WMM Capable
Aifsn
CWMin/CWMax
Txop
ACM
AckPolicy
After finishing this web page configuration, please click OK to save the settings.
VigorAP 910C User's Guide
To apply WMM parameters for wireless data transmission,
please click the Enable radio button.
It controls how long the client waits for each data transmission.
Please specify the value ranging from 1 to 15. Such parameter
will influence the time delay for WMM accessing categories.
For the service of voice or video image, please set small value
for AC_VI and AC_VO categories For the service of e-mail or
web browsing, please set large value for AC_BE and AC_BK
categories.
CWMin means contention Window-Min and CWMax means
contention Window-Max. Please specify the value ranging from
1 to 15. Be aware that CWMax value must be greater than
CWMin or equals to CWMin value. Both values will influence
the time delay for WMM accessing categories. The difference
between AC_VI and AC_VO categories must be smaller;
however, the difference between AC_BE and AC_BK categories
must be greater.
It means transmission opportunity. For WMM categories of
AC_VI and AC_VO that need higher priorities in data
transmission, please set greater value for them to get highest
transmission opportunity. Specify the value ranging from 0 to
65535.
It is an abbreviation of Admission control Mandatory. It can
restrict stations from using specific category class if it is
checked.
Note: Vigor AP provides standard WMM configuration in the
web page. If you want to modify the parameters, please refer to
the Wi-Fi WMM standard specification.
"Uncheck" (default value) the box means the AP will answer the
response request while transmitting WMM packets through
wireless connection. It can assure that the peer must receive the
WMM packets.
"Check" the box means the AP will not answer any response
request for the transmitting packets. It will have better
performance with lower reliability.
