INSTRUCTION MANUAL
CONVERTIBLE CHILD SEAT
ISOFIX COMPATIBLE
Series No. BS3300A-i20133
IMPORTANT: KEEP THIS BOOKLET IN THE PLACE PROVIDED
ON THE CHILD RESTRAINT
Birth to 2-3 years (approx) REARWARD FACING
12 months to 4 years (approx) FORWARD FACING
Instructions for Installation & Use
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Safe-N-Sound and is the answer not in the manual?

Questions and answers

Related Manuals for Britax Safe-N-Sound

Summary of Contents for Britax Safe-N-Sound

  • Page 1 INSTRUCTION MANUAL CONVERTIBLE CHILD SEAT Birth to 2-3 years (approx) REARWARD FACING ISOFIX COMPATIBLE 12 months to 4 years (approx) FORWARD FACING Series No. BS3300A-i20133 IMPORTANT: KEEP THIS BOOKLET IN THE PLACE PROVIDED ON THE CHILD RESTRAINT Instructions for Installation & Use...

  • Page 2: Table Of Contents

    CONTENTS QUICK START GUIDE - a shortened version of the manual • REARWARD FACING SEATBELT • REARWARD FACING ISOFLEX ® • FORWARD FACING SEATBELT • FORWARD FACING ISOFLEX ® MEET YOUR CHILD SEAT IMPORTANT INFORMATION AND WARNINGS SHOULDER HEIGHT MARKERS OUTGROWN YOUR CHILD SEAT CHILD SEAT SUITABILITY GUIDE REARWARD FACING...
  • Page 3 CONTENTS FORWARD FACING 06/04/2021 https://tiny.cc/tiny/31881590/qr/print/l CHILD SEAT FEATURES - FORWARD FACING SET UP • GENERAL INFORMATION • FORWARD FACING RECLINE POSITIONS Scan QR code • INSTALLING INTO YOUR VEHICLE for forward • SEATBELT FOR FORWARD FACING facing seatbelt installation video. •...

  • Page 4: Rearward Facing Seatbelt

    QUICK START GUIDE - REARWARD FACING SEATBELT Hey, before you install me! Don't forget to note your serial number found on the seat to complete your warranty registration. Lift + latch Cover Pull Press Press Remove infant insert Do not trap buckle Lift out middle cover under seatbelt Instructions for Installation &...
  • Page 5 QUICK START GUIDE - REARWARD FACING SEATBELT Replace middle cover Remove slack Pull Push Replace infant insert Pull to tighten Attach Store strap Remove slack Lift Harness Straps not below green zone DO NOT USE Infant use only Instructions for Installation & Use...

  • Page 6: Rearward Facing Isoflex

    QUICK START GUIDE - REARWARD FACING ISOFLEX ® Hey, before you install me! Don't forget to note your serial number found on the seat to complete your warranty registration. Lift + latch Remove infant insert Pull Press Press Lift out middle cover Press to lengthen Press button Under cover...
  • Page 7 QUICK START GUIDE - REARWARD FACING ISOFLEX ® Close door and Push down replace middle cover Pull to tighten Push Pull Pull Store strap Attach Replace Remove slack infant insert Lift Harness Straps not below green zone DO NOT USE Infant use only Instructions for Installation &...

  • Page 8: Forward Facing Seatbelt

    QUICK START GUIDE - FORWARD FACING SEATBELT Hey, before you install me! Don't forget to note your serial number found on the seat to complete your warranty registration. Press grey button Under cover Remove Cover slide button to release door Lift Open door...
  • Page 9 QUICK START GUIDE - FORWARD FACING SEATBELT Replace middle cover Remove slack Pull to tighten Pull Attach Push Remove slack Lift Store strap Harness Straps not below green zone Instructions for Installation & Use...

  • Page 10: Forward Facing Isoflex

    QUICK START GUIDE - FORWARD FACING ISOFLEX ® Hey, before you install me! Don't forget to note your serial number found on the seat to complete your warranty registration. Press grey button Under cover Remove Cover slide button to release door Lift Open door...
  • Page 11 QUICK START GUIDE - FORWARD FACING ISOFLEX ® Close door and Press to lengthen Press button replace middle cover and remove Pull Push down Pull Push Attach Pull to tighten Lift Pull Remove slack Store strap Harness Straps not below green zone Instructions for Installation &...

