Scalar i40 and Scalar i80 Quick Start Guide
Figure 2 Removing the Robot
Restraint
4
3 Remove the top foam.
4 Scalar i80 only: Remove the shipping carton by lifting it straight up out of the
bottom tray.
5 With the help of a second person, lift the library chassis out of the bottom foam and
place it on a table approximately waist high.
WARNING: Two people are required to safely lift the library out of its packaging
or into a rack.
Caution: Lift the library chassis at the sides. Avoid putting the weight of the
library chassis on the front bezel.
6 Remove the anti-static wrapping from the library. Keep the anti-static wrapping
intact so that you can use it later if needed.
7 Save the packing box, packaging material, and anti-static wrapping in case you need
to move or ship the library in the future.
8 Remove the robot restraint. The robot restraint consists of four (4) thumbscrews, a
plastic sheet, and a small metal clip, located on the top cover of the library. (See
Figure 2.)
a Unscrew and remove the four thumbscrews from the top cover (see
Save the thumbscrews in case you need to move or ship the library in the future.
Note: The robot may stay at the top of the library, or it may move downward
toward the floor of the library. If it moves downward, you will hear the
gears turning as it moves. This is normal.
b Remove the plastic sheet and metal clip and discard. You will not need to use
them again.
Plastic
sheet
Metal
clip
Figure 2).
Unpacking the Library
