Page 1 User’s Guide User’s Guide User’s Guide User’s Guide User’s Guide Quantum PX720 Quantum PX720 6444601-08 A01...
Page 2 Quantum PX720 User’s Guide, 6444601-08 A01, July 2007, Made in USA. Quantum Corporation provides this publication “as is” without warranty of any kind, either express or implied, including but not limited to the implied warranties of merchantability or fitness for a particular purpose.
Page 3: Table Of Contents
Tape Drive and Media Analysis ..............20 Library Components ..................20 Cabinet ....................... 21 OCP......................23 CHM ......................25 Tape Drives....................27 Load Port and Magazines................ 28 Cross Link Mechanism (CLM)..............30 Getting Started ....................30 Quantum PX720 User’s Guide...
Page 4 Removing/Installing Removable Bin Packs ......... 83 Chapter 3 Quantum PX720 Remote Management Quantum PX720 Web Pages................87 Quantum PX720 Web Page Menu Items ..........87 Accessing PX720 Web Pages ..............90 Using the Quantum PX720 Web Pages..........91 Quick Status....................91...
Page 5 Date & Time..................... 143 Library ...................... 144 Partitions ....................149 Secure Key....................155 Utilities ......................165 Library ...................... 166 Selftests..................... 170 Barcode Tests................... 171 Logs......................173 System Tests .................... 177 Maintenance .................... 178 About ....................... 183 Logout......................184 Quantum PX720 User’s Guide...
Page 6 Appendix C Event Reporting Information Events ..................210 Warning Events ....................213 Critical Events....................214 Appendix D Regulatory Statements FCC Statement....................216 Japan Statement (VCCI) ................217 DEN-AN Notice (Japan Industry Canada Digital Apparatus) ....217 Quantum PX720 User’s Guide...
Page 7 Notice for USA and CANADA Only ............218 Cette remarque ne concerne que les Etats-Unis et le Canada ....219 Battery Statement ................... 219 Electronic Waste, Recycling, and Disposal - WEEE........223 Declaration of Conformity................224 Glossary Index Quantum PX720 User’s Guide...
Page 8 Intermediate Level Capacity ............5 Figure 3 Full Capacity ................. 6 Figure 4 Slot Shelf Numbering, PX720 SDLT (Left Panels) ....10 Figure 5 Slot Shelf Numbering, PX720 SDLT (Right Panels) ....11 Figure 6 Slot Shelf Numbering, PX720 SDLT (Back Slots)....12 Figure 7 Slot Shelf Numbering, PX720 LTO (Left Panels) ....
Page 9 LTO Cleaning Cartridges ............47 Figure 29 Closing the Front Door .............. 48 Figure 30 Closing the Back Door ............... 49 Figure 31 PX720 Cabling Configuration........... 50 Figure 32 Turning On the Library ............. 52 Figure 33 OCP Main Screen................ 54 Figure 34 OCP Components...............
Page 10 Figure 48 Installing the Removable Bin Packs......... 85 Figure 49 Quantum PX720 Web Page Menu Items......... 88 Figure 50 Quantum PX720 Web Page Menu Items (Continued) ..89 Figure 51 Quantum Tape Security Menus ..........89 Figure 52 Overview Page................90 Figure 53 Activity Area ................
Page 11 Utilities Page ................166 Figure 100 Library Page ................167 Figure 101 Selftests Page................171 Figure 102 Barcode Tests Page..............172 Figure 103 Logs Page................... 174 Figure 104 System Tests Page ..............177 Figure 105 Maintenance Page ..............179 Quantum PX720 User’s Guide...
Page 12 Figure 108 Tape Drive LEDs ..............192 Figure 109 Shipping Restraints - Storage Location ......... 204 Figure 110 Installing the Robotic Shipping Restraint ......205 Figure 111 Installing the Counterweight..........206 Figure 112 Crating the Library..............208 Quantum PX720 User’s Guide...
Page 13 Table 12 Attention Messages..............56 Table 13 Partitions Details ................ 65 Table 14 Load Port Details................ 74 Table 15 Device Options ................76 Table 16 Tape Drive Details..............77 Table 17 Move Media Options ..............79 Quantum PX720 User’s Guide xiii...
Page 14 Tape Drive LED Conditions (SDLT and LTO)..... 190 Table 40 Physical Characteristics ............194 Table 41 Interfaces..................194 Table 42 Performance Characteristics ........... 195 Table 43 Reliability Characteristics............195 Table 44 Environmental Specifications ..........195 Table 45 Electromagnetic Interference/ Electromagnetic Compatibility ................197 Quantum PX720 User’s Guide...
Page 15 Tables Table 46 Information Events..............211 Table 47 Warning Events ................ 213 Table 48 Critical Events ................214 Quantum PX720 User’s Guide...
Page 16: Preface
Preface This manual introduces the Quantum PX720 library and discusses: • Library operations • Configuration • Relocation • Basic troubleshooting Audience This manual is written for library operators and field service engineers. Purpose This document provides information about the PX720 including: •...
Page 17 • Chapter 4, Troubleshooting discusses problems you may encounter during the setup and operation of the PX720 library. • The Appendixes provide library specifications, relocation and repacking instructions, automatic drive cleaning instructions, laser regulations, regulatory statements, and event reporting.
Page 18 S — hexadecimal sense key value AA — hexadecimal additional sense code QQ — hexadecimal additional sense code qualifiers Related Documents The following Quantum documents are also available for the Quantum PX720 library: Document Document No. Document Title Description...
Page 19 Contacts Quantum company contacts are listed below. Quantum Corporate Headquarters To order documentation on the PX720 Series or other products contact: Quantum Corporation P.O. Box 57100 Irvine, CA 92619-7100 (949) 856-7800 (800) 284-5101 Technical Publications To comment on existing documentation send e-mail to: doc-comments@quantum.com...
Page 20: Storagecare Guardian
StorageCare Guardian enables Quantum to proactively monitor the health of Quantum products, use diagnostic data to predict possible failures, and determine whether or not the problem involves a Quantum product or other critical component in the environment. Benefits gives the customer added assurance that Quantum...
Page 21 StorageCare Guardian allows Quantum to: • Monitor diagnostic data related to Quantum products • Receive alarms that notify Quantum of issues at the customer site • Run diagnostic utilities to more quickly determine the root cause of issues •...
Page 22 StorageCare Guardian provides information and updates to the Quantum Enterprise Server that resides at Quantum Support. 4 If an error or problem is detected, Quantum queues a request to the agent for data collection or real-time access to StorageCare Guardian the system.
Page 23 StorageCare Guardian Quantum PX720 User’s Guide xxiii...
Page 24: Chapter 1 Library Description
Chapter 1 Library Description This chapter describes both the Quantum PX720 and its components. The chapter consists of: • Overview • Features and Benefits • DLTSage™ Tape Security • Mixed Media Support • SMI-S Support • Library Components • Cabinet •...
Page 25 Chapter 1 Library Description Overview Overview The PX720 library revolutionizes how IT professional meet demanding requirements by providing reliability for maximum up-time, flexible architecture for investment protection, and scalability for fast data growth environments. All this coupled with superior price/performance by providing installation, Web-based management and full redundancy ™...
Page 26: Capacity On Demand (Cod)
All levels of capacity on demand do NOT include the available Note: bins located on the back wall of the PX720 library. The back wall bins will increase the overall number of bins in the library. Available upgrades include: Entry to Intermediate level, Entry to Full level, and Intermediate to Full level.
Page 27: Figure 1 Entry Level Capacity
Entry level capacity configuration Left-hand panels Right-hand panels Intermediate Level Capacity The intermediate level capacity PX720 (see figure 2) allows cartridge slots to be accessed from bin panels one through four. Available Slots (with Drive Type removable load ports) SDLT Quantum PX720 User’s Guide...
Page 28: Figure 2 Intermediate Level Capacity
Panels 5 and 6 are unavailable in the Intermediate level capacity Left-hand panels Right-hand panels Full Capacity The full capacity PX720 (see figure 3) allows cartridge slots to be accessed from all six bin panels. Available Slots (with Drive Type removable load ports) SDLT Quantum PX720 User’s Guide...
Page 29: Figure 3 Full Capacity
Chapter 1 Library Description Overview Available Slots (with Drive Type removable load ports) Figure 3 Full Capacity Full capacity allows cartridge slots to be accessed from all panels Left-hand panels Right-hand panels Quantum PX720 User’s Guide...
Page 30: Library Models
9 for bin panel locations). Tape Drive Types The Quantum PX720 can be configured with up to 20 tape drives and up to 648 SDLT or 732 LTO tape cartridges slots. Table 1 SDLT320 Quantum PX720 SDLT Model (drives/slots)
Page 31: Shelf Slot Numbering Conventions
Both with and without card cage storage elements are reflected in the following tables. Quantum PX720 SDLT Model The Quantum PX720 SDLT model stores cartridges in the following locations: • Up to 20 tape drives • 648 storage slots on interior walls (see table •...