  • Page 12: Meet Your Child Seat

    AND FOLLOW THESE INSTRUCTIONS EXACTLY and use only Britax Safe-n-Sound ® recommended parts and accessories. If in doubt about the method of installation, consult Britax Childcare or agent, or a child restraint fitter or, in New Zealand, to consult the agent for the vehicle. 只用于后向式安装，直到婴儿的肩膀达到靠下的肩高标记（大约12个月的宝宝）或者中部的肩高标...
  • Page 13 MEET YOUR CHILD SEAT ISOFIX COMPATIBLE There will be straps fitted to each side of the lower part of the seat. Britax flexible strap ISOFIX Compatible connector technology is known as ISOFLEX ® WHAT ARE ISOFIX LOW ANCHORAGES IN A VEHICLE? ISOFIX low anchorages are fixed, standardised anchoring points for securely installing an ISOFIX compatible child restraint in a vehicle fitted with ISOFIX low anchorages.

  • Page 14: Important Information And Warnings

    IMPORTANT INFORMATION AND WARNINGS • Fit the restraint firmly to the car seat. • Fit the harness firmly to the child. • A loose restraint or harness is dangerous. • Supervision of children is needed because they may be able to undo the buckles and adjusters.
  • Page 15 IMPORTANT INFORMATION AND WARNINGS IMPORTANT: TO BE USED WITH A LAP-SASH OR LAP-ONLY SEATBELT OR ISOFIX LOW ANCHORAGES IN THE BACK OF MOST CARS WITH FORWARD FACING SEATS. GENERAL • Do not attach the lower attachment connectors of two separate child restraints to the same ISOFIX low anchorages in your car.

  • Page 16: Shoulder Height Markers

    SHOULDER HEIGHT MARKERS Shoulder height markers are featured clearly on the child seat (as seen in diagram). The markers provide an indicator for when your child has outgrown the child's seat rearward or forward facing modes. Instructions for Installation & Use...
  • Page 17 Your child MUST be forward facing forward facing their shoulders are above the middle marker. Middle Height Marker Your child can be Britax recommends rearward facing rearward facing using this restraint OR forward facing forward facing in rearward if their shoulders are...
  • Page 18 SHOULDER HEIGHT MARKERS IMPORTANT: Follow this advice. Instructions for Installation & Use...
  • Page 19 SHOULDER HEIGHT MARKERS Child Use (Forward Facing) Upper Height Marker Middle Height Marker Older Baby (Rearward Facing) Older Baby (Forward Facing) Middle Height Marker Lower Height Marker Middle Height Marker Lower Height Marker Newborn (Rearward Facing) Lower Height Marker Instructions for Installation & Use...

  • Page 20: Outgrown Your Child Seat

    OUTGROWN YOUR CHILD SEAT When your child has outgrown this seat, you can use: • A harnessed child seat with in-built harness suitable for children approximately 6 months to 8 years old. • A convertible booster seat with in-built harness until approximately 4 years old and then as a booster seat with vehicle lap-sash seatbelt until approx 6 to 8 years of age (or seatbelt...

  • Page 21: Child Seat Suitability Guide

    CHILD SEAT SUITABILITY GUIDE CHILD SEAT SUITABILITY GUIDE These child restraints, when used correctly, allow the driver to meet the Australian Road Rules in each state. Instructions for Installation & Use...

  • Page 22: Child Seat Features - Rearward Facing

    CHILD SEAT FEATURES - REARWARD FACING 1. Adjustable Headrest 2. Shoulder Height Markers 3. Shoulder Pads 4. Infant Insert - For Use Up to Lower Height Marker 5. Harness 6. EZ Buckle 7. Harness Adjuster Button 8. Harness Adjuster Strap (lower) 9.
  • Page 23 CHILD SEAT FEATURES - REARWARD FACING 16. Vehicle's Anchor Fitting 17. Attachment Clip 18. REARWARD FACING BELT PATH (Blue) 19. Level Indicator 20. FORWARD FACING BELT PATH (Yellow) 21. Advanced Side Impact Cushion Technology (SICT™) 22. Top Tether and Instruction Manual Storage Pocket 23.

