USB MASS STORAGE
USB ADDRESS NUMBER
USB INTERFACE 2
PRINT MODE
AUTOFEED
CHARS / INCH
SPEED / QUALITY
PAPER WIDTH
Sharing mode from Mass Storage:
Disabled D = sharing mode disabled
Enabled = sharing mode enabled
Numerical address code for the univocal identiication of the USB device (in case of more
than a USB device connected with the same PC):
0 D 2 4
1 3 5
Sharing mode of the detected image (connect a PC via USB):
Disabled = sharing mode disabled
Enabled = after scanning, the BMP image of the ticket is sent to the PC through
the USB port.
= the printer is detected by the PC as a logic disk.
D
Mass Storage
After scanning, the BMP image of the ticket is stored into the "LAST
SCAN" drive together with a txt ile. browse the logical disk from your
PC.
Printing mode:
Normal D = enables printing in normal writing way
Reverse = enables printing rotated 180 degrees
Setting of the Carriage Return character:
CR disabled D = Carriage Return disabled
CR enabled = Carriage Return enabled
NOTE: The parameter is printed only with CUSTOM/POS emulation enabled.
Font selection:
A = 11 cpi, B = 15 cpi
A = 15 cpi, B = 20 cpi D
NOTES:
CPI = Characters Per Inch
Setting of printing speed and printing quality:
Normal
High Quality
High Speed D
Width of printing area:
72mm (70mm width)
74mm (72mm width)
76mm (74mm width)
78mm (76mm width)
80mm (78mm width)
D
82mm (80mm width)
6 8
7 9