Page 32: Table 7 Storage Elements (Sdlt)
With Cardcage 9-12 13-16 17-20 Figure figure 5, and figure 6 show the storage slot, load port slot, and tape drive numbering conventions. These conventions are used by the library GUI and the diagnostic software program. Quantum PX720 User’s Guide...
Page 33: Figure 4 Slot Shelf Numbering, Px720 Sdlt (Left Panels)
Chapter 1 Library Description Overview Figure 4 Slot Shelf Numbering, PX720 SDLT (Left Panels) Load port enabled Load port disabled 0000 0016 0032 0048 0064 0080 0000 0016 0032 0048 0064 0080 0001 0017 0033 0049 0065 0081 0001 0017...
Page 34: Figure 5 Slot Shelf Numbering, Px720 Sdlt (Right Panels)
Chapter 1 Library Description Overview Figure 5 Slot Shelf Numbering, PX720 SDLT (Right Panels) Load port enabled Load port disabled 0274 0290 0306 0322 0338 0354 0290 0306 0322 0338 0354 0370 0275 0291 0307 0323 0339 0355 0291 0307...
Page 35: Figure 6 Slot Shelf Numbering, Px720 Sdlt (Back Slots)
CLM is present in the library. Quantum PX720 LTO Model The Quantum PX720 LTO model stores cartridges in the following locations: • Up to 20 tape drives • 732 storage slots on interior walls (see table •...
Page 36: Table 8 Storage Elements (Lto)
With Cardcage 9-12 13-16 17-20 Figure figure 8, and figure 9 show the storage slot, load port slot, and tape drive numbering conventions. These conventions are used by the library GUI and the diagnostic software program Quantum PX720 User’s Guide...
Page 37: Figure 7 Slot Shelf Numbering, Px720 Lto (Left Panels)
Chapter 1 Library Description Overview Figure 7 Slot Shelf Numbering, PX720 LTO (Left Panels) Load port enabled Load port disabled 0000 0018 0036 0054 0072 0090 0000 0018 0036 0054 0072 0090 0001 0019 0037 0055 0073 0091 0001 0019...
Page 38: Figure 8 Slot Shelf Numbering, Px720 Lto (Right Panels)
Chapter 1 Library Description Overview Figure 8 Slot Shelf Numbering, PX720 LTO (Right Panels) Load port enabled Load port disabled 0324 0342 0360 0378 0396 0414 0306 0324 0342 0360 0378 0396 0325 0343 0361 0379 0397 0415 0307 0325...
Page 39: Sliding Out The Slot Panels
Chapter 1 Library Description Overview Figure 9 Slot Shelf Numbering, 0655 0648 0649 0656 PX720 LTO (Back Slots) Removed if card 0650 0657 0651 0658 cage is present 0659 0652 0660 0653 0654 0661 0662 0669 0670 0663 0664 0671...
Page 40: Features And Benefits
Middle slot panel latch Lower slot panel latch Features and Benefits The Quantum PX720 provides the following features and benefits: • High-capacity, high-performance data storage and retrieval • The library may house up to: • 648 SDLT tape cartridges and 20 SDLT tape drives •...
Page 41 Easy access and replacement of critical components • A user-friendly OCP (operator control panel) provides a wide range of configuration and service-related functions • Web based management system provides the ability to remotely access the library status and administer library functions Quantum PX720 User’s Guide...
Page 42: Dltsage™ Tape Security
PX720 tape library (firmware revision 4.5 or later). Mixed Media Support The PX720 tape library is capable of supporting mixed media in the same library (SDLT and LTO media) tape drives and media in the same library frame.
Page 43: Tape Drive And Media Analysis
Tape Drive and Media Analysis Tape Drive and Media Analysis The PX720 library provides the ability to proactively monitor tape drive and media health by continuously tracking dozens of critical tape drive and media performance parameters. If a critical operating parameter...
Page 44: Cabinet
• An OCP in the center of the cabinet enables you to monitor and control library operations • Power button located under the service tray (older libraries may have plastic molded doors and newer libraries have metal molded doors) Quantum PX720 User’s Guide...
Page 45: Figure 11 Px720 Cabinet-Front View
Chapter 1 Library Description Library Components Figure 11 PX720 Cabinet-Front View PX720 plastic PX720 metal molded door molded door (older libraries) (new libraries) Door latch Power button Door latch Power button Service tray • Two configurable load ports with either 16 SDLT or 18 LTO cartridge...
Page 46: Ocp
• AC power distribution box. The top plug is reserved for the cross link mechanism (CLM) used to connect multiple cabinets. Power connectors and breaker switches are located on the front of the unit. Figure 12 PX720 Cabinet-Back Panels Power supplies...
Page 47: Table 9 Ocp Features
READY state. The library will be NOT READY during power-on self-tests, when magazines are being released, or during access to certain menu items. • Both LEDs flash when there is a library fault that requires operator attention. Quantum PX720 User’s Guide...
Page 48: Chm
Chapter 1 Library Description Library Components Figure 13 OCP—Initial Screen Green buttons The CHM consists of the following components: • CHM (Cartridge handling mechanism) • Vertical carriage assembly • Horizontal drive motor • Extension axis assembly Quantum PX720 User’s Guide...
Page 49: Figure 14 Chm (Cartridge Handling Mechanism)
An inventory can also be initiated from the host computer. Although the library does not require tape cartridges to have barcode labels, properly labeled tape cartridges and full storage slots speed up the inventory process. Quantum PX720 User’s Guide...
Page 50: Tape Drives
Gen IV * Compressed capacity assumes a 2:1 compression ratio. When fewer than 20 drives are installed in a Quantum PX720, the tape drives must occupy consecutive drive clusters, beginning with drive cluster 0 (refer to the label located on the inside of the back door for tape drive cluster locations).
Page 51: Load Port And Magazines
Achten Sie darauf, dass Sie mit Ihren Fingern oder Warning: anderen Körperteilen nicht zu nahe an die Türen des Ladeports gelangen, wenn diese offen sind. Die Stopp-Taste befindet sich auf der Bediener- Systemsteuerung, falls die Roboter in einem Notfall angehalten werden müssen. Quantum PX720 User’s Guide...
Page 52: Figure 15 Left Load Port Bin Packs
(8 bins per pack) Figure 16 Right Load Port Bin Fixed bin packs Packs (8-SDLT, 9-LTO-2 bins per pack) SDLT removable bin packs (7 bins per pack) LTO removable bin packs (8 bins per pack) Quantum PX720 User’s Guide...
Page 53: Cross Link Mechanism (Clm)
Chapter 1 Library Description Getting Started Cross Link Mechanism The Quantum PX720 cross link mechanism (CLM) allows you to connect (CLM) up to five libraries together and allow multiple libraries to appear as one to the host system. If a CLM is installed in the library, the CLM and all...
Page 54: Cabling The Quantum Px720
After the Quantum PX720 is in its final location, the tape drives and PX720 robotics controller must be connected to the backup host system(s). To cable the Quantum PX720: 1 Open the back door of the Quantum PX720 to gain access to the tape drives and robotics controller (see figure 17).
Page 55: Figure 17 Tape Drives And Robotics Controller
3 Connect the host computers to the tape drives by routing SCSI cables up through the base of the library and along the right-hand side of the cabinet (see figure 18). Tech Tip: Start cabling with drive cluster 0 at the top of the library and work down. Quantum PX720 User’s Guide...
Page 56: Figure 18 Connecting The Tape Drives
Host computers Cluster with 1 tape drives Terminators per bus Terminators Host computers Terminators SCSI cables Host computers Make sure that all SCSI cables droop down slightly to Note: ensure that the back door closes. Quantum PX720 User’s Guide...
Page 57: Loading The Tape Cartridges
SDLT) into the library starting with the left-hand panels (see Shelf Slot Numbering Conventions on page 8 for slot locations). The Quantum PX720 must be initially configured with an IP address Initial Configuration before the remote management software is available. To configure the Quantum PX720 IP address:...
Page 58: Figure 20 Turning On The Library
Power button Door latch Power button Service tray 2 When the library completes the boot up sequence and the OCP is active, press from the screen. Menu Home The OCP displays the screen (see figure 21): Menu Quantum PX720 User’s Guide...
Page 59: Figure 21 Menu Screen
Chapter 1 Library Description Getting Started Figure 21 Menu Screen Select 3 From the screen, use the up and down arrows to highlight Menu and press Setup Select 4 The library prompts you for your password (see figure 22). Quantum PX720 User’s Guide...
Page 60: Figure 22 Password Screen
Chapter 1 Library Description Getting Started Figure 22 Password Screen 5 Enter the 6 digit password. The password is accepted after the sixth digit is entered. Note: The default password is 001122. screen displays (see figure 23): Setup Quantum PX720 User’s Guide...
Page 61: Figure 23 Setup Screen
Restore Factory Settings • Drive Autoclean (default disabled) • Drive Autounload (default disabled) • Configured Drives • Configured Slots • Left Load Port (16) (default enabled) • Right Load Port (32) (default enabled) • Service Mode Quantum PX720 User’s Guide...
Page 62 10 Use the up and down arrows to select the reboot option and press Select The library reboots. The library is now ready for operation. For more information on Quantum PX720 remote management, see chapter 3 on page 86. Quantum PX720 User’s Guide...
