One common use case of panel mode is to use each individual footswitch to turn independent MIDI-
controllable effects on or off.
In Panel Mode, the LCD displays the Panel Name, Panel Number, and 3-character names for each of
the 4 footswitches:
Panel Name
P a n e l
D s t
Footswitch
1 Name
Basic Panel Operation
In Panel Mode, each footswitch is referred to simply by a number, 1 through 4. The footswitches are
configured to send customized MIDI messages when they are switched on or off. The LED
corresponding to each footswitch indicates if the footswitch is currently in the on state or the off
state.
Footswitches
Each of the 4 footswitches can be individually configured to have its own MIDI Message Type, On
Message, Off Message, Name, and Action. Footswitch 4 can alternately be used as a tap tempo input.
MIDI Message Type
Each footswitch is assigned a MIDI message type. The MIDI message can be set to Continuous
Controller, Program Change, Note On, Macro (user-defined message), System Real-time Start, System
Real-time Stop, or System Real-time Continue messages
On Message
The On Message defines what MIDI data will be sent when the footswitch is put into the On state.
There may be one or two bytes of data required for the message, depending on the message type.
Message Type On Message
[Status Byte] [Data Byte 0]
Program Change Program number (0-127)
Note On/Off Note On number (0-127)
Continuous Control Continuous control number (0-127)
Macro None
System Real-time None
