Certificate Management - Draytek VigorAP 910C User Manual

Authentication Client
Backup
Restore
After finishing this web page configuration, please click OK to save the settings.
3 . 1 2 . 2 C e r t i f i c
3 . 1 2 . 2 C e r t i f i c
When the local client and remote server are required to make certificate authentication (e.g.,
Radius EAP-TLS authentication) for wireless connection and avoiding the attack of MITM,
a trusted root certificate authority (Root CA) will be used to authenticate the digital
certificates offered by both ends.
However, the procedure of applying digital certificate from a trusted root certificate authority
is complicated and time-consuming. Therefore, Vigor AP offers a mechanism which allows
you to generate root CA to save time and provide convenience for general user. Later, such
root CA generated by DrayTek server can perform the issuing of local certificate.
Root CA can be deleted but not edited. If you want to modify the settings for a Root CA,
please delete the one and create another one by clicking Create Root CA.
Click Create Root CA to open the following page. Type in all the information that the
window request such as certifcate name (used for identifying different certificate), subject
alternative name type and relational settings for subject name.
VigorAP 910C User's Guide
Delete Selected – Delete the selected user profile (s).
Delete All – Delete all of the user profiles.
This internal RADIUS server of VigorAP 910C can be treated as
the external RADIUS server for other users. Specify the client IP
and secret key to make the wireless client choosing VigorAP
910C as its external RADUIS server.
Client IP – Type the IP address for the user to be authenticated
by VigorAP 910C when the user tries to use VigorAP 910C as
the external RADIUS server.
Secret Key – Type the password for the user to be authenticated
by VigorAP 910C while the user tries to use VigorAP 910C as
the external RADIUS server.
Confirm Secrete Key – Type the password again for
confirmation.
Configure
Delete Selected – Delete the selected client(s).
Delete All – Delete all of the clients.
Click it to store the settings (RADIUS configuration) on this
page as a file.
Click it to restore the settings (RADIUS configuration) from an
existed file.
a t e M a n a g e m e n t
a t e M a n a g e m e n t

Add – Make a new client with IP and secrete key
specified on the left boxes.

Cancel – Clear current settings for the client.
182