Page 63: Chapter 2 Basic Library Operations
3 Place cartridges (right side up) in the fixed slots. Caution: Placing the cartridges in the bins upside down can cause damage to the library (see figure 25 for SDLT cartridges and figure 26 for LTO cartridges). Quantum PX720 User’s Guide...
Page 64: Taking Esd Precautions
Rough handling can displace the tape leader, making the cartridge unusable and potentially hazardous to the tape drives. Components within the PX720 contain static-sensitive parts. To prevent Taking ESD Precautions damage to these parts while performing installation, maintenance, or replacement procedures, observe the following precautions: •...
Page 65: Sdlt Cartridges
Do not use older barcode labels on tape cartridges for newer drive types. Labeling The PX720 is a multi-media library, meaning multiple drive and tape cartridge types can be present in a single library. Barcode labels are attached to each tape cartridge to differentiate the different tape cartridge types (SDLT, LTO, and cleaning cartridges).
Page 66: Figure 24 Inserting A Barcode Label (Sdlt)
Set the write-protect switch to protected archiving tape cartridges. Proper Insertion Orientation Refer to figure 25 for proper label placement, write protection settings and insertion orientation. Quantum PX720 User’s Guide...
Page 67: Lto Cartridges
Do not use older barcode labels on tape cartridges for newer drive types. The PX720 is a multi-media library, meaning multiple drive and tape cartridge types can be present in a single library. Barcode labels are attached to each tape cartridge to differentiate the different tape cartridge types (SDLT, LTO, and cleaning cartridges).
Page 68: Figure 26 Lto Cartridges
Caution: LTO tape drive media cannot be degaussed due to the fact that it uses "magnetic servos." Do not attempt to degauss LTO tape drive media. If this media is degaussed, it will no longer work. Quantum PX720 User’s Guide...
Page 69: Cleaning Cartridges
27 for SDLT and figure 28 for LTO). • SDLT cleaning cartridge labels are in the following format: CLN###S# • LTO cleaning cartridge tables are in the following format: CLN###L# Figure 27 SDLT Cleaning Cartridges Quantum PX720 User’s Guide...
Page 70: Placing Tape Cartridges In The Cabinet
Preparing the Cabinet for Operation To prepare the cabinet for operation: • Close the Cabinet Doors and Access Panels • Connecting Host Workstations Quantum PX720 User’s Guide...
Page 71: Close The Cabinet Doors And Access Panels
Chapter 2 Basic Library Operations Preparing the Cabinet for Operation Close the Cabinet Doors The PX720 has one front door and one back door. and Access Panels 1 Close and lock the front door using the key provided in the accessory...
Page 72: Connecting Host Workstations
Connecting Host Connect the SCSI cables and jumpers as shown in the following figure. Workstations Quantum ships sufficient SCSI cables and terminators with Note: this cabinet to set up two-drives per SCSI bus. The cabinet controller SCSI HBA (media changer) can be included with one of the two drive connections or directly connected to the host.
Page 73: Figure 31 Px720 Cabling Configuration
Chapter 2 Basic Library Operations Preparing the Cabinet for Operation Figure 31 PX720 Cabling Configuration Host computers Cluster with 2 tape drives per bus Host computers Cluster with 1 tape drives Terminators per bus Terminators Host computers Terminators SCSI cables...
Page 74: Turning The Library On And Off
2 Turn on the power switch located behind the laptop tray (see figure 32). During the power up sequence, the power button blinks while the library performs an inventory. The power up sequence can take several minutes. Quantum PX720 User’s Guide...
Page 75: Placing The Library On-Line Or Off-Line
Operations Screen on page 74. Operations To turn off the library: Turning Off the Library 1 Place the library off-line, see Placing the Library On-line or Off-line. The library robotics completes any current commands and then stops. Quantum PX720 User’s Guide...
Page 76: Using The Ocp (Operator Control Panel)
The first screen the OCP displays after library initialization is the main Home Screen screen. This screen displays library status and provides information on the number of tape drives, slots, and library name (see figure 33). Quantum PX720 User’s Guide...
Page 77: Ocp Buttons
Note: If the date and time is modified from the remote management pages (see Quantum PX720 Remote Management on page 86), the date and time on the OCP main screen may take up to three minutes to update with the new information.
Page 78: Table 11 Library Status Information
Latest Cluster FPGA Revision is ” message, the tape drive cluster FPGA software Required revision does not meet the minimum requirement for the tape drive. Contact Quantum customer support for information on updating the tape drive cluster controller software. Table 11 Library Status Information...
Page 79: Table 12 Attention Messages
The cabinet robot has stopped. Door Open The cabinet front door is open. Slow Mode The cabinet robot is operating in slow mode. Operating in slow mode is only possible when the door sensors have been disabled. Quantum PX720 User’s Guide...
Page 80: Ocp Components
A diagnostic test is running (system test or self-test). Sift Sorting A Sift Sort export is running. OCP Components The OCP allows the user to perform various functions on the Quantum PX720. Figure 34 provides a list of the OCP functionality available from screen.
Page 81: Figure 34 Ocp Components
Save Settings Left Load Port Connection Type Connection Type Change Password Right Load Port Restore Factory... Serial Number Serial Number Drive Autoclean Drive Autounload Barcoad Length Service Information Event Log * indicates components that require additional hardware. Quantum PX720 User’s Guide...
Page 82: Menu Screen
Chapter 2 Basic Library Operations OCP Components The following sections provide information on each function available from the Quantum PX720 OCP: • Menu Screen • Load Ports Screen • Operations Screen • Diagnostics Screen • Stop Button screen provides access to contact information, cabinet...
Page 83: Figure 36 Library Screen
† menu item only available with the library partitioning option installed. Library Information To view library information: 1 From the screen, use the up and down arrows to highlight Menu and press Library Select screen displays (see figure 36): Library Figure 36 Library Screen Back Quantum PX720 User’s Guide...
Page 84: Figure
Contact Info - customer contact information • Contact number - customer service contract number used to identify the library to Quantum customer support • Software - software version currently loaded on the library including the cabinet controller and cabinet robotics •...
Page 85: Figure 37 Cabinet Screen
Drives — number of drives configured in the cabinet for the specific drive type • Ports— number of load port slots configured in the cabinet for the specific drive type 2 When you are finished viewing cabinet information, press Back return to the screen. Menu Quantum PX720 User’s Guide...
Page 86: Figure 38 Health Status Screen
(see figure 38): Health Status Figure 38 Health Status Screen Back screen displays the current library health. Health Status When you are finished viewing health status information, press Back return to the screen. Menu Quantum PX720 User’s Guide...
Page 87: Figure 39 Partitions Screen
Partitions Figure 39 Partitions Screen Select 2 From the screen, use the up and down arrows to highlight a Partitions specific partition and press to view the partition details. Select displays (see figure 40): Partition Details Quantum PX720 User’s Guide...
Page 88: Figure 40 Partitions Details
Displays the IEEE ID of the partition. State Displays the library state (online/offline). Slot start Displays the starting slot address for the addr partition. Slot start Displays the physical starting slot address phys idx for the partition. Quantum PX720 User’s Guide...
Page 89: Figure
Port start Displays the starting load port slot addr address in the partition. Port start Displays the physical starting load port phys idx slot address. Total ports Displays the total load port count in the partition. Quantum PX720 User’s Guide...
Page 90: Quantum Px720 User's Guide
Displays the current autoclean status state (active/idle). Drive clean Displays the number of drive clean attempts attempts in the partition. Emulation Displays the current library emulation (quantum/ATL P7000). Setup Information/Options To view or edit the setup information: Quantum PX720 User’s Guide...
Page 91: Figure 41 Setup Screen
If partitioning is enabled on this library, all setup options Note: other than Change Network Settings Change Password are moved to the Restore Factory Settings Partitioning options OCP screen (see table 13 on page 65). • Change Network Settings Quantum PX720 User’s Guide...
Page 92: Figure
Left Load Port (default enabled) • Right Load Port (default enabled) 3 To set the network information, use the up and down arrows to select and press Change Network Settings Select screen displays (see figure 42): Change Network Settings Quantum PX720 User’s Guide...
Page 93: Figure 42 Change Network Settings Screen
6-digit password using the numbers provided on the OCP. Press to accept the new password. When prompted, Select re-enter the password to confirm. • To restore the factory defaults, use the up and down arrows to select Restore Factory Defaults and press Select Quantum PX720 User’s Guide...
Page 94: Figure
For the network information, tape drive configuration, and number of slots to be active, the library must reboot. Service Information/Options The Service Information screen is used by Customer Service only. Event Log Information To view the event log: Quantum PX720 User’s Guide...
Page 95: Load Ports Screen
Die Stopp-Taste befindet sich auf der Bediener- Systemsteuerung, falls die Roboter in einem Notfall angehalten werden müssen. To access the screen, press from the screen. The Load Ports Ports Home OCP displays the screen (see figure 43): Load Ports Quantum PX720 User’s Guide...
Page 96: Figure 43 Load Ports Screen
Press to open the load port. To view the load port details, use the up and down buttons to select and then press Details Select The following load port details are available (see table 14): Quantum PX720 User’s Guide...
