Draytek VigorAP 910C User Manual page 102

Extension Channel
Rate
PHY Mode
Security
Peer Mac Address
Packet-OVERDRIVE This feature can enhance the performance in data transmission
VigorAP 910C User's Guide
With 802.11n, there is one option to double the bandwidth per
channel. The available extension channel options will be varied
according to the Channel selected above. Configure the
extension channel you want.
If you choose 11g Only or 11b Only, such feature will be
available for you to set data transmission rate.
Display the PHY Mode specified for such device.
Select WEP, TKIP or AES as the encryption algorithm.
Four peer MAC addresses are allowed to be entered in this
page at one time.
about 40%* more (by checking Tx Burst). It is active only
when both sides of Access Point and Station (in wireless
client) invoke this function at the same time. That is, the
wireless client must support this feature and invoke the
function, too.
Note: Vigor N61 wireless adapter supports this function.
Therefore, you can use and install it into your PC for matching
with Packet-OVERDRIVE (refer to the following picture of
Vigor N61 wireless utility window, choose Enable for
TxBURST on the tab of Option).
92
