AVIATION
USER MANUAL
KPM180H
TK180

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TK180 and is the answer not in the manual?

Questions and answers

Related Manuals for Custom Audio Electronics TK180

Summary of Contents for Custom Audio Electronics TK180

  • Page 1 AVIATION USER MANUAL KPM180H TK180...
  • Page 3 CUSTOM S.p.A. GENERAL SAFETY INFORMATION THE CE MARK AFFIXED TO THE PRODUCT CERTIFY THAT THE Via Berettine 2/B Your attention is drawn to the following actions PRODUCT SATISFIES THE BA- that could compromise the characteristics of the 43010 Fontevivo (PARMA) - Italy SIC SAFETY REQUIREMENTS.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS 1 INTRODUCTION ............. . 7 1.1 Document structure .
  • Page 6 6 MAINTENANCE ............. . 69 6.1 Printer paper jam .

  • Page 7: Introduction

    1 INTRODUCTION 1.1 Document structure This document includes the following chapters: 1 INTRODUCTION information about this document 2 DESCRIPTION general description of device 3 INSTALLATION information required for a correct installation of the device 4 OPERATION information required to make the device operative 5 ...

  • Page 9: Description

    2 DESCRIPTION 2.1 Box contents Remove the device from its carton being careful not to damage the packing material so that it may be re-used if the device is to be transported in the future. Make sure that all the components illustrated below are present and that there are no signs of damage. If there are, contact Customer Service.
  • Page 10 KPM180H (models with presenter) 1. Device 2. Installation instruction sheet 3. Reducer for paper width 4. External low paper sensor with cable...
  • Page 11 TK180 (metallic models) 1. Short guide 2. Device 3. AC adapter 4. Reducer for paper width 5. Serial cable 6. USB cable 7. External low paper sensor with cable...
  • Page 12 TK180 (plastic models) 1. Short guide 2. Device 3. AC adapter 4. Reducer for paper width 5. AC power cable •  Open the device packaging. •  Take out the device. •  Take out the rest of the content. •  Keep the box, trays and packing materials in the event the device must be transported/shipped in the future.

  • Page 13: Device Components: External Views

    2.2 Device components: external views KPM180H (standard models) 1. Device chassis 2. Device cover 3. Opening lever for device 1. Paper out 2. Status LED 3. LF LINE FEED key 4. FF FORM FEED key 5. Paper input 6. Adjustable cursor for paper in 7.
  • Page 14 KPM180H (models with presenter) 1. Device chassis 2. Device cover 3. Opening lever for device 4. Opening lever for presenter 5. Paper out 6. Status LED 7. LF LINE FEED key 8. FF FORM FEED key 9. Presenter chassis 10. Paper input 11.
  • Page 15 TK180 (metallic models) 1. Device chassis 2. Device cover 3. Paper out 4. Display 5. Paper input 6. Adjustable cursor for paper in 7. Keys and connectors panel (see following paragraphs)
  • Page 16 TK180 (plastic models) 1. Connectors cover 2. Display 3. Paper out 4. LF LINE FEED key 5. FF FORM FEED key 6. ON/OFF key 7. Device cover 8. Opening lever for device 9. Paper input 10. Adjustable cursor for paper in 11.

  • Page 17: Device Components: Keys And Connectors Panel

    2.3 Device components: keys and connectors panel Models without ETHERNET port 1. ON/OFF key (only for KPM180H and metallic TK180) 2. Connector for low paper sensor (external) 3. RS232 serial port (DB9) 4. USB port 5. Power supply port 6. Status LED 7.

  • Page 18: Device Components: Internal Views

    2.4 Device components: internal views KPM180H (standard models), TK180 1. Printing head with temperature sensor 2. Top mobile sensor for detecting black mark on the thermal side of paper or hole between tickets 3. Bottom mobile sensor for detecting black mark on the thermal side of paper or hole between tickets 4.
  • Page 19 KPM180H (models with presenter) 1. Printing head with temperature sensor 2. Top mobile sensor for detecting black mark on the thermal side of paper or hole between tickets 3. Bottom mobile sensor for detecting black mark on the thermal side of paper or hole between tickets 4.