  • Page 24: General Information

    SETUP - GENERAL INFORMATION FOR REARWARD FACING CHILD SEAT UPPER ANCHORAGE POINT This child seat must be installed using the top tether. The top tether will need to attach to the appropriate upper anchorage point for both rearward and forward facing modes. Refer to the car owner's handbook for anchorage locations or points.

  • Page 25: Convert To Rearward Facing

    SETUP - CONVERT TO REARWARD FACING CONVERT TO REARWARD FACING MODE: To fully recline the child seat, Step 1. Squeeze the grey recline lever upwards. Step 2. Press the blue release button down whilst squeezing the grey recline lever, rotate the child seat to rearward facing position.
  • Page 26 SETUP - CONVERT TO REARWARD FACING IMPORTANT: Rebound bar and cover must be set up as shown in rearward facing mode. HOW TO SETUP THE REBOUND BAR AND COVER: Step 1. Unbutton the flap over the remound bar located at the front of the seat. Step 2.

  • Page 27: Installing Into Your Vehicle

    SETUP - INSTALLING INTO YOUR VEHICLE FOR REARWARD FACING INSTALLING INTO YOUR VEHICLE: Step 1. Press harness adjuster button. Step 2. Place your hand under both shoulder harness straps, then pull shoulder Press Pull harness straps to lengthen. Step 3. Disengage buckle by pressing red button.
  • Page 28 SETUP - INSTALLING INTO YOUR VEHICLE FOR REARWARD FACING Choose the vehicle seat position. Step 5. Ensure child seat is against vehicle seatback - the rebound bar does not need to contact vehicle seatback. If desired, this gap may be packed (see page 30).

  • Page 29: Recline Angle

    SETUP - RECLINE ANGLE FOR REARWARD FACING REARWARD FACING LEVEL INDICATOR: The Rearward Facing Level Indicator shows when your child seat is installed at the correct angle for your vehicle. It gives you confidence the child seat is positioned correctly whenever you travel.
  • Page 30 SETUP - RECLINE ANGLE FOR REARWARD FACING ANGULAR ADJUSTMENT OF RESTRAINT Some vehicle seats have more rearward slope than others. The angle may be adjusted by placing a firm packing between the child seat and the underside of the base. Packing can be a firmly rolled up towel (see figure A).

  • Page 31: Seatbelt For Rearward Facing

    SETUP - SEATBELT FOR REARWARD FACING HOW TO INSTALL USING SEATBELT: Step 1. Remove infant insert (if fitted). IMPORTANT - Ensure buckle tongues are placed into buckle tongue holders prior to feeding through seatbelt. VEHICLE SEATBELT Step 2. Lengthen vehicle seatbelt. Sash belt belt studs closed...
  • Page 32 SETUP - SEATBELT FOR REARWARD FACING Step 4. Feed vehicle seatbelt through blue REARWARD FACING BELT PATH guide, ensure the seatbelt is not twisted during installation. Step 5. Continue feeding vehicle seatbelt through opposite blue REARWARD FACING BELT PATH guide. Step 6.
  • Page 33 SETUP - SEATBELT FOR REARWARD FACING Step 7. Hold the child seat in position with firm downward pressure onto the child Pull seating area. Remove all slack from the seatbelt by feeding seatbelt slack from the buckle side back across the child seat while pulling the vehicle sashbelt upwards.
  • Page 34 SETUP - SEATBELT FOR REARWARD FACING Step 8. Refit infant insert as required. You are now ready to install top tether. Refer to page 39. ENSURE THERE ARE NO TWISTS IN ISOFLEX CONNECTOR STRAPS ® ALWAYS REMOVE SLACK FROM ISOFLEX STRAPS.

