11.10 VeriPrint

Mass Storage / FTP Server
It is possible to conigure the default parameters for VeriPrint system by editing the "Scanner.cfg" ile on the device Flash
Drive. You can enter the Flash Drive by iles sharing from Mass Storage or by iles sharing from FTP Server connection
(see par.11.1).
In both cases, the relative parameter should be enabled during the coniguration process (see chapter 5).
After editing device's parameter, simply save the "Scanner.cfg" ile to make the modiies activated.
The "Scanner.cfg" ile is a coniguration ile that contains all the conigurable parameters listed in text format and divided
into some sections (indicated in square brackets).
The available values for every parameter, are listed after the parameter name. The value marked with the symbol ' * ' is the
default one. To modify device's parameters, change the numeric value after the name of parameters. To set the parameter
to the default value, change the numeric value with the symbol D.
The "Scanner.cfg" ile permits the coniguration of the following parameters:
SCANHRES
SCANVRES
SAVETIMEMODE
BWTHRESHOLD
LASTHRES
LASTVRES
LASTBITPIX
LASTFILENAME
LASTCROP:
JOURHRES
JOURVRES
JOURBITPIX
88

setup

®
600*, 300
400*, 200
0, 1, 2*
0 ÷ 255 (150*)
SCANHRES, 300*, 200
SCANVRES, 300*, 200
8, 4*, 1
'image'*, 0, 1, 2
0*, 1
SCANHRES, 300, 200*
SCANVRES, 300, 200*
8, 4, 1*
scanner horizontal resolution
scanner vertical resolution
save time mode:
0 = after cut
1 = after motor off
2 = after cut or motor off
black/white threshold
bmp horizontal resolution saved in LASTSCAN disk
bmp vertical resolution saved in LASTSCAN disk
profondità colori del bmp salvato nel disco LAST IMAGE
bmp name saved in LASTSCAN disk:
'image' = <name of ile without extension, max 12 chars>
0 = no ile
1 = DDMMYYhhmmss.bmp
2 = YYMMDDhhmmss.bmp
crop of bmp saved in LASTSCAN disk:
0 = no crop
1 = crop
bmp horizontal resolution saved in SD/MMC CARD
bmp vertical resolution saved in SD/MMC CARD
colour depth of bmp saved in SD/MMC CARD
