Source Audio Soleman User Manual page 10

Scene Names
Each scene can be given a custom name. Scene names can be up to 32 characters in length, and the
LCD will scroll the name back and forth if the name exceeds the size of the display.
Scene names can be edited using the Edit Menu and also the
a b c d e f g h i j k l m n o p
Scene numbers can optionally be displayed in large digits for easier visual recognition. This option is
available in the Edit Menu. When large scene digits are displayed, only 13 characters of the Scene
name are displayed at any time.
a b c d e f g h i j k l m
Scene Mode Expression Pedal Usage
For each scene, the expression output can be assigned to a different MIDI continuous controller. This
makes it possible to control different parameters on the target MIDI hardware or software
depending on what scene is active. To modify the expression output for the active scene, use the edit
menu (as shown in the graphic below) or the
Selection)
E x p
S c e n e
Scene MIDI Message Type
By default, when scenes are activated, they will output a MIDI program change (PC) message. The
program number will always match the scene number.
However, it is possible to choose other MIDI message types using the
Note On messages or Macros.
Scene MIDI Message Channel
By default, the MIDI program change message associated with a scene will be sent on the Global
Default MIDI Out Channel, which can be modified in the Edit Menu.
It is possible, however, to define custom MIDI messages that use different channels on a scene-by-
scene basis using the
SA165
M I D I
1 2 7 :
USB Editor Software.
Soleman User's Guide
USB Editor
USB Editor Software. (See
C C
C C
Software.
1 2 7
Scene/Panel Expression CC
1 1
USB Editor Software, such as
10