Page 97: Operations Screen
Operations Operations Screen commands to the cabinet and tape drives. To access the screen, press from the screen. The Operations Home OCP displays the screen (see figure 44): Operations Quantum PX720 User’s Guide...
Page 98: Figure 44 Operations Screen
Figure 44 Operations Screen Select 1 To change the status of the cabinet or tape drive(s), use the up and down arrows to highlight the specific device and press Select The following device options are available (see table 15): Quantum PX720 User’s Guide...
Page 99: Table 15 Device Options
A reboot shuts down the CLM and re initializes the system. The CLM will be temporarily unavailable to accept host commands until the cabinet is online. Details Displays the CLM system details. Move table 17 on page 79. Media Quantum PX720 User’s Guide...
Page 100: Table 16 Tape Drive Details
Table 16 Tape Drive Details Tape Drive Details Description Media This option displays the barcode label if present. Present Is there a tape drive present in drive bay? (yes/no) Configured Is the tape drive configured with SCSI ID? (yes/ Quantum PX720 User’s Guide...
Page 101: Quantum Px720 User's Guide
Displays the tape drive ADI status if the tape drive is ADI capable (yes/no). Sense Codes Displays any sense code information for this tape drive. Additional Displays any additional sense information for this Sense tape drive. Information Quantum PX720 User’s Guide...
Page 102: Figure 45 Move Media Screen
Table 17 Move Media Options Move Media Options Description Addressing Logical or physical addressing. Source † Cabinet number in a CLM environment that contains the source element. Source Type The source types can be a slot, drive, or load port. Quantum PX720 User’s Guide...
Page 103: Diagnostics Screen
Menu screen allows the user perform diagnostic test on the Diagnostics Diagnostics Screen library. To access the screen, press from the screen. The Diagnostics Diags Home OCP displays the screen (see figure 46): Diagnostics Quantum PX720 User’s Guide...
Page 104: Figure 46 Diagnostics Screen
Read Cabinet Serial Number • Read Cabinet IEEE ID • Read Cabinet Type • Sequential Slot Test • Sequential Drive Test • Random Test • Random Slot Test • Random Slot to Drive • Element to Element Quantum PX720 User’s Guide...
Page 105: Stop Button
To insert a tape cartridge into a magazine: 1 Prepare the tape cartridges to be inserted by affixing a barcode label and write-protecting or write-enabling each cartridge as desired. For more information about these procedures, refer to Inserting Tape Cartridges on page 40. Quantum PX720 User’s Guide...
Page 106: Removing/Installing Removable Bin Packs
You will hear a “click” when it locks into position. Removing/Installing Both the left and right load ports on the front of the PX720 can have either Removable Bin Packs fixed or removable bin packs. These bin packs can support both SDLT...
Page 107: Figure 47 Removing The Bin Packs
The bin pack handle can be used to lift the bin pack out of the library. 2 To install the removable bin packs, place the base of the bin back into the bin panel and snap into place as shown in figure Quantum PX720 User’s Guide...
Page 108: Figure 48 Installing The Removable Bin Packs
Chapter 2 Basic Library Operations Inserting Tape Cartridges into the Load Port Figure 48 Installing the Removable Bin Packs Quantum PX720 User’s Guide...
Page 109: Quantum Px720 Remote Management
Chapter 3 Quantum PX720 Remote Management The Quantum PX720 utilizes a web-based interface which allows you to configure and manage the Quantum PX720 from a remote workstation on the same network. The Quantum PX720 is managed through the following web pages (accessible using Internet browser software installed on the host computer): •...
Page 110: Quantum Px720 Web Pages
Chapter 3 Quantum PX720 Remote Management Quantum PX720 Web Pages Quantum PX720 Web Pages The internet browser software is not supplied with the Quantum PX720; you must obtain and install it independently. The Quantum PX720 supports the following internet browsers: •...
Page 111: Figure 49 Quantum Px720 Web Page Menu Items
Chapter 3 Quantum PX720 Remote Management Quantum PX720 Web Pages Figure 49 Quantum PX720 Web Page Menu Items Status Operations Setup Utilities Status - cont. Setup - Cont. Setup - Cont. Overview Tape Alert Find Identification Network Library Library Library Information...
Page 112: Figure 50 Quantum Px720 Web Page Menu Items (Continued)
Chapter 3 Quantum PX720 Remote Management Quantum PX720 Web Pages Figure 50 Quantum PX720 About Logout Web Page Menu Items (Continued) About Library Information Model Software Version Serial Number IEEE ID Slots Load Ports Drives Links Figure 51 Quantum Tape...
Page 113: Accessing Px720 Web
Chapter 3 Quantum PX720 Remote Management Quantum PX720 Web Pages Accessing PX720 Web To access the Quantum PX720 web pages: Pages 1 On the host computer, open the internet browser software. 2 In the field, type http://IPaddress/ where IP address is the IP Address address for the Quantum PX720.
Page 114: Using The Quantum Px720 Web
• Security Settings The banner frame displays the corporate logo and product name. The contents frame displays a list of the Quantum PX720 web pages. To view a page, click its corresponding link. The management frame displays the page you selected.
Page 115: Table 20 Quick Status Health Messages
Chapter 3 Quantum PX720 Remote Management Quantum PX720 Web Pages Quick Status Icon Library Health Description Library health: The library health is in a state Warning Warning (may need attention) Library health: The library health is in a state Critical...
Page 116: Activity Area
Chapter 3 Quantum PX720 Remote Management Quantum PX720 Web Pages Quick Status Messages Description The CHM (cartridge handling Stopped mechanism) has stopped. Check the error log and contact Quantum Customer Support if necessary. A library door (front) is open. Door Open...
Page 117: Cross Link Mechanism (Clm)
Activate • Excessive # of bad blocks on Smart Media Cross Link Mechanism The Quantum PX720 cross link mechanism (CLM) allows you to connect (CLM) up to five libraries together and allow them to appear as one library to the host system.
Page 118: Browser Options
Chapter 3 Quantum PX720 Remote Management Quantum PX720 Web Pages Table 21 CLM Information The cabinet designated as the “Master” contains the CLM electronics and controlls the other attached “Slave” libraries. The status information for each cabinet (master and slave) is displayed in the respective cabinet page.
Page 119: Security Settings
Operator settings, but cannot modify the settings. If the PX720 remote management pages are inactive for more than 5 Session Timeout minutes, the session will time out and you will be required to log back...
Page 120: Status
Chapter 3 Quantum PX720 Remote Management Status Figure 56 Session Timeout Screen Status page displays the general status or health of the library as well Status as specific hardware status. The page also provides access to event logs as well as library statistics.
Page 121: Event Log Page
Chapter 3 Quantum PX720 Remote Management Status Figure 57 Status Page page allows the user to view events that occur on the Event Log Event Log Page library. These events are divided into the following categories: • All categories - views all events in all categories •...
Page 122: Figure 58 Event Log Page
Chapter 3 Quantum PX720 Remote Management Status Figure 58 Event Log Page To view an Event Log 1 In the page, change the areas to reflect the Event Log From time range of the event log you wish to view. Click the up and down arrows to change the hour and/or minute values by increments of one.
Page 123: Statistics Page
Chapter 3 Quantum PX720 Remote Management Status 4 Click to save the event information to a local destination. Save As... Use the button to email the event list or event detail to one or Send... more recipients. 5 Click on an event summary to open another window containing details about the particular event.
Page 124: Quantum Px720 User's Guide
Chapter 3 Quantum PX720 Remote Management Status Cabinet or Component Statistical Information Cabinet (library) Time since last power-on (seconds) Time processing robot commands (seconds) Estimated number of power cycles Attempted slot/port picks Attempted slot/port places Attempted drive picks Attempted drive places...
Page 125: Quantum Px720 User's Guide
Chapter 3 Quantum PX720 Remote Management Status Cabinet or Component Statistical Information Number of extension retries Number of gripper retries Number of depth retries Number of rotary retries Number of drive place retries Number of drive pick retries Number of partially gripped cartridge...
Page 126: Tape Alert Page
Chapter 3 Quantum PX720 Remote Management Status Figure 59 Statistics Page Statistics for individual elements (a specific drive, slot, or Note: port) are included in the element detail window and can be viewed by clicking on a drive, slot, or port link from zoom windows accessed via the pages.
Page 127: Figure 60 Tape Alert Page
Chapter 3 Quantum PX720 Remote Management Status Figure 60 Tape Alert Page Refresh tape alert data Display filters Tape alert flags Barcode with tape alerts Drives with Tape Alerts pages is divided into the following sections: Tape Alert • Refresh Tape Alert Data •...
Page 128: Quantum Px720 User's Guide
Chapter 3 Quantum PX720 Remote Management Status Refresh Tape Alert Data The tape alerts data is generated and stored internally for quick reporting and viewing. If the data files do not exist (i.e. factory default), they will be generated automatically. To update the files, click...
