PARTS LIST

Ref. No.

Part No.

TK5AD002

TK2953310A

TK21046350

TK21102320

TK21145031

TK21145230

TK21145240

TK21035093

TK21176550

TK21291290

TK28061360

TK2912304A

TK2952265A

TK2952266A

TK2952266C

TKAKC420G9C

TKAKC421G9C

TKAKC401G9C

TKAKC403G9C

TKAKC422G9C

TK22331630

TK22331730

TK22331341

TK22331321

TK22331700

TK22240240

TK35U95B0

TK35U42B0

TK35V01B0

TK29A5208C

TK35U94A0

TK35V09A0

TK35V10A0

TK35V00A0

TK37306B0

TK37303B0

TK22331640

TK22331750

TK22331710

TK21176820

TK2958266A

TK22060460

TK22060450

CABINET & CHASSIS

Description

DECK MECHANISM (ADC2345BDS)

DPBB-3X10SSA

COVER (TOP)

DECK BRACKET

HEATSINK (MITSUMI) (FXR-725GD/A.SS, SS, XE)

HEATSINK (2P) (FXR-730GD/A.SS)

HEATSINK (2P-CDC) (FXC-750GD/A.SS, FXC-755RDS/XE)

CHASSIS ASSY (CST)

BRACKET ASSY (DET)

PLATE SPRING (REL)

INSULATOR (PCB)

APPM-3X4SSA

DPBS-2.6X5SSA

DPBS-2.6X6SSA

DPBS-2.6X6SSC

FPPART FXR725GD/SSSOP (FXR-725GD/A.SS, FXR-725GD/SS)

FPPART FXR725GD/XESOP (FXR-725GD/XE)

FPPART FXR730GD/ASSSOP (FXR-730GD/A.SS)

FPPART FXC750GD/SSSOP (FXC-750GD/A.SS)

FPPART FXC755RDS/XESOP (FXC-755RDS/XE)

FPASSY(A) (FXR-725GD/XE)

FPASSY(A) (FXR-725GD/SS, A.SS)

FPASSY(A) (FXR-730GD/A.SS)

FPASSY(A) (FXC-750GD/A.SS)

FPASSY(A) (FXC-755RDS/XE)

FACE PLATE(B) (FXR-725GD/ASS, SS, XE, FXR-730GD/A.SS,

DISP CIRCUIT BOARD (FXR-725GD/A.SS, SS, XE)

DISP CIRCUIT BOARD (FXR-730GD/A.SS, FXC-750GD/A.SS)

DISP CIRCUIT BOARD (FXC-755RDS/XE)

TPB2-2X8SSC

MAIN CIRCUIT BOARD (FXR-725GD/A.SS, SS, XE)

MAIN CIRCUIT BOARD (FXR-730GD/A.SS)

MAIN CIRCUIT BOARD (FXC-750GD/A.SS)

MAIN CIRCUIT BOARD (FXC-755RDS/XE)

BL ASSY RF33S (FXR-730GD/A.SS, FXC-750GD/A.SS)

BL ASSY RF33R (FXC-755RDS/XE)

FPASSY (C) (FXR-725GD/A.SS, SS, XE, FXR-730GD/A.SS)

FPASSY (C) (FXC-750GD/A.SS)

FPASSY (C) (FXC-755RDS/XE)

BRACKET (STOPPER)

DPSS-2.6X6SSA

ESC ADAPTOR (SANYO) (FXR-725GD/XE, FXC-755RDS/XE)

ESC ADAPTOR (E-1.5) (FXR-725GD/SS, A.SS, FXR-730GD/A.SS,

— 17 —

FXC-750GD/A.SS, FXC-755RDS/XE)

FXC-750GD/A.SS)
