General Precautions

Observe the following Precautions when using the SYSDRIVE Inverters and peripheral devices.
This manual may include illustrations of the product with protective covers removed in order to
describe the components of the product in detail. Make sure that these protective covers are on the
product before use.
Consult your OMRON representative when using the product after a long period of storage.
Definition of Precautionary Information
Indicates an imminently hazardous situation which, if not avoided, will result in death or
DANGER
serious injury.
Indicates a potentially hazardous situation which, if not avoided, could result in death or
WARNING
serious injury.
Indicates a potentially hazardous situation which, if not avoided, may result in minor or
Caution
moderate injury, or property damage.
WARNING
WARNING
WARNING
WARNING
WARNING
Caution
Do not touch the inside of the Inverter. Doing so may result in electric shock or
injury.
Wiring or inspection must be performed only after turning OFF the power sup-
ply, confirming that the CHARGE indicator (or status indicator) is OFF and
after waiting for the time specified on the front cover. Not doing so may result
in electrical shock.
Do not damage, pull on, apply stress to, place heavy objects on or pinch the
cables. Doing so may result in electrical shock.
Do not touch the rotating parts of the motor under operation. Doing so may
result in injury.
Do not modify the product. Doing so may result in injury or damage to the
product.
Do not store, install or operate the product in the following places. Doing so
may result in electrical shock, fire or damage to the product.
•
Locations subject to direct sunlight.
Locations subject to temperatures or humidity outside the range
•
specified in the specifications.
Locations subject to condensation as the result of severe changes in
•
temperature.
Locations subject to corrosive or flammable gasses.
•
Locations very close to combustable materials.
•
Locations subject to dust (especially iron dust) or salts.
•
Locations subject to exposure to water, oil or chemicals.
•
Locations subject to shock or vibrations.
•
General Precautions
i