  • Page 20: Product Labels

    2.5 Product labels PC = Product code (14 digits) SN = Serial number HW = Hardware release FW type = Firmware type product label firmware label E xx XXXXXXXXXXXXXX 0000000000000000000 FW type...

  • Page 21: Key Functions: Power Up

    2.6 Key functions: power up Models without ETHERNET port POWER UP Hold down Hold down printing printing SETUP report FONT TEST Fast push Fast push skip the enter the SETUP MODE SETUP MODE Fast push Fast push modify next selected parameter parameter...
  • Page 22 Models with ETHERNET port POWER UP Hold down Hold down printing printing SETUP report FONT TEST Fast push Fast push skip the enter the SETUP MODE SETUP MODE Fast push Fast push print the report and enter the enter the SETUP PROCEDURE SETUP PROCEDURE for ETHERNET parameters...

  • Page 23: Key Functions: Standby

    2.7 Key functions: standby STANDBY Fast push Hold down Fast push Advance the paper perform a (preset length) device reset Is the “Notch/B.Mark Position” parameter set on “Disabled”? (see Setup) printing perform the demo ticket ticket alignment...

  • Page 24: Status Messages

    2.8 Status messages The status LED indicates hardware status of device. Given in the table below are the various LED signals and the cor- responding device status. STATUS LED DESCRIPTION DEVICE OFF GREEN DEVICE ON: NO ERROR RECEIVE DATA RECEPTION ERRORS GREEN (PARITY, FRAME ERROR, OVERRUN ERROR) COMMUNICATION...

  • Page 25: Display Messages

    2.9 Display messages TK180 The display shows the emulation currently set, the irmware release and a device status message on the upper row. The lower row reports an error code (for example, ERR8) and the error description, in case of not successful outcome of commands (see following image). EMULATION FIRMWARE DEVICE STATUS RELEASE MESSAGE X.XX ONLINE ERRx <description>...

  • Page 27: Installation

    3 INSTALLATION 3.1 Fastening NOTE: All the dimensions shown in following igures are in millimetres. KPM180H (standard models) The device is provided with four ixing holes on the bottom of device (see following igure). To fasten the device on a panel,  use four M3 screws. 4 x M3 It's very important to consider the screws length not to damage the internal components placed near the ixing holes (see  following igure). Device chassis Fixing panel Section A-A Fixing screw The screw length (L) will be calculated according to the thickness of the panel (Sp) on which the device is ixed, as follows: L ≤ 10mm + Sp For example, if panel thickness is 10mm (Sp = 10mm), the maximum length for screws will be 20mm.
  • Page 28 KPM180H (models with presenter) The device is provided with six ixing holes on the bottom of device (see following igure). To fasten the device on a panel,  use six M3 screws. 32.5 6 x M3 Additionally, the panel must provide an opening for dust of paper that meets the following measures (in millimetres): min. 9...
  • Page 29 It is very important to consider the screws length not to damage the internal components placed near the ixing holes (see  following igure). Device chassis Device chassis Fixing panel Fixing panel Detail A Detail B Fixing screw Fixing screw The screw length (L) will be calculated according to the thickness of the panel (Sp) on which the device is ixed, as follows: L ≤ 5mm + Sp  (Detail A) L ≤ 10mm + Sp  (Detail B) For example, if panel thickness is 10mm (Sp = 10mm), The maximum screw length will be 15mm (detail A) or 20mm (detail B).
  • Page 30 TK180 (plastic models) The device is provided with two slots for the mounting of the machine on a panel. The slots are placed at the bottom of the machine (see following igure) 71.43 58.5...
  • Page 31 Additionally, the panel can provide an opening for the passage of the connection cables that meets the hole at the bottom of the device. The measures (in millimeters) of the opening are shown in the following igure: 58.5...

