EPSON Stylus Photo RX700
Category Error Code
50H Home seek error
51H CR unlocking error
Sequence error
52H CR locking error
60H PW detection error (Hi check error)
Sensor error
61H PW detection error (Low check error)
62H Tray detection (CDR detector 2) error
Sensor error
63H Paper detection error
A0H Waste ink overflow
A1H Platen waste ink overflow
Maintenance
error
A2H Ink holder waste ink overflow
A3H Tube maintenance error
Troubleshooting
Table 3-3. Fatal Errors (continued)
Error
An error occurred in the
carriage operating sequence.
PW detector trouble
Sensor trouble
Life expiration of maintenance
parts
Overview
Cause
Checking the operation of the Carriage Assy:
Move the Carriage Assy by hand, and check to see if it moves
smoothly.
Making the following adjustments:
♦
Bi-D
♦
PF
♦
Right and left margin adjustment
♦
PW adjustment
Checking the following parts and replace the defective one:
♦
Checking the head FFC (CN6~9) for disconnection or breakage
♦
Checking the lead wires of the CR Motor ~ Relay Connector (CN19)
for disconnection or breakage
♦
Checking the CR Encoder FFC (CN3) for disconnection or breakage
♦
Checking the CR Guide Shafts (Main & Sub) for adhesion of dirt or
insufficient lubrication
♦
Checking the Linear Scale for adhesion of dirt or damage
♦
Checking the CR Encoder for adhesion of dirt or damage
♦
Checking the PW Sensor for adhesion of dirt or damage
♦
Checking the CR Belt for damage or improper tension
♦
Checking the CR Motor and replacing it if necessary
♦
Main Board (p.86)
♦
Power Supply Board
Checking the PW Sensor
♦
Checking the PW Sensor for adhesion of dirt and dust
♦
Checking the connection of the FFC (PW Sensor ~CR Encoder Board
~Main Board)
Making the following adjustments:
♦
Right and left margin adjustment
♦
PW adjustment
Checking the following parts and replace the defective one:
♦
FFC
♦
Valve Assy
♦
Carriage Assy
♦
Main Board (p.86)
♦
Power Supply Board
Check the operation of the actuator and the connection of the connector.
Replacing the sensor
Replace all the maintenance parts, and clear the maintenance counter.
♦
Refer to Maintenance Error (p.147)
Revision A
Remedy
(p.91)
(p.118)
(p.118)
(p.118)
(p.115)
(p.109)
(p.118)
(p.109)
62