Page 129: Error Status Page
Chapter 3 Quantum PX720 Remote Management Status Details Upon clicking for a , or , a new View Details Tape Alert Flag Barcode Drive window is displayed listing all tape alerts, barcodes, or drive associations. Clicking on an associated tape alert, barcode, or drive from the resulting window will display all events for that tape alert.
Page 130: Cabinet Page
Chapter 3 Quantum PX720 Remote Management Status Click to save the error status information to a local Save As... destination. Use the button to email the error status Send... information to one or more recipients. Note: page can be accessed from any page by...
Page 131: Clm (If Installed)
Chapter 3 Quantum PX720 Remote Management Status condition and may require user attention. Related values or error messages are listed under details. To view the status of a library component: 1 Click to expand or collapse all branches. Expand All/Collapse All...
Page 132: Operations
Chapter 3 Quantum PX720 Remote Management Operations Click to save the CLM status information to a local destination. Save As... Use the button to email the hardware status information to one or Send... more recipients. Operations page is divided into the following sections: Operations •...
Page 133: Accessing The Operations Page
Chapter 3 Quantum PX720 Remote Management Operations Accessing the To access the page, click from the contents frame. Operations Operations Operations Page The management frame displays the page (see figure 64). Operations Figure 64 Operations Page page allows the user to find and locate specific barcodes within...
Page 134: Figure 65 Find Page
Chapter 3 Quantum PX720 Remote Management Operations Figure 65 Find Page Find barcode Show contents Select physical/logical page is divided into the following sections: Find • Find Barcode • Show Contents • Select Map • Partition Layout • Show Grippers...
Page 135: Quantum Px720 User's Guide
Chapter 3 Quantum PX720 Remote Management Operations 2 Click Find A separate window displays the barcode(s) sharing the barcode string entered in the barcode field and it’s location within the library. Click the individual barcode label to display the corresponding cartridge detail page.
Page 136: Figure 66 Physical Map
Chapter 3 Quantum PX720 Remote Management Operations (i.e. similar to pulling out a loadport or drawer) displaying all elements (slots, ports, or drives) in a spreadsheet format. Note: The physical map shows gaps in the element addressing depending on the load port configuration.
Page 137: Quantum Px720 User's Guide
Chapter 3 Quantum PX720 Remote Management Operations view of the panel (i.e. similar to pulling out a loadport or drawer) displaying all elements (slots, ports, or drives) belonging to the partition in a spreadsheet format. From the zoom view, clicking on an element opens a detail window.
Page 138: Figure 67 Logical Map
Chapter 3 Quantum PX720 Remote Management Operations Figure 67 Logical Map Unassigned partition First partition Second partition Quantum PX720 User’s Guide...
Page 139: Move Page
Chapter 3 Quantum PX720 Remote Management Operations Partition Layout The partition layout displays a map of all elements within the library color coded to designate the partitions (see Partition Layout on page 151). Show Grippers Click this link to list all available grippers and their contents including a “virtual”...
Page 140: Figure 68 Move Page
Chapter 3 Quantum PX720 Remote Management Operations Figure 68 Move Page Move cartridge Source Destination To move a cartridge: 1 Select a source cabinet (or partition), source element (slot, port, drive, or address), and enter a starting position and count. If the count field is left empty, only the starting cartridge is moved.
Page 141: Inventory Page
Chapter 3 Quantum PX720 Remote Management Operations 3 Click to perform the move. The progress of the move displays Apply in a separate window. page allows the user to perform an inventory on all Inventory Inventory Page elements within the library or specific element ranges.
Page 142: Drives Page
Chapter 3 Quantum PX720 Remote Management Operations 2 Enter the starting position and count (range). Note: The edit boxes for the starting position and count are invisible until you select slot, port, drive, or address. If the starting position and count are left blank, all elements of the selected type will be inventoried.
Page 143: Sift Sort
Chapter 3 Quantum PX720 Remote Management Operations Figure 70 Drives Page Drive operations To perform an action on a tape drive(s) 1 Select a partition or cabinet, drive (or all drives), and a count. The count indicates the range of drives where the action is Note: performed.
Page 144: Figure 71 Sift Sort Page
Chapter 3 Quantum PX720 Remote Management Operations cartridge ID's, provides easier visualization of daily/weekly/monthly tapes, and enhances the library view from the remote management pages. To access the page, from the page, click on the Sift Sort Operations Sift tab at the top of the page.
Page 145: Quantum Px720 User's Guide
Chapter 3 Quantum PX720 Remote Management Operations 2 Select the destination for the sorted tape cartridges ( Partition Element , and Type Position Note: If the check box is checked and a destination Relocate Full element contains a cartridge, that cartridge will be relocated to an empty bin or port depending on the destination element selected.
Page 146: Setup
Chapter 3 Quantum PX720 Remote Management Setup Setup page is divided into the following sections: Setup • Identification • Users • Devices • Bridges - Only if a Fibre Channel bridge is present • Network • LDAP • Events •...
Page 147: Identification
Chapter 3 Quantum PX720 Remote Management Setup Figure 72 Setup Page The identification information is used to identify the library to assist Identification customer support when servicing the library. 1 To access the page, from the page, click on the...
Page 148: Users
Chapter 3 Quantum PX720 Remote Management Setup Field Description Enter the contract number for the library. This is Contract used to identify the library to customer support. Number* Customer internal tracking number. Asset Number Enter the location of the library. This helps to...
Page 149: Figure 73 Users Page
Chapter 3 Quantum PX720 Remote Management Setup Figure 73 Users Page 2 Edit the user information as desired (see table 25 for a description of the fields). 3 Click when complete. Save Table 25 User Information Field Description Enter the full name of the user...
Page 150: Quantum Px720 User's Guide
Chapter 3 Quantum PX720 Remote Management Setup Field Description There are three User Roles available: User Role • have access to all pages. Administrators • have access to all pages except the Operators pages under the , or Operations Setup Utilities tabs.
Page 151: Figure 74 Create Secure User
Chapter 3 Quantum PX720 Remote Management Setup When a user is created with administrator privileges (other than the default admin user), the section appears at the bottom Create Secure User of the page (see figure 74). Users Figure 74 Create Secure User...
Page 152: Devices
Chapter 3 Quantum PX720 Remote Management Setup Figure 75 Delete Secure User To update the secure key password: Note: Only the can change the secure user password. Secure User 1 Enter a secure password. must be alphanumeric strings of at least...
Page 153: Figure 76 Devices Page
Native Fibre Channel Tape Drives Native Fibre Channel tape drives such as the HP LTO-2/-3 and Quantum SDLT600/DLT-S4 can be directly connected to a Fibre Channel host or network without a SCSI to Fibre Channel bridge. When native Fibre...
Page 154: Figure 77 Native Fibre Channel Drive Configuration
Chapter 3 Quantum PX720 Remote Management Setup Channel tape drives are installed in the library, a link for Fibre appears in the connectivity type column that displays the drive configuration. To configure native Fibre Channel tape drive: 1 Under the page, click in the connectivity column.
Page 155: Bridges
Configured Speed Auto box and click Apply Note: 4G speed is only available on the Quantum DLT-S4 tape drive and the HP LTO-4 tape drive. The drive is configured. This section allows users to manage the FC470 Fibre Channel bridge(s) Bridges installed in the cabinet.
Page 156: Network
Chapter 3 Quantum PX720 Remote Management Setup The FC470 web interface displays. For more information on the FC470 Fibre Channel bridge and the web interface, see the Quantum FC470 User’s Guide Addendum (PN 6513505) included on the Quantum PX720 documentation CD.
Page 157: Figure 80 Network Page
2 Edit the network information as desired (see table 26 for a description of the fields). 3 Click Save The Quantum PX720 will not use the new network information until it has been rebooted. The button is available at the bottom of Reboot page. Network...
Page 158: Ldap
View or set the email server information Email Server View or set the DNS address DNS Address Indicates a required field. page allows the user to configure the PX720 library to utilize an LDAP LDAP LDAP server. (Lightweight Directory Access Protocol) provides the...
Page 159: Figure 81 Ldap Page
Chapter 3 Quantum PX720 Remote Management Setup Figure 81 LDAP Page 2 Edit the LDAP configuration information as desired (see table 27 for a description of the fields). Note: The local users database created in the setup tab and Users the LDAP users database created remotely on the LDAP server can be used at the same time.
Page 160: Quantum Px720 User's Guide
Chapter 3 Quantum PX720 Remote Management Setup Field Description Enter the LDAP server address. This address can Server Address be either an IP address or a host name. Enter the LDAP server port to be used. The Server Port default port is...
Page 161: Events
Chapter 3 Quantum PX720 Remote Management Setup Field Description Enter the operator group DN to allow access to Operator Group the system operator’s privileges. Name To test the LDAP server connectivity, click Send Send Test Test 3 When you have completed entering the LDAP configuration information, click Update.
Page 162: Figure 82 Events Page
Field Description When a hardware failure occurs on the Message Type: Quantum PX720 system such as a transition to Critical a degraded, limited access, or failed system state, an email is sent to everyone on the critical failure recipient list.
Page 163: Table 29 Send Email Test
SNMP If the customer wishes to use the Quantum PX720 system with a network framework application such as HP OpenView, or CA Unicenter, the SNMP configuration must be defined. SNMP stands for Simple Network...
