
Type the value for such SSID. Packets transferred from such
SSID to LAN will be tagged with the number.
If your network uses VLANs, you can assign the SSID to a
VLAN on your network. Client devices that associate using the
SSID are grouped into this VLAN. The VLAN ID range is
from 3 to 4095. The VLAN ID is 0 by default, it means
disabling the VLAN function for the SSID.
Means the channel of frequency of the wireless LAN. You may
switch channel if the selected channel is under serious
interference. If you have no idea of choosing the frequency,
please select AutoSelect to let system determine for you.
If you choose 11a Only, such feature will be available for you
to set data transmission rate.
The default setting is the maximum (100%). Lower down the
value may degrade range and throughput of wireless.
