- Page 1 Introduction Removing the Library from the Rack Installing the Internal Shipping Restraints Packing the Library for Shipment Document 81-81453-02 A01, January 2006 Chassis Repacking Instructions Quantum PX502...
- Page 2 Made in the USA. Quantum Corporation provides this publication “as is” without warranty of any kind, either express or implied, including but not limited to the implied warranties of merchantability or fitness for a particular purpose. Quantum Corporation may revise this publication from time to time without notice.
-
Page 3: Removing The Library From The Rack
Introduction This document explains how to repack the Quantum PX502 library. Follow these instructions carefully to ensure the library is shipped properly. This procedure consists of the following steps: • • • Removing the Library from the Rack To remove the PX502 library from the rack:... - Page 4 Disconnect all power supply cords before servicing to avoid electric shock. 4 To remove the library chassis from the rack (see Refer to the PX502 Quick Start Guide (PN 81-81292) for Note: additional PX502 rack mount information. Loosen the captive screws securing the tape drives to the chassis and remove the tape drive(s) from the back of the library.
- Page 5 Quantum PX502 Chassis Repacking Instructions Document 81-81453-02 A01 January 2006 Figure 1 Removing the PX502 Library Tape drives Power supplies Right magazine Removing the Library from the Rack...
-
Page 6: Installing The Internal Shipping Restraints
FlexLink™ cover and top cover plate to the library chassis (see figure If the bottom FlexLink cover has been removed, replace it Note: before shipping the library back to Quantum. FlexLink cover Installing the Internal Shipping Restraints Top cover... - Page 7 Figure 3 Moving the Robotics Quantum PX502 Chassis Repacking Instructions 2 If the library is not operational and the not executed, grasp the robotics and gently move it to the front of the library (see figure Take standard ESD precautions when working within the Caution: library chassis.
- Page 8 Quantum PX502 Chassis Repacking Instructions Document 81-81453-02 A01 January 2006 Figure 4 Installing the Metal Restraints 4 Install the two halves of the robotics shipping foams as shown in Install the left-hand foam first so that it fits down into the robotics platform, then push towards the back of the unit until it stops.
- Page 9 Robotics motor Foam inside robotics platform Quantum PX502 Chassis Repacking Instructions Right-hand shipping foam 5 Slide the robotics with the shipping foams under the metal restraints so the metal bands fall into the restraint cutouts. Clamp the two halves of...
- Page 10 Quantum PX502 Chassis Repacking Instructions Document 81-81453-02 A01 January 2006 Figure 6 Securing the Robotics Tie band 6 Install the top covers previously removed in 7 Install the tape drives, and power supplies previously removed in Removing the Library from the...
- Page 11 Quantum PX502 Chassis Repacking Instructions Document 81-81453-02 A01 January 2006 Figure 7 Opening the Right and Left Magazine Access Doors Left magazine door Right magazine door Door releases 9 Install the tape cartridge magazines. Installing the Internal Shipping Restraints...
-
Page 12: Packing The Library For Shipment
Quantum PX502 Chassis Repacking Instructions Document 81-81453-02 A01 January 2006 Packing the Library for Shipment Figure 8 Preparing the Library for Shipping 1 Package the library into the shipping carton as shown in that the library chassis is placed in an antistatic bag before placing the library in the shipping carton.