Page 164: Quantum Px720 User's Guide
Name characters (a-z, A-Z), no special characters or blank spaces are allowed Caution: If no communities are defined, the Quantum PX720 is universally accessible through a “public” community (read-only). IP address in the field, if the value in the Network...
Page 165: Figure 83 Snmp Section Of Event Page
Chapter 3 Quantum PX720 Remote Management Setup Figure 83 SNMP Section of Event Page 4 Enable the trap selections to be reported (see table 30): Table 30 SNMP Trap Field Description Selections If selected, are enabled. Informational Informational Traps If selected, are enabled.
Page 166: Date & Time
The date and time page allows the user to view and set the date and time Date & Time on the library. This allows the library to time stamp any events that occur. The Quantum PX720 must be offline to adjust the time and Note: date.
Page 167: Library
Test NTP NTP Server. 3 Click when complete. Save The Quantum PX720 will not use the new date and time zone information until it has been rebooted. The button is available Reboot at the bottom of the page. The library configuration section allows the user to configure automatic Library library settings.
Page 168: Figure 85 Library Page
Chapter 3 Quantum PX720 Remote Management Setup Figure 85 Library Page 2 Edit the library settings (for each cabinet in a CLM configuration) as desired (see table 31 table 32 for a description of the fields) and click Apply If the partitioning option is enabled, the host configuration...
Page 169: Table 31 Library Configuration
Chapter 3 Quantum PX720 Remote Management Setup Table 31 Library Configuration Field Description When enabled, the library powers on in the offline Power-on Offline mode. When enabled, the library performs an inventory Online auto when the library is returned online.
Page 170: Quantum Px720 User's Guide
Chapter 3 Quantum PX720 Remote Management Setup Field Description Unload drives When enabled, the library will automatically send an unload command to the drive prior to the automatically application moving the cartridge back to a bin. Note: This option should be enabled if the application does not issue the unload command to the drive prior to sending the move command.
Page 171: Figure 86 Capacity Level
Enter the capacity level (Intermediate or Full) to enable in the option box and enter the Capacity Key to enable the slots. The Capacity Key is found either in an e-mail or letter from Quantum. Changing the capacity level causes the library to automatically reconfigured when you click...
Page 172: Partitions
Library partitioning requires the optional Quantum PX720 Library Partitioning Upgrade Kit to be installed in your library. To add this upgrade kit, please contact your Quantum Enterprise Storage Partner (reseller or VAR), your Quantum sales representative or Quantum Corporate at 1-800-677-6268 (or 949-856-7800 for international) or quantuminfo@quantum.com.
Page 173: Figure 87 Partitions Page
Chapter 3 Quantum PX720 Remote Management Setup Figure 87 Partitions Page page contains a list of all user defined partitions and a Partitions section for either creating a partition or changing a partition's configuration and options. Newly created or edited partitions are...
Page 174: Figure 88 Partition Details
Chapter 3 Quantum PX720 Remote Management Setup Figure 88 Partition Details Partition Layout The partition layout displays a map of all elements within the library color coded to designate the partitions. Quantum PX720 User’s Guide...
Page 175: Figure 89 Partition Layout
Chapter 3 Quantum PX720 Remote Management Setup To view the partition layout, click the link. Partition Layout Note: Use the link when creating or editing Partition Layout partitions. Click on any slot, port, or tape drive to open an element details window.
Page 176: Table 33 Creating A Partition
Chapter 3 Quantum PX720 Remote Management Setup Creating a Library Partition To create a library partition: Note: The library must be offline to create or edit a library partition. 1 Enter the partition information listed in table 33 and click create the partition.
Page 177: Quantum Px720 User's Guide
Chapter 3 Quantum PX720 Remote Management Setup Field Description Unload Drives Select this box to automatically unload the tape drives in the partition when the backup job is Automatically complete. Select this box to return the tape drive serial Return Drive numbers to the host connected to this partition.
Page 178: Secure Key
Chapter 3 Quantum PX720 Remote Management Setup The area below the section displays the current partition Partitions settings. Note: If this is the initial partitioning of the library after the partitioning upgrade has been added, select the default “library” partition and change the HBA assignment to 0.
Page 179: Figure 90 Secure Key Page
Chapter 3 Quantum PX720 Remote Management Setup Figure 90 Secure Key Page Quantum PX720 User’s Guide...
Page 180: Figure 91 Protection Mode For Cartridges
Chapter 3 Quantum PX720 Remote Management Setup The Secure Key page is divided into the following sections: • Protection Mode for Cartridges • Enable/Disable Secure Key for Drives • Modify Secure Key for Library • Assign Secure Key to Cartridge •...
Page 181: Figure 92 Enable/Disable Secure Key For Drives
Chapter 3 Quantum PX720 Remote Management Setup • - The secure key will never Never Write Secure Key to a Cartridge be written to a cartridge placed in a secured tape drive. • - The secure key will Only Write Secure Key to Blank Cartridges only be written to blank, unformatted cartridges.
Page 182: Figure 93 Modify Secure Key For Library
Chapter 3 Quantum PX720 Remote Management Setup Modify Secure Key for Library Refer to figure 93 for information on Modify Secure Key for Library Figure 93 Modify Secure Key for Library To modify the secure key used by the library: 1 Select the secure key name from the list of available names.
Page 183: Figure 94 Assign Secure Key To Cartridge
Chapter 3 Quantum PX720 Remote Management Setup Figure 94 Assign Secure Key to Cartridge Click to list all secured cartridges and their assigned secure key Find names. To assign a secure key to a cartridge: 1 Enter the barcode of the cartridge. Separate multiple barcodes with either spaces or commas.
Page 184: Figure 95 Create Secure Key Name/Secure Key Pair
Chapter 3 Quantum PX720 Remote Management Setup Figure 95 Create Secure Key Name/Secure Key Pair To create a secure key name/secure key pair: 1 Enter the Secure Key Name The secure key name must be less than 12 characters, may...
Page 185: Figure 96 Delete Secure Key Name
Chapter 3 Quantum PX720 Remote Management Setup Figure 96 Delete Secure Key Name maintained on the library are displayed in one of Secure Key Names three lists: • - keys not associated with any cartridges or tape Unused Secure Keys drives currently in the system.
Page 186: Figure 97 Backup Secure Key File
Chapter 3 Quantum PX720 Remote Management Setup Backup Secure Key File Refer to figure 97 for information on Backup Secure Key File Figure 97 Backup Secure Key File The list of maintained on the library Secure Key Name/Secure Key Pairs should be backed up to a local device whenever a change is made to the security keys.
Page 187: Figure 98 Upload Secure Key File
Chapter 3 Quantum PX720 Remote Management Setup Upload Secure Key File Refer to figure 98 for information on Upload Secure Key File Figure 98 Upload Secure Key File A file containing a list of can be Secure Key Name/Secure Key Pairs restored to the library.
Page 188: Utilities
Chapter 3 Quantum PX720 Remote Management Utilities Utilities page is divided into the following sections: Utilities • Library • Selftests • Barcode Tests • Logs • System Tests • Maintenance To access the page, from the page, click on the...
Page 189: Library
Chapter 3 Quantum PX720 Remote Management Utilities Figure 99 Utilities Page The library page is divided into the following sections: Library • Start/Stop Library • Online/Offline • Home Robotics • Reboot Library • Reboot CLM • Remove Cabinet (CLM Only) •...
Page 190: Figure 100 Library Page
Chapter 3 Quantum PX720 Remote Management Utilities Figure 100 Library Page Start/Stop Library button allows the user to start or stop the cabinet Start/Stop Library remotely. The action displayed on the button depends on the current state of the cabinet. If the cabinet is running, a...
Page 191: Quantum Px720 User's Guide
Chapter 3 Quantum PX720 Remote Management Utilities Online/Offline button allows the user to turn the cabinet online or Online/Offline offline remotely. The action displayed on the button will depend on the current state of the library or cabinet. If the library (cabinet) is online, an button will be displayed.
Page 192: Quantum Px720 User's Guide
Chapter 3 Quantum PX720 Remote Management Utilities 1 Click Reboot The library reboots. The browser is redirected to a Rebooting page. Reboot CLM button allows you to remotely reboot the cross link Reboot CLM mechanism (CLM). Note: option is only available is a CLM is installed Reboot CLM in the library.
Page 193: Selftests
Chapter 3 Quantum PX720 Remote Management Utilities • Drive — calibrates the tape drives within the cabinet Note: The library must be off-line before calibrating any element. To calibrate an element within the cabinet: 1 Select the element to calibrate and click Calibrate The element calibrates.
Page 194: Barcode Tests
Chapter 3 Quantum PX720 Remote Management Utilities Figure 101 Selftests Page To run a selftest on a cabinet: The library must be off-line before executing any selftests. Note: Note: If a CLM is installed in the library, you run selftest on the entire system or individual libraries or CLM.
Page 195: Figure 102 Barcode Tests Page
Chapter 3 Quantum PX720 Remote Management Utilities • - unique number for every cabinet Serial number • - Institute of Electrical and Electronics Engineers IEEE ID identification. • - PX720 or emulated P7000 Library type The barcode reader is also used to calibrate the robot's position during inventory.