  • Page 35: Isoflex ® For Rearward Facing

    SETUP - ISOFLEX FOR REARWARD FACING ® ® HOW TO INSTALL USING ISOFLEX Step 1. Locate the ISOFIX Low Anchorages ISOFIX low anchors in the vehicle in the vehicle rear seat. If you cannot rear seat locate the ISOFIX bars, check your vehicle owners manual.
  • Page 36 SETUP - ISOFLEX FOR REARWARD FACING ® Step 4. Slide button to release door to expose ISOFLEX Connectors. ® Slide button to release door Lift door Step 5. To remove the ISOFLEX connectors ® Press button from their location, press the red button and lift out Step 6.
  • Page 37 SETUP - ISOFLEX FOR REARWARD FACING ® Step 7. Lengthen ISOFLEX strap by pressing ® adjuster button and pulling strap through Step 8. To close door, remove any excess shoulder/lap straps, harness tongues Close and crotch buckle that may become door trapped.
  • Page 38 SETUP - ISOFLEX FOR REARWARD FACING ® Push down Step 10. Push downwards on the seat to compress the seat into the vehicle. Whilst pushing into the seat, pull on adjuster strap to remove all slack and tighten the ISOFLEX strap.

  • Page 39: Top Tether For Rearward Facing

    SETUP - TOP TETHER FOR REARWARD FACING HOW TO INSTALL THE TOP TETHER: Step 1. Press top tether adjuster button and Press Step 2. Lengthen top tether strap fully, ensure all unnecessary twists are removed. Pull Step 3. Connect top tether attachment clip to vehicle anchor fitting.
  • Page 40 SETUP - TOP TETHER FOR REARWARD FACING Step 5. Ensure slack is removed from the top tether straps by pulling top tether adjuster strap. Do not over tighten as it may cause your child seat to lift. Pull ALWAYS REMOVE SLACK IN THE TOP TETHER AND STORE STRAP.

  • Page 41: Open Advanced Side Impact Cushion Technology

    SETUP - OPEN ADVANCED SIDE IMPACT CUSHION TECHNOLOGY FOR REARWARD FACING OPEN ADVANCED SIDE IMPACT CUSHION TECHNOLOGY: NOTE. The SICT™ system should not be used if the child seat is in the centre position. For further information on SICT™ refer to page 13.

  • Page 42: Headrest And Shoulder Harness

    SETUP - HEADREST AND SHOULDER HARNESS FOR REARWARD FACING HOW TO USE - HEADREST AND SHOULDER HARNESS: Step 1. Press top tether adjuster button and Press Step 2. Lengthen top tether strap fully (if desired). Pull Step 3. Press harness adjuster button. Step 4.
  • Page 43 SETUP - HEADREST AND SHOULDER HARNESS FOR REARWARD FACING Step 7. Place buckle tongues into buckle tongue holders. Step 8. Place baby into child seat. Ensure baby is positioned with their back flat against the back rest and their bottom correctly positioned into the curved seat base.
  • Page 44 SETUP - HEADREST AND SHOULDER HARNESS FOR REARWARD FACING Step 10. Engage Buckle. ENSURE BUCKLE IS ALWAYS Tongue CONNECTED DURING USE. Buckle ENSURE ALL HARNESS STRAPS ARE NOT TWISTED. Shoulder Strap strap Step 11. Remove all slack from the lap strap area (including behind baby's bottom), by pulling up on the shoulder straps.

  • Page 45: Remove Child From Child Seat

    SETUP - REMOVE CHILD FROM CHILD SEAT FOR REARWARD FACING REMOVING CHILD FROM SEAT: Press Step 1. Press top tether adjuster button and Step 2. Lengthen top tether strap fully. Pull Step 3. Loosen shoulder harness straps by pressing the harness adjuster button. Press Step 4.

  • Page 46: Remove Child Seat From Vehicle Seatbelt

    SETUP - REMOVE CHILD SEAT FROM VEHICLE FOR REARWARD FACING SEATBELT REMOVING CHILD SEAT FROM Press VEHICLE: Step 1. Press top tether adjuster button and Step 2 . Lengthen top tether strap fully. Pull Step 3. Disconnect top tether attachment clip from vehicle anchorage fitting.

  • Page 47: Remove Child Seat From Vehicle Isoflex

    SETUP - REMOVE CHILD SEAT FROM VEHICLE FOR REARWARD FACING ISOFLEX ® REMOVING CHILD SEAT FROM Press VEHICLE: Step 1. Press top tether adjuster button and Step 2 . Lengthen top tether strap fully. Pull Step 3. Disconnect top tether attachment clip from vehicle anchorage fitting.
  • Page 48 SETUP - REMOVE CHILD SEAT FROM VEHICLE FOR REARWARD FACING ISOFLEX ® Step 7. Slide button to release door to expose ISOFLEX Connectors storage pins. ® Lift door Slide button to release door Step 8. Feed ISOFLEX Connectors back ® through blue REARWARD FACING BELT PATH.

