The IP traffic has been divided into two IP subnets, 192.207.35.0 and
192.207.36.0. The subnets are internally routed by the Switch 3800.
The subnets are assigned different VLAN names, Finance and Personnel,
respectively. The remainder of the traffic belongs to the VLAN named
MyCompany. All ports are members of the VLAN MyCompany.
192.207.35.1
192.207.35.0
Finance
1 2
Figure 5-6 Protocol-based VLANs
Predefined Protocol Filters
The following protocol filters are predefined on the Switch 3800:
192.207.36.1
My Company
3
IP
IPX
NetBIOS
DECNet
Overview of Virtual LANs
192.207.36.0
Personnel
4
= IP traffic
= All other traffic