Page 196: Logs
Chapter 3 Quantum PX720 Remote Management Utilities To perform a Barcode Test Note: The library must be offline to perform barcode tests. 1 Select a cabinet. 2 Select the type of test. 3 Click Read The results of the test are listed in the Previous Barcode Reader Test section.
Page 197: Figure 103 Logs Page
Chapter 3 Quantum PX720 Remote Management Utilities Figure 103 Logs Page There are three types of log files that can be retrieved from the PX720 library: • Tape Drive Logs (ADI Enabled drives only) • Bridge Traces and Event Logs (if bridges are present) •...
Page 198: Quantum Px720 User's Guide
Only the most recent bridge log file will be stored on the PX720 system.
Page 199: Quantum Px720 User's Guide
Chapter 3 Quantum PX720 Remote Management Utilities Cabinet/Robotic Controller Logs The Cabinet Controller (CC) and Robotics Controller (RC) Log files contain large amounts of information and may be helpful for diagnostic purposes. CC and RC Log files may be created either individually or combined into one file.
Page 200: System Tests
Chapter 3 Quantum PX720 Remote Management Utilities The system test section allows the user to run a series of tests on the System Tests library robotics and tape drives. If a system test is in process (initiated by another remote...
Page 201: Maintenance
Chapter 3 Quantum PX720 Remote Management Utilities The cabinet performs the system test. A progress window opens showing the progress of the system test. An button is available Abort to end the system test before it completes. If you leave the runs field empty, the system test will run continuously until you abort the system test.
Page 202: Figure 105 Maintenance Page
Chapter 3 Quantum PX720 Remote Management Utilities Figure 105 Maintenance Page The following maintenance functionality is supported: • Configuration Files • Upload Library Firmware • Upload Fibre Channel Bridge Firmware • Upgrade Drive Firmware Quantum PX720 User’s Guide...
Page 203: Table 34 Configuration File Types
Chapter 3 Quantum PX720 Remote Management Utilities Configuration Files Configuration files contain all of the configurable information on the library (see table 34). This configuration file should be saved on a local host on the same network. If the library configuration file is corrupted, this backup configuration file can be uploaded back to the library without reconfiguring the entire library.
Page 204: Quantum Px720 User's Guide
Chapter 3 Quantum PX720 Remote Management Utilities 1 Select to save a configuration file to your computer. Select Backup to restore a configuration file from your computer to the Restore library. Select to restore the configuration file to the factory Factory settings.
Page 205: Quantum Px720 User's Guide
Chapter 3 Quantum PX720 Remote Management Utilities To upload Fibre Channel bridge firmware: 1 Select the check box for each bridge to be updated. Upgrade 2 Enter a path and filename where the file exists, or click Browse 3 Click to upload the file.
Page 206: About
Chapter 3 Quantum PX720 Remote Management About About page contains the page and page. About About Links 1 To access the page, click on the tab at the top of the page. About About page displays the model number, software version, serial About number, and slot/drive configuration.
Page 207: Logout
Your browser must have access to the internet for these links to operate. Logout page allows you to logout of the PX720 remote management Logout pages. To logout of the library remote management pages, click Logout The browser closes.
Page 208: Chapter 4 Troubleshooting
Chapter 4 Troubleshooting This chapter describes problems you may encounter during the setup and operation of the Quantum PX720. Corrective information is provided to help you resolve the problems. Several of these problems produce error messages on the OCP called sense data values.
Page 209: Table 35 Start-Up Problems
Communication error between the robot Communication controller and cabinet controller has been Error lost. Reboot the library. If the problem continues, contact an authorized Quantum field service engineer. Tape drive cluster is Turn both switches on the tape drive not recognized after...
Page 210: Ocp Problems
Corrective Action The OCP is blank. Confirm that power is on, then contact an authorized Quantum field service engineer. The OCP does not Contact an authorized Quantum field service respond to engineer. buttons. An error message Write down the details of the error message, is displayed.
Page 211: Operating Problems
Check cable connections, cable length, SCSI the library. addresses, and termination. Restart the host and the library. If the host and library still are not communicating, contact an authorized Quantum field service engineer. Quantum PX720 User’s Guide...
Page 212: Quantum Px720 User's Guide
Stop button is displayed. If using the remote management pages, the library must be off-line. Retry the command. A flash memory Contact an authorized Quantum field service error is reported. engineer. A maximum Turn off the library and allow it to cool down.
Page 213: Tape Drive Led Conditions
Quantum Enterprise Storage on the OCP and Partner (reseller or VAR), your Quantum sales remote representative or Quantum Corporate at 1-800- management 677-6268 (or 949-856-7800 for international) or present.
Page 214: Quantum Px720 User's Guide
LEDs will turn ON. If the condition persists, call an off and obey the firmware authorized Quantum field service command). engineer. Flashing Microbridge incompatibility Contact an authorized Quantum (under hardware control). field service engineer. Quantum PX720 User’s Guide...
Page 215: Figure 108 Tape Drive Leds
Chapter 4 Troubleshooting Common Problems and Solutions Figure 108 Tape Drive LEDs Red LEDs Green LEDs Quantum PX720 User’s Guide...
Page 216: Appendix A Library Specifications
Appendix A Library Specifications This appendix lists characteristics and specifications of the Quantum PX720. These characteristics and specifications are categorized as follows: • Physical Characteristics • Performance and Reliability Characteristics • Environmental Specifications Note: For tape drive specifications see the appropriate tape drive product manual.
Page 217: Table 40 Physical Characteristics
Appendix A Library Specifications Physical Characteristics Table 40 Physical Quantum PX720 Dimensions and Weight Characteristics Width 30 in. (76 cm), packaged: 48 in. (122 cm) Depth 50 in. (127 cm), packaged: 56 in. (142 cm) Footprint 30 x 50 in. (76 x 127 cm), packaged: 48 x 56 in.
Page 218: Performance And Reliability Characteristics
Less than 30 minutes MTTR Environmental Specifications Table 44 provides various library environmental specifications. Table 44 Environmental Power Environment Specifications Electrical inputs Voltage 200 VAC to 240 VAC Rated Frequency 50/60Hz Rated Current Power consumption VA max 1600W Quantum PX720 User’s Guide...
Page 219: Quantum Px720 User's Guide
Indirect ESD Contact discharge @ 2, 4, 6, 8kV to the VCP Radiated fields Unmodulated 27MHz to 500MHz@ 3 V/ per IEC-801-3 Fast transients Data cables @ 0.5kV (EFT or Burst) Power cables @ 1kV per IEC801-4 Quantum PX720 User’s Guide...
Page 220: Table 45 Electromagnetic Interference/ Electromagnetic Compatibility
230MHz – 1000MHz VCCI (Japan) 47dBuV/m, Class 1GHz – 10GHz AS/NZS 3548 (Australia/ New Zealand) 60dBuV/m, Class CNS13438 (Taiwan) RF Emissions per Radiated Emissions Legal Limits CFR47, Part 15 (FCC) 1GHz – 10GHz 60dBuV/m, Class A (3 meters) Quantum PX720 User’s Guide...
Page 221: Quantum Px720 User's Guide
Legal Limits: +2kV, +4kV Quantum Limits: +6kV, +8kV RF Radiated Fields per Radiated Fields Legal Limits: EN55024 (European Union, 80MHz – 1000MHz 3V/m, 80% AM Limits) Modulation EN61000-4-3 (Test Quantum Limits Procedure) 10V/m, 80% AM Modulation Quantum PX720 User’s Guide...
Page 222: Quantum Px720 User's Guide
Surge per Power Line Coupling Legal Limits: EN55024 (European Union, 3Vrms, 80% AM Limits) Modulation EN61000-4-5 (Test Quantum Limits Procedure) 10V/m, 80% AM Modulation Legal Limits: 3Vrms, 80% AM Modulation Quantum Limits 10V/m, 80% AM Modulation Quantum PX720 User’s Guide...
Page 223: Quantum Px720 User's Guide
0V for 5 seconds Harmonic Current Harmonic Emissions Legal Limits: Emissions per 100Hz – 2000Hz Class A Limit per EN61000-3-2 Specification (Up to 40 Harmonic) Voltage Flicker per Power Line Coupling Legal Limits: EN61000-3-3 per Specification Quantum PX720 User’s Guide...
Page 224: Appendix B Relocating The Library
Quantum PX720 to another location. This appendix explains how to relocate the Quantum PX720. As used in this appendix, the term relocate means either to ship the library or simply to move it to a nearby location (for example, from one area in a building to another).
Page 225: Checking The New Installation Site
Checking the New Installation Site Check the new installation site for the library using the guidelines found in the Quantum PX720 Pre-Installation Site Survey Instructions. Make sure the new location meets all applicable clearance, environmental, and power requirements.
Page 226: Removing Tape Cartridges
5 Carefully pack all tapes for shipment. Installing Shipping To install internal shipping restraints: Restraints and Packing 1 Remove the robot shipping restraints from their storage location under the left cartridge slot panel (see figure 109). Quantum PX720 User’s Guide...
