Appendix

MIDI Message Types
Here is a table of some common MIDI Message types and their corresponding data formats. In Scene
and List modes, the Soleman uses Program Change or Note On messages by default. In Panel mode,
Control Change messages can also be used.
Macros can be used in any of the modes (Scene, List, or Panel) to allow for custom MIDI messages of
other types, such as pitch bend or SysEx messages.
Status Byte
Message Type
Hex
Note On 9n
Continuous
Controller (i.e.
Bn
Control
Change)
Program
Cn
Change
Pitch Bend En
SA165
Data Byte 0
Binary Hex Binary
1001nnnn kk 0kkkkkkk
1011nnnn cc 0ccccccc
1100nnnn pp 0ppppppp
1110nnnn ll 0lllllll
Soleman User's Guide
Data Byte 1
Hex Binary
vv 0vvvvvvv
vv 0vvvvvvv
- -
mm 0mmmmmmm
Description
This message is sent when a
note is depressed (start). k is
the key (note) number. v is the
velocity.
This message is sent when a
controller value changes.
Controllers include devices
such as pedals and levers.
Controller numbers 120-127
are reserved as "Channel Mode
Messages". c is the controller
number (0-119). v is the
controller value (0-127).
This message sent when the
patch number changes. p is the
new program number.
This message is sent to indicate
a change in the pitch bender
(wheel or lever, typically). The
pitch bender is measured by a
fourteen bit value. Center (no
pitch change) is 2000H.
Sensitivity is a function of the
transmitter. (llllll) are the least
significant 7 bits. (mmmmmm)
are the most significant 7 bits.