  • Page 32: Low Paper Sensor

    3.2 Low paper sensor KPM180H The device includes a low paper sensor with the cable (see following igure). To ix the sensor, use an M3 screw not supplied. MATERIAL NOT MATERIAL INCLUDED INCLUDED Low paper sensor Fixing screw M3 Low paper sensor board Connector Low paper wiring For the assembly procedure, proceed as follows: Low paper witing Spacer Low paper sensor Paper roll Low paper sensor board Support 1÷6 mm...
  • Page 33 Low paper wiring Connect the wiring coming from the low paper sensor board at the connector shown in figure.

  • Page 34: Connections

    3.3 Connections The following igure shows the possible connections for the device. Models without ETHERNET port RS232 POWER Serial standard cable (supplied with metallic TK180) Correctly insert the power supply connector (see following paragraphs) standard cable (supplied with metallic TK180) Power supply cable (supplied with TK180) Power supply serial device USB device ATTENTION: In some conditions, we recommend the installation of a ferrite core on the power supply cable.
  • Page 35 POWER Correctly insert the Serial cable power supply (for available connector (see serial cables, following paragraphs) see chapter 8) standard cable (supplied with metallic TK180) ETHERNET ETHERNET UTP Power supply CrossOver standard cable cable standard cable (pin-to-pin) (supplied with TK180)

  • Page 36: Pinout

    3.4 Pinout POWER SUPPLY Tripolar female connector 1 GND 2 +24 Vdc 3 GND 4 Frame GND ATTENTION: Respect power supply polarity. NOTE: Power supply cable The following igure shows the connector pinout of the power supply cable for the device: Tripolar male connector n.c. +24 V Power supply cable USB INTERFACE Female USB type B connector 1 USB0-VBUS (in) 2 USB0_D-...

  • Page 37: Rs232 Serial Interface

    Models without ETHERNET port RS232 SERIAL INTERFACE Female DB9 connector 1 DTR 2 TX During transmission, takes the values “0” and “1” depending on data. 3 RX During reception, takes the values “0” and “1” depending on data. 4 DSR 5 GND 6 DTR When “1”, device is power on.
  • Page 38 Models with ETHERNET port RS232 SERIAL INTERFACE Female RJ45 connector 1 DTR 2 TX (out) During transmission, takes the values “0” and “1” depending on data 3 RX (in) During reception, takes the values “0” and “1” depending on data 4 DR 5 GND 6 DT...

  • Page 39: Ethernet Interface

    ETHERNET INTERFACE Female RJ45 connector 1 RX +1 2 +3.3V ETH 3 RX -1 4 TX +1 5 +3.3V ETH 6 TX -1 7 n.c 8 GND 9 +3.3 V 10 LED-LNK 11 +3.3 V 12 LED-LAN 13 Shield 14 Shield NOTES: The functionality of two LED are speciied in the following tables: - For 10Base-T connection:...

  • Page 40: Driver And Sdk

    3.5 Driver and SDK The drivers are available for the following operating system: OPERATING DESCRIPTION INSTALLATION PROCEDURE SYSTEM Driver for Windows XP From the START menu, press Run Driver for Windows VISTA (32/64bit) and type-in the path where the SW Windows was saved on your PC, then click OK.

  • Page 41: Operation

    4 OPERATION 4.1 Opening cover KPM180H TK180 (plastic models) Push the release lever Push the release lever in the direction shown in the figure. in the direction shown in the figure. Open the Open the device cover. device cover.
  • Page 42 TK180 (metallic models) Open the metallic cover. Open the device cover. Push the opening lever shown in figure.

  • Page 43: Adjusting Paper Width

    4.2 Adjusting paper width Paper width may be adjusted from 25 mm to 82.5 mm by moving the adjustable cursor as shown in the following igure. 90° To manage paper width from 20 mm to 25 mm, apply the spacer on the mobile paper guide (see following igure), then  adjust the paper width. NOTE: For some models, only the internal printer group is represented.

  • Page 44: Adjusting The Alignment Sensors

    4.3 Adjusting the alignment sensors The device is equipped with two mobile sensors for the detection of the alignment black mark placed both on the thermal side and on the non-thermal side of paper as shown in the following igure. The user will need to manually move these mobile sensors according to the position and the type of the black mark on the paper (see next paragraphs).
  • Page 45 To adjust the mobile sensors position according to the black mark position and type on paper, open the device cover (see par.4.1) and move the sensors to the desired position using a small screwdriver or a pointed object. ATTENTION: To avoid damaging the sensor, use the plastic tabs as foothold for the screwdriver to push the sensor in the desired position.