  • Page 49: Store Rebound Bar And Cover

    SETUP - STORE REBOUND BAR AND COVER FOR REARWARD FACING STORE REBOUND BAR: Step 1. Slide button to release door to locate Under middle the grey release rebound bar button. cover slide button to Step 2. Uncover the rebound bar and press release door the grey release rebound bar button to unlock the rebound bar.

  • Page 50: Close Advanced Side Impact Cushion Technology

    SETUP - CLOSE ADVANCED SIDE IMPACT CUSHION TECHNOLOGY FOR REARWARD FACING CLOSE ADVANCED SIDE IMPACT CUSHION TECHNOLOGY: Step 1. Rotate clockwise to close. Instructions for Installation & Use...

  • Page 51: Child Seat Features - Forward Facing

    CHILD SEAT FEATURES - FORWARD FACING 1. Adjustable Headrest 2. Shoulder Height Markers 03. Shoulder Pads (If supplied) 04. Harness 5. Release Buckle (Red button) 06. EZ Buckle (If supplied) 7. Harness Adjuster Button 8. Harness Adjuster Strap (lower) 9. Cover 10.
  • Page 52 CHILD SEAT FEATURES - FORWARD FACING 14. Forward Facing Recline Positions 15. REARWARD FACING BELT PATH (Blue) 16. FORWARD FACING BELT PATH (Yellow) 17. Advanced Side Impact Cushion Technology (SICT™) (If supplied) 18. Top Tether Adjuster Strap 19. Top Tether Storage Pocket and Instruction Manual Location 20.

  • Page 53: General Information

    SETUP - GENERAL INFORMATION FOR FORWARD FACING IS THERE ENOUGH ROOM ? 538mm To ensure that the space is sufficient, the FORWARD purchaser should check the measurements FACING between the vehicle’s rear and front seats in MEASUREMENTS which the child restraint is intended to be used for forward facing mode.
  • Page 54 SETUP - GENERAL INFORMATION FOR FORWARD FACING Step 4. Reattach the flap and press down the studs. Step 5. Place one hand on the child seat back and with the other hand on the grey recline lever, squeeze upwards. Step 6. Rotate child seat into an upright position.

  • Page 55: Forward Facing Recline Positions

    SETUP - FORWARD FACING RECLINE POSITIONS FORWARD FACING RECLINE POSITIONS: When you convert your child seat to forward facing mode, there are four, simple to use forward facing recline positions you can choose from to ensure your child travels as comfortably as possible.

  • Page 56: For Forward

    SETUP - INSTALLING INTO YOUR VEHICLE FOR FORWARD FACING INSTALLING INTO YOUR VEHICLE: Step 1. Choose vehicle seat position. Step 2. Ensure child seat is against vehicle seatback and top tether is not trapped behind seat. Place top tether and attachment clip over back of vehicle seat towards anchor fitting.
  • Page 57 SETUP - INSTALLING INTO YOUR VEHICLE FOR FORWARD FACING Step 3. Press harness adjuster button. Step 4. Place your hand under both shoulder Press harness straps, then pull shoulder Pull harness straps to lengthen. Step 5. Disengage buckle by pressing red button.

  • Page 58: Seatbelt For Forward Facing

    SETUP - SEATBELT FOR FORWARD FACING HOW TO INSTALL SEATBELT: Step 1. Lift open cover from the middle panel. Step 2. Lengthen vehicle seatbelt. VEHICLE SEATBELT Sash belt belt Step 3. Feed vehicle seatbelt through yellow FORWARD FACING BELT PATH guide, across the seat and out the opposite guide.
  • Page 59 SETUP - SEATBELT FOR FORWARD FACING ENSURE SEATBELT IS ROUTED ACROSS THE CHILD SEAT UNDER THE TRIM. DO NOT TRAP HARNESS STRAPS. Step 4. Engage the vehicle seatbelt buckle and tongue. ENSURE THERE ARE NO TWISTS IN SEATBELT. REMOVE SLACK. Instructions for Installation &...
  • Page 60 SETUP - SEATBELT FOR FORWARD FACING Step 5. Hold the child seat in position with firm downward pressure onto the child Pull seating area. Remove all slack from the seatbelt by feeding seatbelt slack from the buckle side back across the child seat while pulling the vehicle sashbelt upwards.

