MIDI Input Control
The Soleman supports a limited number of functions to be controlled via MIDI Input. MIDI messages
received either via the 5-pin DIN MIDI Input Jack or the USB-MIDI connection will have the same
result. This allows users to recall Scenes, Set Lists, or Panels via MIDI so that the Soleman can be
remotely controlled from external hardware or software. The following table describes the MIDI
Input function mapping:
MIDI Message Type
Program Change (PC)
Note On
Continuous Control (CC)
Continuous Control (CC)
Continuous Control (CC)
Continuous Control (CC)
*Continuous Control functions are available with Firmware Version 1.06 or later.
SA165
Data Value 0 Data Value 1
0-63 N/A
0-127 Any
102* 0, 1, 2
103* 0-127
104* 0-63
105* 0-63
Soleman User's Guide
Function
Recall Panels 0-63, respectively
Recall Scenes 0-127, respectively
Set Mode (0=Scene, 1=Set List, 2=Panel)
Recall Scenes 0-127, respectively
Recall Set Lists 0-63, respectively
Recall Panels 0-63, respectively