  • Page 46: Switch The Device On

    4.4 Switch the device ON KPM180H Power supply cable (optional) EXTERNAL POWER SUPPLY UNIT (OPTIONAL) Connect the power supply cable to an external power supply unit (optional). IN DC 24V 1.6A Power supply cable (optional) Correctly insert the power supply connector with the flat side upwards Connect the power supply cable to the device.
  • Page 47 ON/OFF Switch device on pressing the ON/OFF key. The green leds (front and rear) turn on and the device is ready.
  • Page 48 TK180 (metallic models) IN DC 24V 1.6A Power supply (included) Correctly insert the power supply connector with the flat side upwards Connect the power adapter (supplied) to the device. Use the type of electrical power supply indicated on the label.
  • Page 49 X.XX ONLINE ON/OFF Accendere il dispositivo premendo il tasto ON/OFF. Il display si accende e visualizza il messaggio in figura. TK180 (plastic models) Rimuovere il coperchio del vano connettori facendolo scorrere nella direzione indicata.
  • Page 50 Inserire correttamente la ferrite del cavo alimentatore all’interno del vano connettori Alimentatore (in dotazione) Inserire corretta- mente il connettore alimentatore con il lato piatto verso Connettere l’alimentatore (in dotazione) al dispositivo posizionando il cavo come illustrato in figura. Utilizzate il tipo di alimentazione elettrica indicato sull’etichetta del dispositivo. Chiudere il vano connettori posizionando il coperchio precedentemente rimosso.
  • Page 51 Cavo di alimentazione in dotazione Collegare il cavo di alimentazione (in dotazione) all’alimentatore e alla presa di rete. X.XX ONLINE ON/OFF Accendere il dispositivo premendo il tasto ON/OFF. Il display si accende e visualizza il messaggio in figura.

  • Page 52: Loading The Paper Roll

    4.5 Loading the paper roll To change the paper proceed as follows. At every change of paper, check inside the device to locate and remove any scraps of paper. NOTE: For some models, only the internal printer group is represented. Close the device cover.
  • Page 53 thermal side ROOM thermal side ROOM Wait until the paper is automatically loaded.
  • Page 54 The following igure gives the limit positions of the paper roll related to the device for a correct paper loading without a  paper roll holder support. The direction of the paper will always form a maximum angle of 90 ° or -90 ° with the insertion plane of paper inside the device. 90° 90° Paper with thermal side on outside of roll -90°...

  • Page 55: Issuing Ticket (Models With Presenter)

    4.6 Issuing ticket (models with presenter) The device allows you to choose between different operating modes for the issuance of printed tickets. The operating modes shown in the following images, depend on the settings of the coniguration parameters and com- mands sent to the device. “EJECT” mode Paper input Printing head min 45° The device starts the ticket printing Cutter Ejector rollers min 45°...
  • Page 56 Ejector rollers Paper output Ticket ejected min 45° The device directly ejects the ticket...
  • Page 57 “CUT&HOLD” mode Printing head Paper input The device starts the ticket printing Ejector rollers Cutter When printing ends, the device cuts the ticket printed...
  • Page 58 Ticket presented Paper output Ejector rollers The device presents a portion of the ticket printed on the paper mouth Ticket withdrawn Paper output The user withdraw the ticket from the paper mouth...

  • Page 59: Configuration

    5 CONFIGURATION 5.1 Coniguration mode To enter the coniguration mode and print a SETUP report with the operating parameters of the device, proceed as follows. ON/OFF LF LINE FEED ON/OFF LF LINE FEED rear keys front keys While pressing the LF LINE FEED key, switch on the device by pressing the ON/OFF key. The device prints the report with the settings parameters. Follow the instruction printed on the paper or shown on display to proceed with configuration procedure.