  • Page 61: Isoflex ® For Forward Facing

    SETUP - ISOFLEX FOR FORWARD FACING ® HOW TO INSTALL USING ISOFLEX ® Step 1. Locate the ISOFIX Low Anchorages ISOFIX low anchors in the vehicle in the vehicle rear seat. If you cannot rear seat locate the ISOFIX bars, check your vehicle owners manual.
  • Page 62 SETUP - ISOFLEX FOR FORWARD FACING ® Step 3. Slide button to release door to expose ISOFLEX Connectors. ® Slide button to release door Lift door Step 5. To remove the ISOFLEX connectors ® Press button from their location, press the red button and lift out Instructions for Installation &...
  • Page 63 SETUP - ISOFLEX FOR FORWARD FACING ® Step 5. Feed ISOFLEX Connectors through ® yellow FORWARD FACING BELT PATH on each side. IMPORTANT: Ensure you feed ISOFLEX ® connectors through the correct belt path without any twists. ALWAYS ROUTE AND ROTATE TOWARDS THE BELT PATH.
  • Page 64 SETUP - ISOFLEX FOR FORWARD FACING ® Step 7. Connect ISOFLEX connectors to ® ISOFIX low anchorages on each side. See vehicle manual to locate ISOFIX positions. A SLIGHT GATHER IN ISOFLEX ® CONNECTOR STRAPS IS ACCEPTABLE BUT TWISTS AND FOLDS ARE NOT. CHECK INSIDE THE CHILD SEAT THAT THE ISOFLEX CONNECTOR STRAP IS...
  • Page 65 SETUP - ISOFLEX FOR FORWARD FACING ® Step 8. Replace middle cover. You are now ready to install top tether. Refer to page 66. ENSURE THERE ARE NO TWISTS IN ISOFLEX CONNECTOR STRAPS. ® ALWAYS REMOVE SLACK FROM ISOFLEX STRAPS. ®...

  • Page 66: Top Tether For Forward Facing

    SETUP - TOP TETHER FOR FORWARD FACING HOW TO INSTALL THE TOP TETHER: Step 1. Press top tether adjuster button and Press Step 2. Lengthen top tether strap fully, ensure all unnecessary twists are removed. Pull Step 3. Connect top tether attachment clip to vehicle anchor fitting.
  • Page 67 SETUP - TOP TETHER FOR FORWARD FACING CAUTION: CHILDREN CAN BE INJURED OR RESTRAINTS AND TOP TETHER STRAP DAMAGED BY UNSECURED CARGO IN A COLLISION. SECURE OR REMOVE HAZARDOUS CARGO BEFORE USING THIS CHILD RESTRAINT. IMPORTANT: The top tether strap must be fitted at all times. Always secure the loose end of the top tether strap to prevent it hanging out of the car or being accessible by the child.
  • Page 68 SETUP - HEADREST AND SHOULDER HARNESS FOR FORWARD FACING HOW TO USE - HEADREST AND SHOULDER HARNESS: Step 1. Press harness adjuster button. Step 2. Place your hand under both shoulder harness straps, then pull shoulder Press Pull harness straps to lengthen. Step 3.
  • Page 69 SETUP - HEADREST AND SHOULDER HARNESS FOR FORWARD FACING Step 5. Place buckle tongues into buckle tongue holders. Step 6. Place child into child seat . Ensure your child sits fully back without slouching. Step 7. The shoulder straps must be in the slots which are nearest to the child’s Harness Straps shoulders, but not more than 25mm...
  • Page 70 SETUP - HEADREST AND SHOULDER HARNESS FOR FORWARD FACING Step 8. Engage Buckle ENSURE BUCKLE IS ALWAYS Tongue CONNECTED DURING USE. Buckle ENSURE ALL HARNESS STRAPS ARE NOT TWISTED. Shoulder Strap strap Step 9. Remove all slack from the lap strap area (including behind child's bottom), by pulling up on the shoulder straps.