Page 227: Figure 109 Shipping Restraints - Storage Location
2 If the cartridge handling mechanism (CHM) is not in the far right position, gently move it along the horizontal carriage until it is as far front as possible. 3 Install the robotic shipping restraints as shown in figure 110. Quantum PX720 User’s Guide...
Page 228: Figure 110 Installing The Robotic Shipping Restraint
Appendix B Relocating the Library Preparing the Library for Relocation Figure 110 Installing the Robotic Shipping Restraint Robot Vertical axis shipping restraint shipping restraint 4 Open the back library door and install the counterweight as shown in figure 111. Quantum PX720 User’s Guide...
Page 229: Disconnecting Library Cables
• If you need to ship the library to the new site. • If you need to transport the library by forklift or similar means. If you are moving the library within a facility, refer to Preparing the Library for Operation on page 209. Quantum PX720 User’s Guide...
Page 230: Crating The Library
5 Place the foam cap over the library. 6 Wrap the cardboard crate around the library (see figure 112) and fasten it using the plastic restraining clips. 7 Place the top onto the crate. 8 Secure the crate with two steel restraining bands. Quantum PX720 User’s Guide...
Page 231: Figure 112 Crating The Library
Appendix B Relocating the Library Crating the Library Figure 112 Crating the Library Quantum PX720 User’s Guide...
Page 232: Preparing The Library For Operation
Appendix B Relocating the Library Preparing the Library for Operation Preparing the Library for Operation After shipping or moving the library, refer to the Quantum PX720 Pre- Installation Site Survey Instructions and the Quantum PX720 Unpacking Instructions to: • Prepare the new installation site •...
Page 233: Appendix C Event Reporting
Appendix C Event Reporting The Quantum PX720 is capable of reporting a variety of events that occur within the cabinet. These events are either report through the OCP and remote GUI or through e-mail alerts. Quantum PX720 Events are broken up into the following sections: •...
Page 234 Updated IP address Updated subnet mask Updated hostname Updated domain Updated default gateway Updated email server Updated DNS address Library Name changed Library shutdown requested from remote GUI Library reboot requested from remote GUI Contract number updated Quantum PX720 User’s Guide...
Page 235 End LoadPort unload Library shutdown requested from OCP Library reboot requested from OCP HP Interface Manager Present Library Database Factory Settings Restored Library Vendor Defaulted to Quantum System Test Started System Test Completed System Test Aborted Library reboot/shutdown via hardware switch...
Page 236: Warning Events
Warning events indicate that a possible error condition exists within the cabinet. These events give the user a chance to check the cabinet before a failure occurs. Table 47 lists the warning events provided by the PX720. Table 47 Warning Events Warning Events No mond connection...
Page 237: Critical Events
Critical events indicate that a failure has occurred in the cabinet. The user must intervene to return the cabinet to operation. Table 48 lists the critical events provided by the PX720. Table 48 Critical Events Critical Events Fork new ted failed...
Page 238 Unable to communicate with cabinet task process Cabinet Controller Connection Failure Cabinet Controller Connection Lost HP Interface Manager Not Present Event Monitor Failure * indicates a variable character. This will change depending on the specific item within the cabinet. Quantum PX720 User’s Guide...
Page 239: Appendix D Regulatory Statements
This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: 1 This device may not cause harmful interference, and 2 This device must accept any interference received, including interference that may cause undesired operation. Quantum PX720 User’s Guide...
Page 240: Japan Statement (Vcci)
Appendix D Regulatory Statements Japan Statement (VCCI) Taiwan Statement !" #$%&'()*+ ,-. Japan Statement (VCCI) DEN-AN Notice (Japan Industry Canada Digital Apparatus) Quantum PX720 User’s Guide...
Page 241: Industry Canada (Digital Apparatus)
200-240V operation. Plug Cap NEMA twist-lock plug with ground pin (NEMA L6-20P configuration) Cord Type: SJT, three 12 AWG (3 x 2.50 mm ) or 18 AWG (1.0 mm ) wires Quantum PX720 User’s Guide...
Page 242: Cette Remarque Ne Concerne Que Les Etats-Unis Et Le Canada
The foregoing notice is provided in accordance with California Code of Regulations Title 22, Division 4.5 Chapter 33, Best Management Practices for Perchlorate Materials. This product/ part includes a lithium battery which contains a perchlorate substance. Quantum PX720 User’s Guide...
Page 243 Tämä tuote sisältää litiumparistoja. ST Micro M4Z28-BR00SH1 - litiumparisto sijaitsee robottitaulussa. Renata CR1225FH-, Panasonic BR1225/1HC- tai Ray-O-Vac BR1225T2-litiumparisto sijaitsee kotelon ohjaintaulussa. Upotettu Dallas Semiconductor DS17887-3 -litiumparisto sijaitsee kuitukanavan ohjaintaulussa. Hävitä paristo paikallisten ja valtakunnallisten säädösten mukaan. Quantum PX720 User’s Guide...
Page 244 Vac BR1225T2 se encuentran ubicadas en la placa del controlador del armario. La batería de litio incorporada Dallas Semiconductor DS17887-3 se encuentra ubicada en la placa del controlador de canal de fibra. Deseche la batería conforme a la norma local, estatal y federal vigente. Quantum PX720 User’s Guide...
Page 245 VARNING BR00SH1 sitter på robotkortet. Litiumbatteriet Renata CR1225FH, Panasonic BR1225/1HC eller Ray-O-Vac BR1225T2 sitter på Cabinet- styrkortet. Det inbyggda litiumbatteriet Dallas Semiconductor DS17887-3 sitter på Fibre Channel-styrkortet. Kasta batteriet i enlighet med lokala och nationella lagar. Quantum PX720 User’s Guide...
Page 246: Electronic Waste, Recycling, And Disposal - Weee
For more information about where you can drop off your waste equipment for recycling, please visit our website at: http://qcare.quantum.com or contact your local government authority, your household waste disposal service or the business from which you purchased the product. Quantum PX720 User’s Guide...
Page 247: Declaration Of Conformity
Appendix D Regulatory Statements Declaration of Conformity Declaration of Conformity Quantum PX720 User’s Guide...
Page 248 This allows the user to add more available Capacity on Demand (COD) slots to the library. Blocks of data are stored on the tape medium Check Condition status along with additional information that the library controller uses Quantum PX720 User’s Guide...
Page 249 Class 1 lasers may therefore be considered eye safe. Class 2 lasers are limited to a maximum output Class II laser product power of 1 mW. A person receiving an eye exposure from a Class Quantum PX720 User’s Guide...
Page 250 IP address can even change while it is still connected. DHCP also supports a mix of static and dynamic IP addresses. Digital Linear Tape technology is owned, developed, and manufactured by Quantum Corporation. DLT tape drives use half-inch wide tape. DLT 8000 tape drives record on 208 tracks (uncompressed).
Page 251 High Voltage Differential or HVD (also called Differential SCSI). The benefit of using HVD cabling is that it works well in noisy areas and can reach up to 25 meters in distance. Quantum DLT8000 and SDLT tape drives can be HVD or LVD devices.
Page 252 It consists of a viewing panel and 4 buttons allowing the user to receive information and imput commands. When the library is in P7000 identity mode, the PX720 will P7000 Identity appear to the host as P7000 library. This is useful when a backup package does not recognize the PX720 identity.
Page 253 CD-ROMs, scanners, medium changers, and communication devices. Super Digital Linear Tape is a Quantum tape drive and tape SDLT cartridge specification offered in three ranges of capacity and transfer rates for workgroup, mid-range, and enterprise needs.
Page 254 95 communication 56 slow mode 56 browser, internet 87 cabinet status 107 stopped 56 buttons cabling routing for the PX720 31 upgrading FW 57 OCP 54 calibrate user needed 57 from remote management pages automatic drive unload from remote...
Page 255 169 warning message 140 performance 7 HP LTO-3 performance 8 HP LTO-4 performance 8 date and time factory defaults configuration 143 restore from OCP 70 deleting a library partition 155 FC470 132 DHCP features 17 Quantum PX720 User’s Guide...
Page 256 154 library 7 OCP information 60 return drive serial numbers to monitor button 91 the host 154 power-on offline 146 move media 116 slot count 153 quick load port open 146 Quantum PX720 User’s Guide...
Page 257 74 Fibre Channel bridge 170 ESD 41 – overview 53 restore factory defaults 70 prefix media type problems 187 robot barcode 147 reset password 146 home 168 problems stop/start button 82 robotics controller 32 OCP 187 Quantum PX720 User’s Guide...
Page 258 SNMP trap 138 send test inserting into load ports 82 critical 142 email 140 inventory 26 informational 142 sense data values 185 loading 34 warning 142 service tray 34 specifications session timeout 96 barcode labeling 45 Quantum PX720 User’s Guide...
Page 259 177 error status 106 timeout event log 98 session 96 events 138 transfer rate 27 find 110 traps identification 124 SNMP 138 inventory 118 – troubleshooting 185 library 144 OCP 187 menu items 87 operating 188 Quantum PX720 User’s Guide...