  • Page 60: Setup Report

    5.2 Setup report The following igure shows the setup report of the device. The shown values for parameters are sample values; for the list  and the description of device parameters see the following paragraphs. DEVICE NAME and <device name>     -  rel  1.00 FIRMWARE MODULES SCODE. <code>      -  rel  1.00 DCODE. <code>  RELEASE     -  rel  1.00 FCODE.
  • Page 61 Models with ETHERNET port The following igure shows the setup report of the ETHERNET parameters. The shown values for parameters are sample  values; for the list and the description of device parameters see the following paragraphs. ETH. SPEED = 10Mb/s DHCP Client ....... : Disabled ETHERNET IP Address ........: 192.168. 0. 1 PARAMETERS Subnet Mask ......: 255.255.240. 0 Default Gateway ......: 192.168. 0. 5 MAC Address ......: 00-0E-E2-0A-D2-D0 [ LF ] to modify parameter KEYS FUNCTIONS...

  • Page 62: Device Status

    5.3 Device status The device operating status is indicated in the coniguration print-out in which, next to the name of the components dis- played, the following information is given: PRINTER TYPE device model PRINTING HEAD TYPE print head model INTERFACE interface present PROGRAM MEMORY TEST OK appears if functioning and NOT OK if faulty DYNAMIC RAM TEST OK appears if functioning and NOT OK if faulty EXTERNAL MEMORY TEST OK appears if functioning and NOT OK if faulty CUTTER TEST *...

  • Page 63: Printer Parameters

    5.4 Printer parameters The device allows the coniguration of the parameters listed in the following table. The parameters marked with the symbol are the default values. Settings remain active even after the device has been turned off and they are stored in non-volatile memory. PRINTER EMULATION Available emulations for the device: SERVICE = used only for upgrade = used for management of baggages ticket = used for management of boarding ticket...
  • Page 64 PROTOCOL STX Value of the start byte of protocol (up to three bytes, expressed in hexadecimal). NOTES: If '00' value is set, this parameter is disabled. This parameter is not available for irmware type. This parameter is not printed on Setup Report, because it is not modiiable during the Setup procedure. To  set this parameter, enter the Setup.ini ile (see par.11.3). PROTOCOL ETX Value of the end byte of protocol (up to three bytes, expressed in hexadecimal). NOTES: This parameter, unlike the STX, can not be disabled.
  • Page 65 NOTCH/B.MARK Threshold value (in percent) for the recognition of the presence of notch by the notch THRESHOLD sensor: NOTE: If the “Notch/B.Mark position” parameter is disabled, this parameter is not printed. Setting of the barcode format associated with ID 4 (see AEA speciications): BARCODE ID 4 Code128 = sets the Code128 format...
  • Page 66 Plastic plastic casing Metal = metallic casing NOTE: The parameter is printed only for TK180 models. PRINTHEAD TEST Setting of the performing of the print head test: POWERON Disabled = the test is performed only during the printing of the setup report...

  • Page 67: Ethernet Parameters

    5.5 Ethernet parameters Models with ETHERNET port These devices allow the coniguration of the parameters listed in the following table. The parameters marked with the symbol are the default values. Settings remain active even after the device has been turned off and they are stored in non-volatile memory. DHCP CLIENT Setting of the DHCP protocol: Disabled = protocol disabled Enabled =...

  • Page 68: Hexadecimal Dump

    5.6 Hexadecimal dump This function is used for the diagnosis of the characters received from the communications port. Characters are printed as hexadecimal code and the corresponding ASCII code (see below). Each line is preceded by a counter in hexadecimal that indicates the number of bytes received.

  • Page 69: Maintenance

    6 MAINTENANCE 6.1 Printer paper jam Open the device cover (see previous paragraphs). Close the device cover. ROOM Remove the damaged paper and check the presence Insert the paper for paper scraps inside the device. Carefully remove all (see previous paragraphs). paper scraps.

