Scalar i40 and Scalar i80 Quick Start Guide
Figure 5 Reinstalled
Components

Turning the Library ON and Configuring Network Settings

8
Caution: Before turning the library on, make sure you removed the shipping restraint
(4 thumbscrews, mylar sheet, metal clip) from the top of the library!
Otherwise, the library will not initialize. See
1 Turn the library ON by pressing the power button on the front bezel (see
• The green power LED on the front panel above the power button illuminates,
and the LCD screen turns on. The library goes through a connection and
initialization sequence. This can take 5 to 17 minutes, depending on the size of
your library.
• The status LED on the rear of each drive sled turns green during initialization.
Power supply cord
Ethernet
Service port –
cable in LEFT
do not use
SCB port
Figure 2
Turning the Library ON and Configuring Network Settings
Filler plate
on page 4.
Figure 6).