  • Page 71: Open Advanced Side Impact Cushion Technology

    SETUP - OPEN ADVANCED SIDE IMPACT CUSHION TECHNOLOGY FOR FORWARD FACING OPEN ADVANCED SIDE IMPACT CUSHION TECHNOLOGY: NOTE. The SICT™ system should not be used if the child seat is in the centre position. For further information on SICT™ refer to page 13.

  • Page 72: Remove Child From Child Seat

    SETUP - REMOVE CHILD FROM CHILD SEAT FOR FORWARD FACING REMOVING CHILD FROM CHILD SEAT: Step 1. Loosen shoulder harness straps by pressing the harness adjuster button. Step 2. Pull both shoulder harness straps Pull Press evenly. Step 3. Disengage buckle by pressing red button.

  • Page 73: Remove Child Seat From Vehicle Seatbelt

    SETUP - REMOVE CHILD SEAT FROM VEHICLE FOR FORWARD FACING SEATBELT HOW TO REMOVE SEAT FROM VEHICLE: Press Step 1. Press top tether adjuster button and Step 2. Lengthen top tether strap fully. Pull Step 3. Disconnect top tether attachment clip from vehicle anchorage fitting.
  • Page 74 SETUP - REMOVE CHILD SEAT FROM VEHICLE FOR FORWARD FACING SEATBELT Step 5. Lift open cover from the middle panel. Step 6. Remove vehicle seatbelt from yellow Forward Facing Belt Path. Replace middle cover. Instructions for Installation & Use...

  • Page 75: Remove Child Seat From Vehicle Isoflex

    SETUP - REMOVE CHILD SEAT FROM VEHICLE FOR FORWARD FACING ISOFLEX ® REMOVING CHILD SEAT FROM Press VEHICLE: Step 1. Press top tether adjuster button and Step 2 . Lengthen top tether strap fully. Pull Step 3. Disconnect top tether attachment clip from vehicle anchorage fitting.

  • Page 76: For Forward Facing Isoflex

    SETUP - REMOVE CHILD SEAT FROM VEHICLE FOR FORWARD FACING ISOFLEX ® Step 7. Slide button to release door to expose ISOFLEX Connectors storage pins. ® Slide button to Lift door release door Step 8. Feed ISOFLEX Connectors back ® through yellow FORWARD FACING BELT PATH.

  • Page 77: Close Advanced Side Impact Cushion Technology

    SETUP - CLOSE ADVANCED SIDE IMPACT CUSHION TECHNOLOGY FOR FORWARD FACING CLOSE ADVANCED SIDE IMPACT CUSHION TECHNOLOGY : Step 1. Rotate clockwise to close. Instructions for Installation & Use...

  • Page 78: Care And Maintenance

    Ensure the buckle is free of fluff, liquid or other matter that may enter the buckle opening. Clean the buckle if it is difficult to engage. See next page. Immediate repair is required if any of the above issues are observed. Contact Britax Customer Service 1300 303 330.

  • Page 79: Clean Harness Buckle

    Click the 3-bar slide is fed through the same slots. If the harness buckle cannot be returned to its original working condition then contact Britax Customer Service for assistance. Instructions for Installation & Use...

  • Page 80: Remove Cover

    CARE AND MAINTENANCE - REMOVE COVER TO REMOVE COVER FOR WASH: NOTE: There is no need to disconnect the shoulder harness assembly straps from restraint. Step 1. Remove the restraint from vehicle. Step 2. Disengage the harness tongues from the harness buckle. Step 3.
  • Page 81 CARE AND MAINTENANCE - REMOVE COVER To remove cover: Step 1. Lift headrest to the highest position. Open door at the back of the child seat and unhook elastic loops. Step 2. Recline child seat to reveal elastic loops at the lower front of the child seat and detach from hooks.

  • Page 82: Replace Cover

    CARE AND MAINTENANCE - REPLACE COVER TO REPLACE COVER: To replace cover: Stretch the cover over the headrest and harness adjuster button, pull the adjuster strap through the cover. Ensure none of the harness straps are twisted. Step 1. Recline child seat to reveal hook at the lower front of the child seat and attach elastic loops.
  • Page 83 ® COVERS AND ACCESSORIES THAT ARE DESIGNED AND TESTED FOR USE WITH THIS PRODUCT. VERY IMPORTANT: Only replace the cover with Britax supplied ® replacement cover with identical shoulder height markers or a replacement cover meeting AS/NZS 8005. Instructions for Installation & Use...

