Channel Statistics
AP's MAC Address
AP's SSID
Select as Universal
Repeater
3 . 9 . 7 U n i v e r s
3 . 9 . 7 U n i v e r s
The access point can act as a wireless repeater; it can be Station and AP at the same time. It
can use Station function to connect to a Root AP and use AP function to serve all wireless
stations within its coverage.
Note: While using Universal Repeater mode, the access point will demodulate the
received signal. Please check if this signal is noise for the operating network, then have
the signal modulated and amplified again. The output power of this mode is the same as
that of WDS and normal AP mode.
Available settings are explained as follows:
Item
SSID
MAC Address
(Optional)
Channel
Security Mode
VigorAP 910C User's Guide
It displays the statistics for the channels used by APs.
If you want the found AP applying the WDS settings, please
type in the AP's MAC address.
To specify an AP to be applied with WDS settings, you can
specify MAC address or SSID for the AP. Here is the place
that you can type the SSID of the AP.
In Universal Repeater mode, WAN would work as station
mode and the wireless AP can be selected as a universal
repeater. Choose one of the wireless APs from the Scan list.
a l R e p e a t e r
a l R e p e a t e r
Description
Set the name of access point that VigorAP 910C wants to
connect to.
Type the MAC address of access point that VigorAP 910C
wants to connect to.
Means the channel of frequency of the wireless LAN. The
default channel is 11. You may switch channel if the selected
channel is under serious interference. If you have no idea of
choosing the frequency, please select AutoSelect to let system
determine for you.
There are several modes provided for you to choose. Each
126
