Accessory Kit Contents

Installing the Library in a Rack or Desktop Kit

Installing the Tape Drives

Tape Drive Slot Location
Considerations
Accessory Kit Contents
9 Once you remove the robot restraint, you may cover the holes in the library top
cover with stickers, which are provided in the accessory kit for this purpose. This
step is optional and is intended to prevent small objects from accidentally falling
into the library through the holes.
10 Remove the protective plastic sheet covering the front panel display.
• Power cord(s) – one for each power supply
• Scalar i40 and Scalar i80 Documentation and Training CD
• Scalar i40 and Scalar i80 Quick Start Guide
China RoHS
• statement
• System, Safety, and Regulatory Information Guide
• Stickers (clear, round) to cover holes in library top cover
Follow the instructions that came with your rail kit or desktop kit to install the library.
If your library already has tape drives installed, skip this section.
Tape drives can only fit in certain slots, as described below and illustrated in
Slots are numbered starting from the bottom and moving up.
• Scalar i40: Half-height tape drives can be installed in slots 1 and 2.
• Scalar i80: Half-height tape drives can be installed in slots 1, 2, 3, 4, and 5.
It is recommended to start installing the tape drives at the bottom slot and work up,
without leaving spaces between.
Scalar i40 and Scalar i80
Figure 3.
5