  • Page 84: Accessories

    ACCESSORIES The following instructions apply to accessories that may be supplied with this restraint at point of purchase. They are for comfort use only. If not, a variety of Britax Safe-n-Sound ® accessories are available from various retailers of Britax Safe-n-Sound products.
  • Page 85 ACCESSORIES INFANT INSERTS (If supplied) For use until infant reaches the lower height marker (approx 18mth old) There are 3 types of infant inserts Infant Insert Designed to provide additional support for smaller babies. Discontinue use at the lower height marker or when the insert is a tight fit or creates discomfort for larger babies.
  • Page 86 ACCESSORIES VEHICLE SEAT PROTECTOR (If supplied) Long Vehicle Seat Protector (If supplied) The Vehicle Seat Protector have been specifically designed to protect your vehicle seat when using your child seat. Place pocket on edge of seat, smooth back toward seat join ('A') and fit in any excess Vehicle Seat Protector into the join of the child seat ('A').

  • Page 87: Installation Of Vehicle Upper Anchor Point

    INSTALLATION OF VEHICLE UPPER ANCHOR POINT Consult the vehicle owner’s handbook for location of anchorage fittings or anchorage points and the possible use of spacers. Some vehicles may have an anchor fitting fitted by the vehicle manufacturer. If anchorage points cannot be found refer to car manufacturer or local child restraint fitting station or traffic authority for optimum position of upper anchorage point and the use of spacers.
  • Page 88 INSTALLATION OF VEHICLE UPPER ANCHOR POINT Extension Straps Length 300mm (Use Britax Safe-n-Sound part 0035 or 0291). ® Length 600mm (Use Britax Safe-n-Sound part 0036 or 0290). ® Available from all major child restraint retailers. 45° Measure distance from restraint upper anchorage attachment clip to the car anchor fitting.
  • Page 89 INSTALLATION OF VEHICLE UPPER ANCHOR POINT IF THE CAR IS FITTED WITH A CHILD RESTRAINT UPPER ANCHORAGE POINT UPPER ANCHORAGE FITTING Locate the upper anchorage point behind Fig.1. the rear seating position. (Consult the car Attachment Bolt owners handbook for the location of the upper Lock washer anchorage point).
  • Page 90 INSTALLATION OF VEHICLE UPPER ANCHOR POINT For vehicles other than Sedans - In Australia, consult your nearest child restraint fitting station or traffic authority for vehicle inspection to find the best, correct position for the placement of the upper anchorage point, and for the correct attachment bolt length and use of spacers.
  • Page 91 INSTALLATION OF VEHICLE UPPER ANCHOR POINT CAR INSTALLATION ACCESSORIES (From retailers of Britax Safe-n-Sound products) ® EXTRA ANCHOR KITS: Available for using the restraint in additional cars. Re-order no: 0038 or 0289 EXTENSION STRAPS: May be required for cars without a fixed parcel shelf.

  • Page 92: In Case Of Accident

    Refer to the Britax crash exchange website for more details Our Crash Exchange Terms and Application form are accessible on our website. Please visit britax.com.au for further information.
  • Page 93 IN CASE OF ACCIDENT TOP TETHER STAGE RELEASE Your child seat is fitted with a Top Tether ‘Stage Release’ system. 1. Indicates how the strap looks when the seat is in good condition. 2. Indicates how the strap looks when the red stitching is torn and frayed.
  • Page 94 IN CASE OF ACCIDENT NOTICE TO INSURANCE COMPANY CHILD RESTRAINT INVOLVED IN AN ACCIDENT All Britax Safe-n-Sound child restraints are manufactured to Australian/New Zealand ® Standards AS/NZS1754-2013 which require us to advise users of child restraints to "Destroy the entire restraint if it has been in use in a severe crash, even if no damage is obvious". The joint Australian/New Zealand Standards committee CS/85, advise that this statement applies whether a child was in the child restraint or not.
  • Page 95 NOTES Instructions for Installation & Use...