  • Page 70: Cutter Paper Jam

    6.2 Cutter paper jam KPM180H (models with presenter) Open the printer cover (see previous paragraphs). Lift the cover of the presenter. Start the automatic unlocking procedure by pressing the LF LINE FEED key. Try to remove the paper. Push the opening lever of the presenter.
  • Page 71 Inspection window Locate the inspection window for the cutter placed in the bottom of the presenter Remove the damaged paper and check the presence for paper scraps inside the printer; carefully remove all scraps of paper. If necessary, use tweezers. Blade Insert a Phillips screwdriver in the inspector window and turn the worm screw...

  • Page 72: Planning Of Cleaning Operations

    If you use the device in dusty environments, you must reduce the intervals between the cleaning operations. For some models, only the internal printer group is represented. (1) Only for KPM180H with presenter. (2) Only for TK180. Don't use any ammonia-based product.

  • Page 73: Cleaning

    6.4 Cleaning For periodic cleaning of the device, see the instructions below Sensors Paper path Disconnect the power supply cable and Disconnect the power supply cable and open the device cover (see par.4.1). open the device cover (see par.4.1). ATTENTION: ATTENTION: Do not use alcohol, solvents, or hard brushes.
  • Page 74 Printing head Printing roller Disconnect the power supply cable and Disconnect the power supply cable and open the device cover (see par.4.1). open the device cover (see par.4.1). ISOPROPYL ALCOHOL ISOPROPYL ALCOHOL ATTENTION: ATTENTION: Do not use solvents, or hard brushes. Do not use solvents, or hard brushes.
  • Page 75 Cutter Disconnect the power supply cable and open the device cover (see par.4.1). ATTENTION: Do not use alcohol, solvents, or hard brushes. Do not let water or other liquids get inside the device. Alcohol, solvent Clean the cutter by using compressed air. Push the opening lever and lift the presenter cover.
  • Page 76 Case Display Disconnect the power supply cable. Disconnect the power supply cable. ATTENTION: ATTENTION: Do not use alcohol, solvents, or hard brushes. Do not use alcohol, solvents, or hard brushes. Do not let water or other liquids get inside the machine. Do not let water or other liquids get inside the device.

  • Page 77: Upgrade Irmware

    6.5 Upgrade irmware WARNING: Firmware rel.: None Printer type: None Hardware rel.: None Select port: None Before proceeding with the upgrade procedure, set PSW Version : None the “Service” value for the “Emulation” parameter (see File [*.cfg] : None chapter 5). File (*.psw): During communication between PC and device for the irmware update it is strictly forbidden to disconnect the ...
  • Page 78 Update via USB interface 9. Select item USB and then select the USB device among ATTENTION: those proposed (e.g. device1): Only  during  the  irmware  update,  the  connection  be- tween PC and device must be direct, without the use Select Printer of HUB device.

  • Page 79: Specification

    7 SPECIFICATION 7.1 Hardware speciications GENERAL Head temperature, paper presence, mobile detectors of black mark or Sensors translucent gap/hole (setting by software), cover open, external low paper MTBF 113 000 hours Emulations SERVICE, ATB, BTP Windows XP VISTA (32/64bit) Windows 7 (32/64bit) Printing driver Windows 8 (32/64bit) Linux...
  • Page 80 Thermal, ixed head Printing method Head life Abrasion resistance 100 km (with recommended paper) Pulse durability 100 M (12.5% duty cycle) UPCA, UPCE, EAN13, EAN8, CODE39, ITF, Printable barcode CODABAR, CODE93, CODE128, CODE32, PDF417, DATAMATRIX, AZTEC, QRCODE Printing speed (2) (4) High Speed = 200 mm/sec 200dpi models Normal = 150 mm/sec High Quality = 100 mm/sec...
  • Page 81 DEVICE ELECTRICAL SPECIFICATIONS Power supply 24 Vdc ±10% (optional external power supply) Medium consumption 1.6 A Typical consumption 1.5 A Stand-by consumption 200dpi models 0.04 A 300dpi models 0.06 A ELECTRICAL SPECIFICATIONS POWER SUPPLY cod.963GE020000003 Power supply voltage from 100 Vac to 240 Vac Frequency from 50 Hz to 60 Hz Current (output)

