3 INSTALLATION
3.1 Connections
The following igure shows the possible connections for the device.
ATTENTION:
In some using conditions, we recommend the installation of a ferrite core on the power supply cable.
ETHERNET
CrossOver
standard
cable
PC
Barcode reader
ETHERNET
standard
(pin-to-pin)
PC
Network
HUB
UTP
cable
PC
Barcode reader
USB
ETH
RS232
DK
VIn 24Vdc
Cash drawer
Power supply
Power
Supply cable
(included)
19
