Source Audio Soundblox Multiwave Distortion User Manual

QUICK stArt

1. PoWEr
To power the unit, insert 4 AA batteries (included) or connect a
Source Audio SA150 9 Volt DC power supply to the 9V DC jack
Note: Power supply must be REGULATED , minimum 200mA, and use a
negative tip plug. Use of a non-Source Audio power supply may cause
damage and void the warranty.
2. GUItAr/AUDIo ConnECtIons
Next, plug your guitar (or other instrument) into the jack labeled
GUITAR IN (B) via a standard ¼-inch cable. Connect your amp (or
other audio device) to the GUITAR OUT (C) jack, again with a standard
¼-inch cable. Both input and output are mono signals.
Note: The unit will not power up until a MONO ¼-inch plug is inserted into
the guitar input. This is to conserve power when the unit is running on bat-
teries. Don't forget to unplug the cable from the input when the unit is not in
use—otherwise the batteries will continue to drain.
3. sEnsor In (optional)
To use your Multiwave Distortion with a Hot Hand sensor: Connect
the sensor to the SENSOR IN (D) jack and follow any instructions
supplied with the sensor. The sensor input works with both wired and
wireless sensors.
4. BrIEF KnoB AnD PEDAl DEsCrIPtIons
(see Controls section for more details)
• SUSTAIN adjusts input gain to the front-end compressor
the amount of distortion gain applied to the signal.
• DRIVE
• OUTPUT adjusts the output level of the effect.
engages and disengages the effect.
• ON/OFF
D
B C
Controls
EFFECt
The effect knob selects which effect
type will be used. There are 21 effect
(A) .
positions around the knob as well
as a setting for CALIBRATE . For
information on the individual settings
see the next section. See the Use with
DrIVE
Hot Hand section for information on
The DRIVE control adjusts the gain
calibration.
of the signal going into the distortion
section. You probably don't want to
max out both SUSTAIN and DRIVE at
the same time, even for rock and roll.
sUstAIn
There is a compressor in front of the
distortion. The SUSTAIN knob adjusts
the input gain of the compressor,
oUtPUt
while the threshold remains fixed.
Adjusts the output level of the effect.
The compression ratio is 4:1, mean-
This is useful for setting the level of
ing that a 24 dB change in the input
the effect compared to the bypass
produces only a 6 dB change in the
signal. Note that because the effect
compressor output. The attack and
compresses the signal, the dynamic
release time constants are fairly
range of the distorted signal will be
quick. Increasing the SUSTAIN control
less compared to the dry signal. This
will result in a higher signal level
should be accounted for when setting
going to the distortion, even when
levels.
DRIVE remains fixed. Increasing the
amount of compression on the signal
on/oFF
effectively creates more sustain.
The ON/OFF switch engages or dis-
engages the effect. When the effect is
engaged, the ON/OFF LED will be lit.
The LED will be off in bypass mode.
The ON/OFF switch is also used to
start the calibration routine when the
EFFECT knob is set to CALIBRATE .
See the section on Use with Hot Hand
for more details.
A
EFFECts
oCtAVE 10-14
Settings 10 and 11 give the purest
octave effect. Settings 12 through
Here are some brief descriptions of
14 also have foldback and can get
the effects included in the Multiwave
pretty strange. Unlike classic octave
Distortion. The EFFECT knob settings
effects, chords can produce some
are split into two major categories:
useful results.
MULTI BAND and SINGLE BAND .
MULTI BAND settings use the band
splitting discussed in the feature
sInGlE BAnD
section and the SINGLE BAND set-
tings do not. Each main category
norMAl 15-16
contains 3 sub-categories: NORMAL ,
These two settings are fairly conven-
FOLDBACK , and OCTAVE . For each
tional distortion sounds.
sub-category, turning the effect knob
clockwise will tend produce more
FolDBACK 17-19
dramatic effects.
With the entire guitar signal pro-
cessed through a single foldback
distortion curve, there will be
MUltI BAnD
much more intermodulation-type
distortion produced.
norMAl 1-3
These three settings are best for
oCtAVE 20, 21
maximum clarity of the individual
20 is the purest single band octave
notes in a chord. These distortion
effect, and 21 includes some foldback.
curves are similar to standard
distortions.
FolDBACK 4-9
The foldback of the distortion curve
greatly increases the distortion
components for these settings. The
higher numbered effects have more
foldback creating even more distor-
tion. Big chords may not work well.
sPECIFICAtIons
Dimensions Power
• L : 7 inches • 110mA @ 9V DC (max 145mA
• W : 4 inches with Hot Hand Wireless Adapter)
• H : 2 inches (including knobs) • 15-20 hours battery life
• NEGATIVE tip power jack
Weight
• 1.25lbs Audio Performance
• 115dB DNR audio ADC
• 24-bit audio conversion
• 56-bit digital data path
• Analog bypass
troUBlEshootInG
Noise:
Low Power Change batteries or plug in a DC power supply.
Near noise source Move pedal away from power supplies and other
equipment.
Other equipment Remove other effects from signal chain,
see if noise persists.
Bad cables Swap out audio cables.
Low volume:
Low power Change batteries or plug in a DC power supply.
Hot Hand doesn't work:
Low power Change batteries or plug in a DC power supply.
Not calibrated properly Calibrate the Hot Hand (see Use with Hot Hand).
Not connected Check Hot Hand connections.
Knobs don't work /light up:
Low power Change batteries or plug in a DC power supply.
Wrong power supply Use correct power supply (see Quick Start).
Corroded input cable plug Check input cable plug for corrosion on sleeve,
swap out cable if necessary.
TRS (stereo) cable used Only use mono cable for input cable.
For additional assistance, please visit www.sourceaudio.net