  • Page 82: Device Dimensions

    7.2 Device dimensions KPM180H (standard models) Length 97.5 mm Height 67 mm Width 108 mm Weight 800 g NOTE: All the dimensions shown in following igures are in millimetres.
  • Page 83 KPM180H (models with presenter) Length 149 mm Height 67 mm Width 108 mm Weight 1 500 g NOTE: All the dimensions shown in following igures are in millimetres.
  • Page 84 TK180 (metallic models) Length 122.6 mm Height 85 mm Width 145.6 mm Weight 2 240 g NOTE: All the dimensions shown in following igures are in millimetres. 61.5 12.6...
  • Page 85 TK180 (plastic models) Length 185.9 mm Height 118.9 mm Width 130 mm Weight 1 940 g NOTE: All the dimensions shown in following igures are in millimetres. 185.9...

  • Page 86: Device Dimensions With Pretensioner Module

    7.3 Device dimensions with pretensioner module KPM180H (standard models) Length 169.5 mm Height 92 mm Width 116 mm Weight 1 230 g NOTE: All the dimensions shown in following igures are in millimetres. 3 x M3 4 x M3 61.5 152.6 164.5...
  • Page 87 KPM180H (models with presenter) Length 222 mm Height 92 mm Width 116 mm Weight 1 930 g NOTE: All the dimensions shown in following igures are in millimetres. 75.5 52.5 3 x M3 4 x M3 32.5 96.35 205.1 139.5...

  • Page 88: Device Dimensions With Paper Roll Holder

    7.4 Device dimensions with paper roll holder TK180 (metallic models) Length 324 mm Height 158 mm Width 145.6 mm Weight 3 240 g NOTE: All the dimensions shown in following igures are in millimetres.
  • Page 89 TK180 (plastic models) Length 371.4 mm Height 210.8 mm Width 136.5 mm Weight 2 840 g NOTE: All the dimensions shown in following igures are in millimetres. 371.4 185.9 162.8...

  • Page 90: Dimensions Of Power Supply Cod. 963Ge020000003

    7.5 Dimensions of power supply cod. 963GE020000003 Length 127 mm Height 35.5 mm Width 56 mm NOTE: All the dimensions shown in following igures are in millimetres. AC INLET n.c. +24V DC OUTPUT WIRE...

  • Page 91: Accessories

    8 ACCESSORIES The following table shows the list of available accessories for device: KPM180H (all models) DESCRIPTION CODE 963GE020000003 POWER SUPPLY (for technical speciications, see the par.7.1) 26500000000352 SERIAL CABLE DB9M-DB9F length = 1.8m (only for models without ETHERNET port) 26900000000026 ADAPTER CABLE RJ45M-DB9F length = 0.1m (only for models with ETHERNET port) 976AH010000002 PRETENSIONER MODULE...
  • Page 92 976AH010000001 PRESENTER MODULE + AUTOCUTTER (only for standard models - for technical speciications, see the par.7.1) TK180 (metallic models) DESCRIPTION CODE 963GE020000003 POWER SUPPLY (for technical speciications, see the par.7.1) 974HL010000001 PAPER ROLL HOLDER 26900000000026 SERIAL CABLE RJ45M-DB9F length = 0.1m (only for models with ETHERNET port)
  • Page 93 TK180 (plastic models) DESCRIPTION CODE 963GE020000003 POWER SUPPLY (for technical speciications, see the par.7.1) 974HL020000001 PAPER ROLL HOLDER 26500000000352 SERIAL CABLE DB9M-DB9F length = 1.8m (only for models without ETHERNET port) 26900000000026 ADAPTER CABLE RJ45M-DB9F length = 0.1m (only for models with ETHERNET port)

  • Page 95: Alignment

    9 ALIGNMENT Device is provided with sensors for the use of alignment notch in order to handle: •  roll of tickets with pre-printed ields and a ixed length; •  Fan-fold of tickets with pre-printed ields and a ixed length. The alignment notch may be formed by •  black mark printed on paper; •  hole between two tickets; All alignment sensors are “relection” sensors: this kind of sensor emits a band of light and detects the quantity of light  relected to it. The presence of the notch is therefore detected by the amount of light that returns to the sensor, considering  that the light is relected by the white paper and absorbed by the black mark.  To use tickets with holes, it is possible to use the same sensors as “transparence” sensors, coupled two by two: a beam of light is emitted by the transmitter sensor and the quantity of light which reaches the opposite receiver sensor is detected.

  • Page 96: Enable Alignment

    9.1 Enable alignment Device is provided with two sensors for alignment, placed as follows: •  one mobile sensor on the bottom lat, •  one mobile sensor on the top lat. To guarantee the alignment, it is necessary to correctly choose the sensor to use for the notch detection depending on the type of notch and its location on the ticket. To do this, you must enable the parameter “Notch/B.Mark Position”...

  • Page 97: Calibration

    9.2 Calibration The sensor calibration occurs automatically and consists in adjusting the quantity of light emitted to match the degree of whiteness of the paper used and the degree of black of the mark printed on paper. The device automatically performs the self-calibration during the Setup procedure only if the “Notch/B.Mark Position” pa- rameter is set to a value other than “Disabled”...
  • Page 98 The following igure shows an example of paper with holes: the outgoing voltage is constant while passing the paper be- tween two holes and presents a variation at each hole. In this case, the optimal value for the “Notch/B.Mark Threshold” parameter is placed about half of the variation. NON-THERMAL SIDE “Notch/B.Mark Threshold” THERMAL SIDE Peak...
  • Page 99 The following igure shows an example of paper with the non-thermal paper printed with black marks and other graphics  (for example, a barcode): the outgoing voltage is constant while passing the white paper between two notches, presents a peak at each black mark and presents some “noise” at each barcode. In this case, the optimal value for the “Notch/B.Mark Threshold”...

  • Page 101: Technical Service

    10 TECHNICAL SERVICE In case of failure, send the 4 pieces of information listed below to our support team: 1. Product code 2. Serial number 3. Hardware release 4. Firmware release 5. Firmware type To get the necessary data, proceed as follows: XXXXXXXXXXXXXX 0000000000000000000 Customer Service Department:...

  • Page 103: Advanced Functions

    Through this kind of connection, it is possible to manage drivers, fonts and logos of the device and conigure the operating  parameters by iles sharing from Mass Storage. FILE SHARING FROM MASS STORAGE 11.2 Drivers installation TK180 (all models) It is possible to install the new driver update directly into the folder “DRIVER” on the Flash Drive of the device. To enter the Flash Drive by iles sharing from Mass Storage you need to enable the relative parameter during the conigu- ration process (see chapter 5).

  • Page 104: Setup

    11.3 Setup It is possible to conigure the default parameters for device setup by editing the “Setup.ini” ile on the Flash Drive. To enter the Flash Drive by iles sharing from Mass Storage, you need to enable the relative parameter during the con- iguration process (see chapter 5). After editing device’s parameter, simply save the “Setup.ini” ile to make the modiies activated. The “Setup.ini” ile is a coniguration ile that contains all the conigurable parameters listed in text format and divided into  some sections (indicated in square brackets). The available values for every parameter, are listed after the parameter name. The value marked with the symbol ‘ * ’ is the default one. To modify printer’s parameters, change the numeric value after the name of parameters. To set the parameter to the default value, change the numeric value with the symbol D.
  • Page 105 ATB ticket length 0*, 1, 2, 3 0 = Auto 1 = Auto No Recovery 2 = 8" Fixed 3 = 7" 3/8 Fixed Near Paper End 0*, 1 0 = Disabled 1 = Enabled Casing Type 0, 1* 0 = Metal 1 = Plastic After Cut Ejecter Type 0*, 1...
  • Page 106 [NETWORK] (only for models with ETHERNET port) DHCP Client 0*, 1 0 = Disabled 1 = Enabled IP Address Subnet Mask Default Gateway Domain Name System TCP Printer Port MAC Address...
  • Page 108 CUSTOM S.p.A. World Headquarters Via Berettine, 2/B - 43010 Fontevivo, Parma ITALY Tel. +39 0521 680111 - Fax +39 0521 610701 info@custom.biz - www.custom.biz All rights reserved www.custom.biz...
